Download this manual See also: Operator's Manual
CiM-550
IP-Enabled Satellite Modem
Installation and Operation Manual
Part Number CD/CIM550.IOM
Rev. 2
December 3, 2002

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CIM-550 and is the answer not in the manual?

Questions and answers

Related Manuals for Comtech EF Data CIM-550

Summary of Contents for Comtech EF Data CIM-550

  • Page 1 CiM-550 IP-Enabled Satellite Modem Installation and Operation Manual Part Number CD/CIM550.IOM Rev. 2 December 3, 2002...
  • Page 3 Comtech EFData Documentation Update Subject: Changes to Chapter 5 Serial Remote Control Date: December 16, 2002 Document: CiM-550 Satellite Modem Installation and Operation Manual, Rev. 2, dated December 16, 2002 Part Number: CD/CiM550.EA2 Collating Instructions: Attach this page to page 5-9 Comments: The following changes provide updated information TX Carrier On/Off State.
  • Page 4 Comtech EF Data Documentation Update Subject: Addition to Chapter 4, Front Panel Menus Date: January 15, 2003 Document: CiM-550 IP Enabled Satellite Modem Installation and Operation Manual, Rev. 2, dated December 16, 2002 Part Number: CD/CiM550.EB2 Collating Instructions: Attach this page to page 47 Comments: The following changes provide additional information for Front Panel Menus.
  • Page 5 Installation and Operation Manual Registered Company. Part Number CD/CIM550.IOM REV. 2 December 3, 2002 Copyright © Comtech EF Data, 2002. All rights reserved. Printed in the USA. Comtech EF Data, 2114 West 7th Street, Tempe, Arizona 85281 USA, (480) 333-2200, FAX: (480) 333-2161...
  • Page 6 3. To ensure that the product is not damaged during shipping, pack the product in its original shipping carton/packaging. 4. Ship the product back to Comtech EF Data. (Shipping charges should be prepaid.) For more information regarding the warranty policies, see Warranty Policy, p. xx.

