CiM-550 IP Enabled Satellite Modem
Front Panel Menus
4.1.5.2.1 SELECT\CONFIG
CONFIG:
INTFC REMCONT MASK IMPED
SELECT\CONFIG\TX
Allows the user to define, on a parameter-by-parameter basis, the transmit configuration
of the unit. These menu sub-branches would be used if the user wished to change, for
example, just the Transmit frequency.
TX: MOD
ON/OFF PWR SCRAM CLK TSI
SELECT\CONFIG\TX\MODULATION
SELECT\CONFIG\TX\FREQUENCY
DISPLAY
ALL TX RX FRAME
DISPLAY
FREQ DATA FEC
DISPLAY
SELECT TX MODULATION:
BPSK QPSK OQPSK (ENTER)
DISPLAY
EDIT TX FREQUENCY:
72.2345 MHz (PRESS ENT
SELECTIONS/DESCRIPTION
ALL
TX
RX
The ALL menu sub-branch permits the user to
completely configure the unit, being prompted, step
by step, to make choices, or edit data. This is highly
recommended for new users, as it will clearly
demonstrate all the parameters which need to be
set.
SELECTIONS/DESCRIPTION
SELECTIONS/DESCRIPTION
Note: If a TURBO FEC option is
selected, the modulation type will
be automatically fixed, and the
user will be presented with a
warning screen.
SELECTIONS/DESCRIPTION
Select the digit to be edited. Change the
value of the digit using the UP/DOWN
arrow keys, then press ENTER.
The range of frequencies is from 52 – 88
MHz (70 MHz factory option) or 104 – 176
MHz (140 MHz factory option).
