CiM-550 IP Enabled Satellite Modem
CLI and Telnet Interface
11.2.5.3 AUPC M
The AUPC Modem Configuration page is activated from the Modem Parameters page.
The AUPC Modem Configuration page contains the following options/fields:
Menu Options/Fields
Framing
AUPC
Target EbNo of Remote
Demod(db)
Tx Max Increase (dB)
Max Power Reached Action
Remote Demod Unlock
Action
Save Parameters
Exit
C
ODEM ONFIGURATION
Entry
F
A
E
D
M
U
S
X
P
AGE
Description
1 - Disabled
2 - Enabled
1 - OFF
2 - ON
Valid ranges are from 0.1 to16.0 dB
Valid ranges are from 0 to 9 dB.
1 - No_Action
2 - Generate_TX_Alarm
1 - Nominal_Power
2 - Maximum_Power
This option allows a user to save the current
configuration of the CiM to permanent storage. This
configuration will be restored on each successive
power cycle of the CiM.
This option allows a user to exit the current menu and
return to its parent menu.
153
Rev. 2
CD/CIM550.IOM