  • Page 7: Table Of Contents

    Table of Contents FIGURES ........................XV TABLES........................XVI CHAPTER 1. INTRODUCTION..................1 1.1 Introduction..........................1 1.2 Major Assemblies........................2 1.3 Standard Features........................2 1.3.1 AUPC..........................2 1.3.2 Software ..........................3 1.3.3 Verification ........................3 1.3.4 Data Interfaces ........................3 1.3.5 CDM-550 Emulation Mode ....................3 1.4 Options .............................
  • Page 8 CiM-550 IP Enabled Satellite Modem Rev. 2 Preface CD/CIM550.IOMCD/CIM550.IOM 2.3 Configuration ........................14 2.4 Select Internal IF Loop......................14 2.5 Connect External Cables...................... 14 2.6 Connector Description......................14 CHAPTER 3. OPERATION..................17 3.1 Methods of Operation......................17 3.1.1 Front Panel Operation ...................... 18 3.1.2 Serial Remote Control Operations ...................
  • Page 9 CiM-550 IP Enabled Satellite Modem Rev. 2 Preface CD/CIM550.IOMCD/CIM550.IOM 5.5.4 Instruction Code Qualifier ....................58 5.5.5 Message Arguments......................60 5.5.6 End Of Packet ........................60 CHAPTER 6. THEORY OF OPERATION ..............81 6.1 Functional Description ......................81 6.2 Offset QPSK Operation......................82 6.3 EIA-232 Operation........................
  • Page 10 CiM-550 IP Enabled Satellite Modem Rev. 2 Preface CD/CIM550.IOMCD/CIM550.IOM CHAPTER 10. CONNECTOR PINOUTS ..............111 10.1 Data Connector - 25 Pin ‘D’ Type Female..............111 10.2 Alarms Connector - 15 Pin ‘D’ Type Male..............112 10.3 Remote Control Connector - 9 Pin ‘D’ Type Male ............113 10.4 Auxiliary Serial Connector –...
  • Page 11 CiM-550 IP Enabled Satellite Modem Rev. 2 Preface CD/CIM550.IOMCD/CIM550.IOM 13.1 SNMP Interface......................... 211 13.2 MIB-II ..........................211 13.2.1 System Group....................... 212 13.2.2 Interface Group ......................214 13.2.3 ICMP Group......................... 221 13.2.4 TCP Group ........................222 13.2.5 UDP Group ........................223 13.2.6 EGP Group........................
  • Page 12 CiM-550 IP Enabled Satellite Modem Rev. 2 Preface CD/CIM550.IOMCD/CIM550.IOM 13.7.23 cimDatagramCompressionOption................278 13.7.24 cimNaptOption......................279 13.7.25 cimQosOption ......................279 13.7.26 cimTcpAccelerationOption..................280 13.7.27 cimTransparentBridgeOption ..................280 13.7.28 cimEncryptionOption....................281 13.7.29 cimIgmpOption ......................281 13.7.30 cimHeaderCompressionOption.................. 282 13.7.31 cimFeaturesConfig..................... 282 13.7.32 cimMidasFeature......................282 13.7.33 cimTelnetFeature .......................
  • Page 13 CiM-550 IP Enabled Satellite Modem Rev. 2 Preface CD/CIM550.IOMCD/CIM550.IOM 13.7.68 cimSatelliteInterface ....................300 13.7.69 cimSatelliteIpAddress ....................300 13.7.70 cimSatelliteSubnetPrefixLen ..................301 13.7.71 cimSatelliteReceiveEnable ..................301 13.7.72 cimSatelliteTransmitEnable..................302 13.7.73 cimSatelliteHdlcAddress1..................302 13.7.74 cimSatelliteHdlcAddress2..................303 13.7.75 cimSatelliteHdlcAddress3..................303 13.7.76 cimSatelliteHdlcAddress4..................304 13.7.77 cimRouteTable......................
  • Page 14 CiM-550 IP Enabled Satellite Modem Rev. 2 Preface CD/CIM550.IOMCD/CIM550.IOM 13.7.113 cimArpTable ......................323 13.7.114 cimArpEntry ......................324 13.7.115 cimArpIndex ......................324 13.7.116 cimArpIpAddress..................... 325 13.7.117 cimArpPhysAddress ....................325 13.7.118 cimArpPhysType ..................... 326 13.7.119 cimArpRowStatus ....................327 13.7.120 cimRedundancy......................328 13.7.121 cimCurrentRedundantState ..................328 13.7.122 cimLocalUnitManagementIpAddress ..............
  • Page 15 13.7.170 cimDroppedPacketsMiscellaneous ................352 13.7.171 cimDroppedPacketsQos................... 353 13.7.172 cimDroppedPacketsQosBuffers................353 13.7.173 cimDroppedPacketsDroppedBuffers ............... 354 13.7.174 cimResetCounters ....................354 13.8 CiM-550 MIB Tree ......................355 13.9 CiM-550 MIB ........................359 13.9.1 cim550.......................... 359 13.9.2 cim550Objects ......................359 13.9.3 cim550SystemInfo ....................... 359 13.9.4 cim550EquipmentID....................
  • Page 16 CiM-550 IP Enabled Satellite Modem Rev. 2 Preface CD/CIM550.IOMCD/CIM550.IOM 13.9.26 cim550RxFECType ....................372 13.9.27 cim550RxFECCodeRate.................... 373 13.9.28 cim550RxSpecInv...................... 373 13.9.29 cim550RxDescrambler ....................374 13.9.30 cim550RxClockMode ....................374 13.9.31 cim550RxBufferSize....................375 13.9.32 cim550RxAcqSweepRange ..................375 13.9.33 cim550RxEbnoAlarmPoint..................376 13.9.34 cim550InterfaceParameters..................376 13.9.35 cim550IfImpedance ....................
  • Page 17 CiM-550 IP Enabled Satellite Modem Rev. 2 Preface CD/CIM550.IOMCD/CIM550.IOM 13.9.71 cim550NotificationsPrefix..................394 13.9.72 cim550ModemUnitFaultsNotification............... 395 13.9.73 cim550ModemTxTrafficFaultsNotification .............. 395 13.9.74 cim550ModemRxTrafficFaultsNotification .............. 395 13.9.75 oduObjects ......................... 396 13.9.76 oduSelect........................396 13.9.77 oduSystemInfo ......................396 13.9.78 oduModelNumberSoftwareVer.................. 397 13.9.79 oduUnitSerialNumber ....................397 13.9.80 oduDeviceTime......................
  • Page 18 14.2.6 Restoring factory Default Configuration ..............422 14.2.7 CiM 1 Configuration....................422 14.2.8 CiM 2 Configuration....................424 14.2.9 Verification ........................424 14.3 Troubleshooting IP Module ..................... 425 APPLICATION NOTE - FLASH UPGRADING THE CIM-550 SATELLITE MODEMS ............................ 427 INDEX ......................... 431 METRIC CONVERSIONS ................... 433...

  • Page 19: Figures

    Figure 7-2. Sequential Decoding 64 kbps................... 99 Figure 7-3. Sequential Decoding 1024 kbps................100 Figure 7-4. Sequential Decoding 2048 kbps................101 Figure 7-5. Comtech EF Data Turbo Product Codec..............102 Figure 7-6. Differential Encoding No FEC................103 Figure 10-1. Rear Panel ......................111 Figure 11-1.
  • Page 20 Table 10-4. Auxiliary Serial Connector - He1402 3 Pin Header..........113 Table 10-5. Async-Serial Console RJ11-6................. 114 Table 10-6. Ethernet Interface RJ45-8..................114 Table 12-1. CiM-550 Web Server Menu Tree................176 Table 12-2. Admin Fields ......................182 Table 12-3. Interface Configuration Fields................185 Table 12-4.
  • Page 21 CiM-550 IP Enabled Satellite Modem Rev. 2 Preface CD/CIM550.IOMCD/CIM550.IOM Table 13-24. Ethernet Interface Subgroup OIDs ............... 235 Table 13-25. Satellite Ijnterface Subgroup OIDs ..............236 Table 13-26. Route Table Group OIDs..................237 Table 13-27. Route Table OIDs....................237 Table 13-28. IGMP Configuration Subgroup OIDs ..............239 Table 13-29.
  • Page 22 ANUAL This manual provides installation and operation information for the Comtech EF Data Cim-550 IP Enabled Satellite Modem. This is a technical document intended for earth station engineers, technicians, and operators responsible for the operation and maintenance of the Cim-550 IP Enabled Satellite Modem.
  • Page 23 UGGESTIONS ONCERNING THIS ANUAL Comments and suggestions regarding the content and design of this manual will be appreciated. To submit comments, please contact the Comtech EF Data Customer Support Department. EMC C OMPLIANCE This is a Class A product. In a domestic environment, it may cause radio interference that requires the user to take adequate protection measures.
  • Page 24 For equipment under warranty, the customer is responsible for freight to Comtech EF Data and all related custom, taxes, tariffs, insurance, etc. Comtech EF Data is responsible for the freight charges only for return of the equipment from the factory to the customer.
  • Page 25 ISCLAIMER Comtech EF Data has reviewed this manual thoroughly in order that it will be an easy-to- use guide to your equipment. All statements, technical information, and recommendations in this manual and in any guides or related documents are believed...
  • Page 26 CiM-550 IP Enabled Satellite Modem Rev. 2 Preface CD/CIM550.IOMCD/CIM550.IOM NOTES: xxii...

