CiM-550 IP Enabled Satellite Modem
SNMP interface
13.4.2.5 R
EDUNDANCY
OID
cimCurrentRedundantState
cimLocalUnitManagementIpAddress
cimRedundantUnitManagementIpAddress
cimRedundantTrafficIpAddress
cimRedundantTrafficSubnetMaskLen
cimForceUnitOffline
13.4.2.6 O
PERATION AND
OID
cimAppVersion
cimSaveConfiguration
cimReset
G
ROUP

Table 13-31. Redundancy OIDs

M
AINTENANCE

Table 13-32. Operation and Maintenance Subgoup OIDs

Description
Displays the CiM Software's name, version, and date.
Allows a user to save the current configuration of the CiM-
550 to permanent storage.
Allows a user to reboot the modem. It has the same logical
effect of power-cycling the unit.
Description
Displays if the modem is Online and Offline.
The Online modem is the one that will
process traffic. The Offline modem monitors
the health of the online unit and will take
over if it detects a failure.
IP Address for the Ethernet Interface for the
Local Unit.
IP Address for the Ethernet Interface of the
Remote Unit.
Traffic IP address will always be active on
the Online Modem. When a fault occurs the
traffic IP address will float between the two
redundant modems.
This is the length of the traffic IP address
and can float between the two redundant
modems depending on if a failure occurs.
Forces a redundant switchover so that if the
modem is online it will transition to offline
and stop processing traffic. If the modem is
already offline, then this command will be
ignored.
G
ROUP
242
Rev. 2
CD/CIM550.IOM
