Drive Size:
5
3
1
6
4
2
Configuration
Single (Standard Installation)
Dual Master
Dual Slave
Cable Select (Shipping Configuration)
Single (Neutral Position)
Key
Jumper NOT Installed
Jumper Installed
Figure 6-7. Jumper positions for the 6.4-GB hard drive (AC36400-60LC)
6.4 GB
Model:
IDE Settings
Compaq Professional Workstation AP400 Maintenance and Service Guide
AC36400-60LC
1-2
3-4
5-6
6-7