  • Page 27: Chapter 1. Introduction

    1.1 I NTRODUCTION The CiM-550 is a high-performance, low-cost, IP-enabled satellite modem designed for closed network Single Channel Per Carrier (SCPC) links. It is ideal for many VSAT applications. Offering a range of data rates from 2.4 to 2048 kbps in 1 bit per second steps, the modem includes Viterbi forward error correction as standard.

  • Page 28: Major Assemblies

    CDM-550 Emulation Mode 1.3.1 AUPC An important innovation in the CiM-550 is the addition of Automatic Uplink Power Control (AUPC). This feature enables the modem to automatically adjust its output power to maintain the Eb/No of the remote end of the satellite link constant. This provides protection against rain fading, a particularly severe problem with Ku-band links.

  • Page 29: Software

    1.3.5 CDM-550 E MULATION The CiM-550 can be made to operate in CDM-550 emulation mode, where it behaves exactly like the Comtech EF Data CDM-550 satellite modem. The emulation mode is selected from the front panel by selecting Configuration/Interface and then selecting either EIA-422/530, V.35, or EIA-232 as the interface rather than IP.

  • Page 30: Options

    1.4 O PTIONS Enhancing the CiM-550’s performance is easy. Additional features can be added quickly on site, using the FAST access code purchased from Comtech EF Data. To enable these features, simply enter the code at the front panel. Description...

  • Page 31: Ip Datagram Compression

    UALITY OF ERVICE Quality of Service (QoS) is an optional feature of the CiM-550. A QoS can be assigned to each route. It dictates the guaranteed minimum and allowable maximum data rate for that route. The CiM-550 classifies the incoming traffic based on the destination address and allocates bandwidth based on the configured profile.

  • Page 32: Specifications

    CiM-550 IP Enabled Satellite Modem Rev. 2 Introduction CD/CIM550.IOM 1.5 S PECIFICATIONS SYSTEM SPECIFICATIONS (FULLY ENHANCED) Frequency Range 52 to 88 MHz, 104 to 176 MHz (option), stability ± 1.5 ppm, 0 to 50 Input/Output Impedance 50 and 75 Ohms (Front panel selectable), 17 dB min. return loss...

  • Page 33: Figure 3-1. Front Panel

    CiM-550 IP Enabled Satellite Modem Rev. 2 Introduction CD/CIM550.IOM None: Uncoded BPSK/QPSK/OQPSK Viterbi: k=7, per IESS 308/309 BPSK: Rate 1/2 QPSK/OQPSK: Rate 1/2, Rate 3/4 and Rate 7/8 Sequential: k=36 (Rate 1/2) per IESS 309 k= 63 (Rate 3/4) per IESS 309...
  • Page 34 CiM-550 IP Enabled Satellite Modem Rev. 2 Introduction CD/CIM550.IOM Hyper Text Transfer Protocol (HTTP) File transfer protocol (FTP) OPERATIONS & MAINTENANCE Configuration & Management Console interface SNMP v2 Private Modem Specific MIB SNMP MIB II support Telnet HTTP Remote software / firmware upgrade...
  • Page 35 CiM-550 IP Enabled Satellite Modem Rev. 2 Introduction CD/CIM550.IOM At 512 kbps, R1/2 QPSK, ± 30 kHz sweep, Example: acquisition time = 0.25 seconds, average Clock tracking range ± 100 ppm min. BER PERFORMANCE (Met with two adjacent carriers 7 dB higher)

  • Page 36: Figure 1-1. Typical Coarse Agc Voltage Characteristic

    CiM-550 IP Enabled Satellite Modem Rev. 2 Introduction CD/CIM550.IOM Figure 1-1. Typical Coarse AGC Voltage Characteristic...

  • Page 37: Dimensional Envelope

    CiM-550 IP Enabled Satellite Modem Rev. 2 Introduction CD/CIM550.IOM 1.6 D IMENSIONAL NVELOPE Figure 1-2. Cim-550 Dimensional Envelope...
  • Page 38 CiM-550 IP Enabled Satellite Modem Rev. 2 Introduction CD/CIM550.IOM NOTES:...

  • Page 39: Chapter 2. Installation

    2.2 M OUNTING If the CiM-550 is to be mounted in a rack, ensure that there is adequate clearance for ventilation. The CiM-550 does not include a cooling fan, so care must be taken that too many units are not mounted on top of each other. The limit is four units, and then a blank 1U panel must be inserted to allow sufficient airflow around the units.

