Video Test Error Codes
Error Code
2424-xx
2425-xx
2431-xx
2432-xx
2448-xx
2451-xx
2456-xx
2458-xx
2468-xx
2477-xx
2478-xx
2480-xx

Network Interface

Error Code
6000-xx
6014-xx
6016-xx
6028-xx
6029-xx
6054-xx
6056-xx
6068-xx
6069-xx
6089-xx
Continued
Description
ECG/VGC monochrome text mode test failed.
ECG/VGC monochrome graphics mode test
failed.
640 × 480 graphics test failure.
320 × 200 graphics (256 color mode) test
failure.
Advanced VGA Controller test failed.
132-column Advanced VGA test failed.
Advanced VGA 256 Color test failed.
Advanced VGA Bit BLT test.
Advanced VGA DAC test.
Advanced VGA data path test.
Advanced VGA Bit BLT test.
Advanced VGA Linedraw test.
Network Interface Test Error Codes
Description
Network ID test failed.
Network configuration test failed.
Network reset test failed.
Network internal test failed.
Network external test failed.
Network configuration test failed.
Network reset test failed.
Network internal test failed.
Network external test failed.
Network open test failed.
Recommended Action
The following steps apply to error codes 2402-xx
through 2456-xx:
1. Run the Setup and Diagnostics utilities.
2. Replace the monitor and retest.
3. Replace the graphics controller and retest.
The following steps apply to error codes 2458-xx
through 2480-xx:
1. Replace the graphics controller and retest.
2. Replace the system board with tray and retest.
Table 4-24
Recommended Action
The following steps apply to error codes 6000-xx
through 6089-xx:
1. Turn the workstation off then on (cold boot) and run
Computer Setup or Windows NT utilities.
2. Verify test procedures.
3. Replace the network board, if installed.
4. Replace the system board with tray.
Compaq Professional Workstation AP400 Maintenance and Service Guide
4-25
