Pin
Signal
1-16
Ground
17 - 18
TERMPWR
19
Reserved
20 - 34
Ground
35
-D12
36
-D13
37
-D14
38
-D15
39
-DP1
40
-D0
41
-D1
42
-D2
43
-D3
44
-D4
45
-D5
46
-D6
47
-D7
48
-DP0
49 - 50
Ground
Table 8-11
SCSI Connector
Connector and Icon
Pin
51 - 52
TERMPWR
53
Reserved
54
Ground
55
-ATN
56
Ground
57
-BSY
58
-ACK
59
-RST
60
-MSG
61
-SEL
62
-C/D
63
-REQ
64
-I/O
65
-D8
66
-D9
67
-D10
68
-D11
Compaq Professional Workstation AP400 Maintenance and Service Guide
8-7
Signal