  • Page 40: Configuration

    Installation CD/CIM550.IOM The CiM-550 is very light - under 7 lbs (3.2 kgs), and very short - 12 ins (305 mm). For this reason, it has not been designed to have rack slides mounted to the side of the chassis. However, Comtech EF Data recommends that some method of support within the rack should be employed, such as rack shelves.
  • Page 41 IF Ports - The IF port connectors are both a 50 ohm BNC female type. 75 ohm cable connectors (male) will have no problem mating with this 50 ohm type. Data - The primary Data connector for the CiM-550 is the RJ-45 connector providing the 10/100 BaseT Ethernet interface.
  • Page 42 CiM-550 IP Enabled Satellite Modem Rev. 2 Installation CD/CIM550.IOM Auxiliary Serial Port - The Auxiliary Serial connector is an HE1402 3 pin header. A suitable mate for this connector is AMP part number 281838-3, with three crimp pins, AMP part number 182734-2, also required. This is an additional EIA-232 serial port, which is only used when the modem is part of a 1:1 pair.

  • Page 43: Chapter 3. Operation

    SNMP Operations Serial Remote Control Operations Serial Command Line Interface (CLI) Operations 3.1 M ETHODS OF PERATION The CiM-550 IP Enabled Modem may be setup and operated using any of the following methods: User Interface Connection Modem CiM Functions Reference...

  • Page 44: Front Panel Operation

    PERATIONS The CiM-550 modem provides a standard serial (EIA-232, EIA-485 4-wire, or EIA-485 2-wire) interface that can be used only for monitor and control of CiM-550 modem parameters (Monitor and Control of the CiM-550 IP parameters is provided separately via the Console Port interface).

  • Page 45: Web Server Operation

    The CiM-550 modem provides an embedded web server application that serves standard HTML web pages that can be used to monitor and control all CiM-550 modem and IP parameters. These web pages have been designed for optimal performance when using MicroSoft’s Internet Explorer version 5 or higher.

  • Page 46: Cim-550 Ip Enabled Satellite Modem Rev

    CiM-550 IP Enabled Satellite Modem Rev. 2 Operation CD/CIM550.IOM NOTES:...

  • Page 47: Chapter 4. Front Panel Menus

    ANEL PERATION The user can fully control and monitor the operation of the CiM-550 modem from the front panel, using the keypad and display. Nested menus are used, which display all available options, and prompt the user to carry out a required action.

  • Page 48: Vacuum Fluorescent Display (Vfd)

    CiM-550 IP Enabled Satellite Modem Rev. 2 Front Panel Menus CD/CIM550.IOM Function RIGHT ARROW Moves the cursor to the right, when it is displayed. LEFT ARROW Moves the cursor to the left, when it is displayed. UP ARROW Used for editing the value at the current cursor position, if appropriate.

  • Page 49: Led Indicators

    A Test Mode is selected (Example: IF Loopback) There is no Test Mode currently selected 4.1.4 M The following figures show the menu structure of the CiM-550 front panel menu. The detailed screens and menus are described in subsequent paragraphs.

  • Page 50: Figure 4-1. Front Panel Modem Menu Tree (1 Of 3)

    CiM-550 IP Enabled Satellite Modem Rev. 2 Front Panel Menus CD/CIM550.IOM CIM-550 Front Panel Menu Tree 1 of 3 PRESS ANY KEY COMTECH CIM-550 MODEM SELECT: CONFIG TEST INFO SN 700000007 1.22 MONIT STORE/LD UTIL ODU CONFIGURE TAKES USER THROUGH...

  • Page 51: Figure 4-2. Front Panel Modem Menu Tree (2 Of 3)

    CiM-550 IP Enabled Satellite Modem Rev. 2 Front Panel Menus CD/CIM550.IOM CIM-550 Front Panel Menu Tree 2 of 3 PRESS ANY KEY COMTECH CIM-550 MODEM SELECT: CONFIG TEST INFO SN 700000007 1.22 MONIT STORE/LD UTIL ODU INFO BUFF MASK EDMAC 70.

  • Page 52: Figure 4-3. Front Panel Modem Menu Tree (3 Of 3)

    CiM-550 IP Enabled Satellite Modem Rev. 2 Front Panel Menus CD/CIM550.IOM CIM-550 Front Panel Menu Tree 3 of 3 PRESS ANY KEY COMTECH CIM-550 MODEM SELECT: CONFIG TEST INFO SN 700000007 1.22 MONIT STORE/LD UTIL ODU STORE/LD STORE STORE STORE CONFIGURATION TO...

