CiM-550 IP Enabled Satellite Modem
SNMP interface
13.5.1.8 L
OGS
OID
cim550ClearEventsLog
cim550NumberUnreadEvents
cim550RetrieveNext5Events
cim550SetStatisticInterval
cim550ClearStatisticsLog
cim550NumberUnreadStatistics
Table 13-43. Logs OIDs
Description
Instructs the unit to clear all Stored Events. A value of
1 (yes) is used to clear the event log.
Returns the number of Stored Events which remain
unread. The value can be between 0 and 99.
Unit returns the oldest 5 Stored Events which have not
yet been read over the remote control. Reply format:
{CR}Subbody{CR}Sub-body{CR}Sub-body{CR}Sub-
body{CR}Subbody,
where Sub-body= ABCddmmyyhhmmss,
A being the fault/clear indicator: F=Fault, C=Clear,
I=Info.
B being the fault type where: 1=Unit, 2=Rx, Traffic,
3=Tx Traffic, 4=Power on/off, or log cleared.
C being the fault code, where the Info codes are:
0=power off, 1=power on, 2=log cleared, 3=global
config change, and 4=redundancy config change.
ddmmyyhhmmss = date/time stamp.
If there are less than 5 events to be retrieved, the
remaining positions are padded with zeros.
Used to set the sample interval for the Statistics
Logging Function. Can be set to:
0
1
2
3
4
5
6
7
8
9
Instructs the unit to clear all Stored Statistics. Can be
set to 1 (yes) to clear the log.
Returns the number of Stored Statistics which remain
unread. Can be between 0 and 250.
255
CD/CIM550.IOM
None
10 Mins
20 Mins
30 Mins
40 Mins
50 Mins
60 Mins
70 Mins
80 Mins
90 Mins
Rev. 2
