CiM-550 IP Enabled Satellite Modem
Web Server Pages
12.3.6.4 A
DDRESS
Field
IP Address
Link Layer Address
Type
Sort By
R P
ESOLUTION ROTOCOL

Table 12-6. ARP Table Fields

Description
Enter a valid ARP table IP address to add or delete.
Enter a valid Link Layer Address which may be a device MAC
address or HDLC address. The field requires hexidecimal input.
For IEEE48 addresses, enter the value in the format of
"xx:xx:xx:xx:xx:xx", for HDLC, enter the value in the format of
"xxxx".
Set to indicate the type of Link Layer Address entered such as
IEEE48 or HDLC.
The ARP table may be sorted by IP addresses or Link Layer 2
addresses.
(ARP) C
ACHE
190
Rev. 2
CD/CIM550.IOM