  • Page 53: Menu Screens

    CiM-550 IP Enabled Satellite Modem Rev. 2 Front Panel Menus CD/CIM550.IOM 4.1.5 M CREENS 4.1.5.1 O PENING CREEN DISPLAY SELECTIONS/DESCRIPTION This is an example of the Opening Screen. Refer to CDM-550 Manual for correct version information. COMTECH CiM-550 MODEM This screen is displayed whenever power is first S/N 1209 S/W VER 1.22...
  • Page 54 CiM-550 IP Enabled Satellite Modem Rev. 2 Front Panel Menus CD/CIM550.IOM 4.1.5.2.1 SELECT\CONFIG DISPLAY SELECTIONS/DESCRIPTION CONFIG: ALL TX RX FRAME INTFC REMCONT MASK IMPED The ALL menu sub-branch permits the user to completely configure the unit, being prompted, step by step, to make choices, or edit data. This is highly...
  • Page 55 CiM-550 IP Enabled Satellite Modem Rev. 2 Front Panel Menus CD/CIM550.IOM SELECT\CONFIG\TX\DATA RATE DISPLAY SELECTIONS/DESCRIPTION Select the digit to be edited. Change the value of the digit using the UP/DOWN EDIT TX DATA RATE: arrow keys, then press ENTER. 2048.000 kbps(PRESS ENT) The overall range of data rates is from 2.4...
  • Page 56 CiM-550 IP Enabled Satellite Modem Rev. 2 Front Panel Menus CD/CIM550.IOM SELECT\CONFIG\TX\ON-OFF DISPLAY SELECTIONS/DESCRIPTION SELECT TX OUTPUT STATE: (ENTER) RTI* * NEW FEATURE RTI means RECEIVE/TRANSMIT INHIBIT. When selected, it will prevent the TX carrier from being transmitted, until the demodulator is locked.
  • Page 57 CiM-550 IP Enabled Satellite Modem Rev. 2 Front Panel Menus CD/CIM550.IOM SELECT\CONFIG\TX\PWR DISPLAY SELECTIONS/DESCRIPTION MANUAL OUTPUT POWER LEVEL MODE: AUPC MANUAL AUPC (ENTER) MANUAL display screen EDIT OUTPUT POWER LEVEL: Default value is 3.0 dB, and upper limit is 9.9 dB -20.0 dBm...
  • Page 58 SELECT TX CLOCKING MODE: INT EXT LOOP-TIMED (ENT) LOOP-TIMED INTERNAL - indicates that the CiM-550 will supply a clock to the DTE, which is derived from its internal high-stability source. EXTERNAL - indicates that the CiM-550 expects to receive a clock from the DTE, to which the unit can phase-lock its internal circuits.
  • Page 59 CiM-550 IP Enabled Satellite Modem Rev. 2 Front Panel Menus CD/CIM550.IOM SELECT\CONFIG\TX\TSI DISPLAY SELECTIONS/DESCRIPTION TSI - Transmit Spectral Interval SELECT TRANSMIT SPECTRAL INVERSION: OFF ON(ENTER) When in the ON position, and QPSK is selected, the transmit spectrum is inverted (which is the same as reversing the direction of phase rotation in the modulator).
  • Page 60 CiM-550 IP Enabled Satellite Modem Rev. 2 Front Panel Menus CD/CIM550.IOM SELECT\CONFIG\RX\DATA DISPLAY SELECTIONS/DESCRIPTION The range is 2.4 to 2048 kbps. EDIT RX DATA RATE: Note: The minimum and maximum data rates are dependent on modulation type and FEC 64.000 kbps (PRESS ENT) decoder rate.
  • Page 61 The output from the buffer will be derived from the local TRANSMIT clock. In this way, the receive data will be perfectly synchronous with this local clock. The CiM-550 can be operated with independent transmit receive and transmit data rates. Even in this configuration, where RX data rate <>...
  • Page 62 CiM-550 IP Enabled Satellite Modem Rev. 2 Front Panel Menus CD/CIM550.IOM SELECT\CONFIG\RX\BUF DISPLAY SELECTIONS/DESCRIPTION Edit the size, in bits of the Plesiochronous/Doppler Buffer. EDIT RX BUFFER SIZE: Values of +/- 256, 512, 1024, 2048 and 4096 bits +/-4096 BITS (PRESS ENT) are possible.
  • Page 63 CiM-550 IP Enabled Satellite Modem Rev. 2 Front Panel Menus CD/CIM550.IOM 4.1.5.2.3 SELECT\CONFIG\FRAME DISPLAY SELECTIONS/DESCRIPTION TRANSPARENT - No framing is selected. No overhead is added, and the unit will be compatible SELECT FRAMING MODE: with other manufacturer’s equipment, when TRANSPARENT FRAMED (ENT) operating in a ‘standard’...
  • Page 64 Note: Selecting either EIA-422/530, V.35, or EIA- 232 as the interface rather than IP will change the CiM-550 to CDM-550 emulation mode. The CiM-550 will then pass standard serial traffic, like a CDM-550, but will not pass IP traffic. The CiM can still be accessed via the ethernet port using Telnet, HTTP, or SNMP.
  • Page 65 CiM-550 IP Enabled Satellite Modem Rev. 2 Front Panel Menus CD/CIM550.IOM 4.1.5.2.5 SELECT\CONFIG\REMCONT DISPLAY SELECTIONS/DESCRIPTION LOCAL SELECT REMOTE CONTROL: REMOTE LOCAL REMOTE (PRESS ENT) If LOCAL is selected then remote control will be disabled. Remote monitoring is still possible. If REMOTE is selected AND If the unit has not been...
  • Page 66 CiM-550 IP Enabled Satellite Modem Rev. 2 Front Panel Menus CD/CIM550.IOM 4.1.5.2.6 SELECT\CONFIG\MASK DISPLAY SELECTIONS/DESCRIPTION ALARM MASK: Eb/No Eb/No RX-AIS BUF-SLIP TX-AIS RX-AIS BUF-SLIP TX-AIS SELECT\CONFIG\MASK\AGC DISPLAY SELECTIONS/DESCRIPTION ACTIVE - If the user selects ACTIVE, then a Receive Traffic fault will be generated whenever the...
  • Page 67 CiM-550 IP Enabled Satellite Modem Rev. 2 Front Panel Menus CD/CIM550.IOM SELECT\CONFIG\MASK\BUF-SLIP DISPLAY SELECTIONS/DESCRIPTION ACTIVE - If the user selects ACTIVE, then a Receive Traffic fault will be generated whenever the SEL BUF-SLIP ALARM MASK: receive circuitry senses that the buffer has either ACTIVE MASKED(PRESS ENT) underflowed, or overflowed.
  • Page 68 CiM-550 IP Enabled Satellite Modem Rev. 2 Front Panel Menus CD/CIM550.IOM (Transmit an alternating 1,0,1,0 pattern) This is a test mode which TX-1,0 forces the modulator to transmit a carrier modulated with an alternating 1,0,1,0 pattern, at the currently selected symbol rate. This causes two discrete spectral lines to appear, spaced at +/- half the symbol rate, about the carrier frequency.

