Comtech EF Data CIM-550 Installation And Operation Manual page 93

CiM-550 IP Enabled Satellite Modem
Remote Control
Parameter Command Arguments for
Command or
Type (Instruction
Response to
Code and
Query
qualifier)
Unit ITF= 1 byte, value of
1,2,3 or 4
Interface
Type
IP Address IPA= 18 bytes,
and network numerical
prefix
Unit FRM= 1 byte, value of
Framing 0 or 1
Mode
Unit Test TST= 1 byte, value of
0 1 2 3 4
Description of arguments
(note that all arguments are ASCII numeric
codes, that is, ASCII codes between 48 and 57)
1 = +/- 256 bits
2 = +/- 512 bits
3 = +/- 1024 bits
4 = +/- 2048 bits
5 = +/- 4096 bits
Command or Query.
Terrestrial interface type, where:
1 = EIA-422/EIA530 DCE,
2 = V.35 DCE
3 = EIA-232 (sync).
4 = IP interface
All other codes invalid. Example: ITF=2 (V.35)
Command or Query.
IP Address and network prefix in the following
format:
xxx.xxx.xxx.xxx.yy
Where:
xxx.xxx.xxx.xxx is the address and yy is the
network prefix (0-31)
Example: IPA=010.006.030.001/24
Command or Query.
Unit operating mode, where
0 = Unframed - transparent (distant-end M&C not
possible)
1 = Framed (EDMAC distant-end M&C possible)
Example: FRM=1 (which is framed)
0 = Normal
67
Response to Command Query
(target to controller)
(Instruction
Code and
qualifier)
but invalid argument found)
RBS* (message ok, but not
permitted in current mode)
ITF= (message ok) ITF?
ITF? (received ok, but
invalid args found)
ITF* (message ok, but not
permitted in current mode)
IPA= (message ok) IPA?
IPA? (received ok,
but invalid arguments found)
IPA* (message ok, but not
permitted in current mode)
FRM= (message ok) FRM?
FRM? (received ok,
but invalid argument found)
FRM* (message ok, but not
permitted in current mode)
TST= (message ok) TST?
Rev. 2
CD/CIM550.IOM
Response to
query
(target to
controller)
command
argument)
ITF=x
(same format
as command
argument)
IPA=xxx.xxx.xxx
.xxx.yy
(same format as
command
arguments)
FRM=x
(same format as
command
argument)
TST=x
