CiM-550 IP Enabled Satellite Modem
Web Server Pages
12.3.6.2 R
OUTES
Field
Name
IP Address/Mask
Next Hop IP Address
Sort By
C
ONFIGURATION

Table 12-4. Routes Configuration Fields

Description
Enter the name of the route to add or delete. The route name is
case sensative however leading and trailing white space is
automatically removed.
Enter the destination IP address and mask. The mask and the IP
address must be valid.
The Next Hop Address is used for WAN routing of traffic from CiM
to CiM.
The route table may be sorted by route name or IP address.
188
Rev. 2
CD/CIM550.IOM