  • Page 69: Figure 4-4. Loopback Modes

    CiM-550 IP Enabled Satellite Modem Rev. 2 Front Panel Menus CD/CIM550.IOM Figure 4-4. Loopback Modes...

  • Page 70: Select\Info

    CiM-550 IP Enabled Satellite Modem Rev. 2 Front Panel Menus CD/CIM550.IOM 4.1.6 SELECT\INFO DISPLAY SELECTIONS/DESCRIPTION INFO:ALL TX RX BUFF MASK EDMAC ID FW MISC FAST BUFF MASK EDMAC MISC FAST 4.1.6.1 SELECT\INFO\TX DISPLAY SELECTIONS/DESCRIPTION Tx:140.0000 2048.000 VIT Q R1/2 S LOP -20.0 ON I...
  • Page 71 CiM-550 IP Enabled Satellite Modem Rev. 2 Front Panel Menus CD/CIM550.IOM 4.1.6.2 SELECT\INFO\RX DISPLAY SELECTIONS/DESCRIPTION Rx: 70.0000 512.000 SEQ B R3/4 BUFF +/-23k I The information displayed here is as follows: Top line: Receive Frequency Receive Data Rate FEC Decoder type (VIT = Viterbi, SEQ = Sequential,...
  • Page 72 CiM-550 IP Enabled Satellite Modem Rev. 2 Front Panel Menus CD/CIM550.IOM 4.1.6.4 SELECT\INFO\MASK DISPLAY SELECTIONS/DESCRIPTION This shows, in the same format as the CONFIG, MASK sub menu, which alarms are currently ALARMS MASKED: masked. If an alarm is not masked, a blank is...

  • Page 73: Select\Monit

    CiM-550 IP Enabled Satellite Modem Rev. 2 Front Panel Menus CD/CIM550.IOM 4.1.6.8 SELECT\INFO\MISC DISPLAY SELECTIONS/DESCRIPTION This screen shows the following: MISC: NORMAL 50 OHMS Test mode 1:1 LINK=IDLE ONLINE IF impedance 1:1 link status - if the CRS-100 1:1 module is being used, this shows the status of the serial link between the two units.
  • Page 74 CiM-550 IP Enabled Satellite Modem Rev. 2 Front Panel Menus CD/CIM550.IOM 4.1.7.1.2 SELECT\MONIT\ALARMS\RECEIVE DISPLAY SELECTIONS/DESCRIPTION The screen will indicate if there are any Receive Traffic Faults. If not, it will display ‘NONE’. RX TRAFFIC: AGC ALARM REDUCE COMPOSITE I/P LVL 4.1.7.1.3 SELECT\MONIT\ALARMS\TRANSMIT...
  • Page 75 CiM-550 IP Enabled Satellite Modem Rev. 2 Front Panel Menus CD/CIM550.IOM 4.1.7.3 SELECT\MONIT\STORED-EVENTS DISPLAY SELECTIONS/DESCRIPTION VIEW STORED EVENTS: VIEW CLEAR ALL CLEAR ALL (PRESS ENTER) 4.1.7.3.1 SELECT\MONIT\EVENTS\VIEW DISPLAY SELECTIONS/DESCRIPTION The event log can store up to 100 events. LOG23: 30/11/97 10:37:32 When a fault condition occurs, it is time-stamped and put into the log.
  • Page 76 CiM-550 IP Enabled Satellite Modem Rev. 2 Front Panel Menus CD/CIM550.IOM 4.1.7.4 SELECT\MONIT\STATS DISPLAY SELECTIONS/DESCRIPTION VIEW LINK STATISTICS: VIEW CLEAR CLEAR CONFIGURE (ENTER) CONFIGURE 4.1.7.4.1 SELECT\MONIT\STATS\VIEW DISPLAY SELECTIONS/DESCRIPTION VIEW STA198:02/11/00 10:37:32 CLEAR ALL 16.0,16.0,9.0,9.0(UP/DN) The user may scroll backwards or forwards through the entries in the statistics log, using the UP/DOWN arrow keys.
  • Page 77 CiM-550 IP Enabled Satellite Modem Rev. 2 Front Panel Menus CD/CIM550.IOM Examples: 08.0,13.5,2.5,1.8 means: Minimum Eb/No observed in the measurement interval = 8.0 dB Average Eb/No observed in the measurement interval = 13.5 dB Maximum TPLI observed in the measurement interval = 2.5 dB Average TPLI observed in the measurement interval = 1.8 dB...

