3-4 Removal and Replacement Procedures
4. Rotate the workstation cover up, remove the front lip of the cover from under the front
bezel, and lift off the cover.
Figure 3-4. Removing the workstation cover
To replace the workstation cover:
1. Be sure all grounding clips and EMI gaskets (shielding strips) are in place.
2. Hold the cover in an almost vertical position, and hook the front lip of the cover behind
the front bezel. Then, rotate the cover down onto the unit.
3. Tighten the thumbscrews on the rear of the workstation.
WARNING: To reduce the risk of personal injury from hot surfaces, allow the
internal system components to cool before touching.
