3-26 Removal and Replacement Procedures
6. Connect the cables to the rear of the drive.
7. Remove the blank bezel from the front bezel.
8. Replace the front bezel and the workstation cover.
To remove a 5.25-inch device in Bay 4, reverse the above steps.
Removing and Replacing a 10K RPM Hard Drive in Bay 4
To remove a 10K RPM hard drive from Bay 4:
1. Perform the service preparations described on page 3-2.
2. Remove the following components:
workstation cover
front bezel
5.25-inch drive (to access hard drive cables)
hard drive from bay 5 (if installed)
NOTE: If there is a hard drive in bay 5, you must remove it to access the mounting holes for the
retaining screws securing the drive assembly. For information on removing a hard drive from
bay 5, see "Bay 5" in this chapter.
CAUTION: When servicing the workstation, make sure cables are placed in their
proper locations during the reassembly process. Improper cable placement can
damage the computer.
CAUTION: Do not route cables near the intake of the power supply. Cables
routed in this manner may block airflow to the power supply, causing it to
overheat.