  • Page 78: Select\Store\Ld

    CiM-550 IP Enabled Satellite Modem Rev. 2 Front Panel Menus CD/CIM550.IOM 4.1.8 SELECT\STORE\LD DISPLAY SELECTIONS/DESCRIPTION STORE STORE/LOAD CONFIG: LOAD STORE LOAD (PRESS ENTER) These sub-menus permit the user to store or load up to 10 different modem configurations in the non- volatile memory of the modem 4.1.8.1 SELECT\STORE/LD\STORE...

  • Page 79: Select\Util

    CiM-550 IP Enabled Satellite Modem Rev. 2 Front Panel Menus CD/CIM550.IOM WARNING! LOC 10 CONTAINS NO DATA! (ENTER) 4.1.9 SELECT\UTIL DISPLAY SELECTIONS/DESCRIPTION SET-RTC UTILITY: SET-RTC DISPLAY MAN-1:1 RECENTER-BUF ID MAN-1:1 CENTER-BUF FAST 4.1.9.1 SELECT\UTIL\ \RTC DISPLAY SELECTIONS/DESCRIPTION Edit the time and date settings of the real-time clock.

  • Page 80: Select\Odu

    CiM-550 IP Enabled Satellite Modem Rev. 2 Front Panel Menus CD/CIM550.IOM 4.1.9.4 SELECT\UTIL\RECENTER-BUF DISPLAY SELECTIONS/DESCRIPTION Pressing ENTER will cause a forced re-centering of the Plesiochronous/Doppler buffer. PRESS ENTER TO RE-CENTER THE RECEIVE BUFFER 4.1.9.5 SELECT\UTIL\ID DISPLAY SELECTIONS/DESCRIPTION Only the bottom line is available (24 characters).

  • Page 81: Chapter 5. Serial Remote Control

    NTRODUCTION This section describes the protocol and message command set for remote monitor and control of the CiM-550 Modem. The electrical interface is either an EIA-485 multi-drop bus (for the control of many devices) or an EIA-232 connection (for the control of a single device), and data is transmitted in asynchronous serial form, using ASCII characters.

  • Page 82: Basic Protocol

    CiM-550 IP Enabled Satellite Modem Rev. 2 Serial Remote Control CD/CIM550.IOM EIA 485 (full duplex) summary: Two differential pairs - one pair for controller to target, one pair for target to controller. Controller-to-target pair has one line driver (controller), and all targets have line- receivers.

  • Page 83: Packet Structure

    CiM-550 IP Enabled Satellite Modem Rev. 2 Serial Remote Control CD/CIM550.IOM 5.5 P ACKET TRUCTURE Controller-to-target: Start of Target Address Instructio Code Optional End of Packet Address Qualifier Packet De-limiter Arguments Code < = or ? Carriage Return ASCII ASCII code...

  • Page 84: Instruction Code

    CiM-550 IP Enabled Satellite Modem Rev. 2 Serial Remote Control CD/CIM550.IOM 5.5.3 I NSTRUCTION This is a three-character alphabetic sequence which identifies the subject of the message. Wherever possible, the instruction codes have been chosen to have some significance. For example TFQ for transmit frequency, RMD for receive modulation type, etc. This aids in the readability of the message, should it be displayed in its raw ASCII form.
  • Page 85 CiM-550 IP Enabled Satellite Modem Rev. 2 Serial Remote Control CD/CIM550.IOM 2) From Target to Controller, the only permitted values are: = (ASCII code 61) ? (ASCII code 63) ! (ASCII code 33) * (ASCII code 42) They have these meanings: The ‘=’...

