CiM-550 IP Enabled Satellite Modem
Web Server Pages
12.3.6.3 M
ULTICAST
Field
Name
Multicast IP Address
LAN to WAN
WAN to LAN
Sort By
Downlink Route All
Available Multicast
R C
OUTES ONFIGURATION

Table 12-5. Multicast Routes Configuration Fields

Description
Enter a valid route name to add or delete. This field is case
sensative, however leading and tailing white space is automatically
removed.
Enter a valid multicast route address. Multicast addresses have the
Class A value of 224 (ie, 224.10.2.1). IP mask is set to 32 bits.
Set to indicate whether this multicast address routes traffic from the
Lan to the Wan (Ether to Satellite).
Set to indicate whether this multicast address routes traffic from the
Wan to the Lan (Satellite to Ether).
Allows sorting of the multicast address table by route name or IP
address.
This read-only parameter lets the user know if the administrator has
enabled the "Downlink Route All Available" feature.
189
Rev. 2
CD/CIM550.IOM
