6. To re-enable a Serial Port:
Click on the down arrow of Available Serial Ports.
Under Settings, select Enable for Serial Port 1 or Serial Port 2.
7. To re-enable the Parallel Port:
Under Settings, click the down arrow to locate Parallel Port.
Select Enable.
8. Save the configuration and exit the utility.
9. Reboot the workstation.

QuickLock

The QuickLock feature disables the keyboard and mouse interfaces while an application is open.
The feature is enabled with a Power-on Password. When this feature is used, the computer is
secure until you enter the Power-on Password.
QuickLock is enabled through Security Management. The keyboard and mouse interface can be
disabled from within an application. Entering a QuickLock key combination (Ctrl+Alt+L) disables
the keyboard and the mouse interface.
To re-enable the input device interface and access the application, you must enter the Power-on
Password established in Security Management.
To enable the QuickLock feature from the Compaq Utilities menu:
1. Turn on the workstation.
When you see the words "F10=Setup" in the bottom-right corner of the screen, press F10.
2.
NOTE: You have approximately two seconds to press F10. If you do not press F10 during this
time, restart the computer to access the utility.
3. Select the desired language when prompted. Then press Enter to bypass the welcome
screens and display the Compaq Utilities menu.
4. Select Computer Setup, then press Enter.
5. Select Built-ins Devices.
6. Select the Security Management feature and press Enter.
7. When the steps in the Security Management screen display, select Enable QuickLock of
the Keyboard.
8. Select QuickLock.
9. Click OK to save the configuration.
10. On the Main screen, select Save, and exit from the File menu.
Compaq Professional Workstation AP400 Maintenance and Service Guide
5-11
