CiM-550 IP Enabled Satellite Modem
SNMP interface
13.4.1.2 C M A
I CCESS
The Access Client List allows an operator to define which remote clients can connect to a
CiM-550 when the Access List Enforcement is enabled. Each entry allows an operator to
specify an IP address and a subnet mask to define a unique class of clients that are
allowed access to the CiM-550.
OID
cimAccessIpAddress1
cimAccessSubnetMaskLen1
cimAccessIpAddress2
cimAccessSubnetMaskLen2
cimAccessIpAddress3
cimAccessSubnetMaskLen3
cimAccessIpAddress4
cimAccessSubnetMask4
cimAccessListEnforcement
Be sure that you have added the SNMP browser's/manager's IP
Address to the access list before enabling access list filtering.
Otherwise, the SNMP browser/manager will no longer be able to
CAUTION
gain access to the CiM.
L S
ISTS UBGROUP

Table 13-17. CiM Access Lists Subgroup OIDs

Description
Defines an access IP address.
Defines the subnet mask length of the corresponding IP
address.
Defines an access IP address.
Defines the subnet mask length of the corresponding IP
address.
Defines an access IP address.
Defines the subnet mask length of the corresponding IP
address.
Defines an access IP address.
Defines the subnet mask length of the corresponding IP
address.
Enables/disables the access list by setting it to 1 (yes) or 0
(no).
228
Rev. 2
CD/CIM550.IOM