  • Page 86: Message Arguments

    CiM-550 IP Enabled Satellite Modem Rev. 2 Serial Remote Control CD/CIM550.IOM 5.5.5 M ESSAGE RGUMENTS Arguments are not required for all messages. Arguments are ASCII codes for the characters 0 to 9 (ASCII 48 to 57), period (ASCII 46) and comma (ASCII 44).
  • Page 87 CiM-550 IP Enabled Satellite Modem Rev. 2 Remote Control CD/CIM550.IOM Parameter Command Arguments for Description of arguments Response to Command Query Response to Command or (target to controller) query Type (Instruction (note that all arguments are ASCII numeric (Instruction Response to...
  • Page 88 CiM-550 IP Enabled Satellite Modem Rev. 2 Remote Control CD/CIM550.IOM Parameter Command Arguments for Description of arguments Response to Command Query Response to Command or (target to controller) query Type (Instruction (note that all arguments are ASCII numeric (Instruction Response to...
  • Page 89 CiM-550 IP Enabled Satellite Modem Rev. 2 Remote Control CD/CIM550.IOM Parameter Command Arguments for Description of arguments Response to Command Query Response to Command or (target to controller) query Type (Instruction (note that all arguments are ASCII numeric (Instruction Response to...
  • Page 90 CiM-550 IP Enabled Satellite Modem Rev. 2 Remote Control CD/CIM550.IOM Parameter Command Arguments for Description of arguments Response to Command Query Response to Command or (target to controller) query Type (Instruction (note that all arguments are ASCII numeric (Instruction Response to...
  • Page 91 CiM-550 IP Enabled Satellite Modem Rev. 2 Remote Control CD/CIM550.IOM Parameter Command Arguments for Description of arguments Response to Command Query Response to Command or (target to controller) query Type (Instruction (note that all arguments are ASCII numeric (Instruction Response to...
  • Page 92 CiM-550 IP Enabled Satellite Modem Rev. 2 Remote Control CD/CIM550.IOM Parameter Command Arguments for Description of arguments Response to Command Query Response to Command or (target to controller) query Type (Instruction (note that all arguments are ASCII numeric (Instruction Response to...
  • Page 93 CiM-550 IP Enabled Satellite Modem Rev. 2 Remote Control CD/CIM550.IOM Parameter Command Arguments for Description of arguments Response to Command Query Response to Command or (target to controller) query Type (Instruction (note that all arguments are ASCII numeric (Instruction Response to...
  • Page 94 CiM-550 IP Enabled Satellite Modem Rev. 2 Remote Control CD/CIM550.IOM Parameter Command Arguments for Description of arguments Response to Command Query Response to Command or (target to controller) query Type (Instruction (note that all arguments are ASCII numeric (Instruction Response to...
  • Page 95 CiM-550 IP Enabled Satellite Modem Rev. 2 Remote Control CD/CIM550.IOM Parameter Command Arguments for Description of arguments Response to Command Query Response to Command or (target to controller) query Type (Instruction (note that all arguments are ASCII numeric (Instruction Response to...
  • Page 96 CiM-550 IP Enabled Satellite Modem Rev. 2 Remote Control CD/CIM550.IOM Parameter Command Arguments for Description of arguments Response to Command Query Response to Command or (target to controller) query Type (Instruction (note that all arguments are ASCII numeric (Instruction Response to...
  • Page 97 CiM-550 IP Enabled Satellite Modem Rev. 2 Remote Control CD/CIM550.IOM Parameter Command Arguments for Description of arguments Response to Command Query Response to Command or (target to controller) query Type (Instruction (note that all arguments are ASCII numeric (Instruction Response to...
  • Page 98 CiM-550 IP Enabled Satellite Modem Rev. 2 Remote Control CD/CIM550.IOM Parameter Command Arguments for Description of arguments Response to Command Query Response to Command or (target to controller) query Type (Instruction (note that all arguments are ASCII numeric (Instruction Response to...
  • Page 99 CiM-550 IP Enabled Satellite Modem Rev. 2 Remote Control CD/CIM550.IOM Parameter Command Arguments for Description of arguments Response to Command Query Response to Command or (target to controller) query Type (Instruction (note that all arguments are ASCII numeric (Instruction Response to...
  • Page 100 CiM-550 IP Enabled Satellite Modem Rev. 2 Remote Control CD/CIM550.IOM Parameter Command Arguments for Description of arguments Response to Command Query Response to Command or (target to controller) query Type (Instruction (note that all arguments are ASCII numeric (Instruction Response to...
  • Page 101 CiM-550 IP Enabled Satellite Modem Rev. 2 Remote Control CD/CIM550.IOM Parameter Command Arguments for Description of arguments Response to Command Query Response to Command or (target to controller) query Type (Instruction (note that all arguments are ASCII numeric (Instruction Response to...
  • Page 102 CiM-550 IP Enabled Satellite Modem Rev. 2 Remote Control CD/CIM550.IOM Parameter Command Arguments for Description of arguments Response to Command Query Response to Command or (target to controller) query Type (Instruction (note that all arguments are ASCII numeric (Instruction Response to...
  • Page 103 CiM-550 IP Enabled Satellite Modem Rev. 2 Remote Control CD/CIM550.IOM Parameter Command Arguments for Description of arguments Response to Command Query Response to Command or (target to controller) query Type (Instruction (note that all arguments are ASCII numeric (Instruction Response to...
  • Page 104 Modem model number. Example: 2550 is CiM-550, no Reed-Solomon or Turbo 3550 is CiM-550 with Reed-Solomon Codec 4550 is CiM-550 with Turbo Codec fitted (Rate 3/4 QPSK only - S/W Version less than 1.15) 5550 is CiM-550 with Turbo Codec fitted (Rate 3/4...
  • Page 105 IF band, with 1 = 70MHz, 2 = 140MHz c defines RX only, with 1 = RX/TX, 2 = RX only. Example: EID=455011 (CiM-550, Rate 3/4 Turbo Codec, 70 MHz band, RX/TX) Faults 5 bytes, Query only. Unit returns the current fault and status...
  • Page 106 CiM-550 IP Enabled Satellite Modem Rev. 2 Remote Control CD/CIM550.IOM Parameter Command Arguments for Description of arguments Response to Command Query Response to Command or (target to controller) query Type (Instruction (note that all arguments are ASCII numeric (Instruction Response to...

  • Page 107: Chapter 6. Theory Of Operation

    UNCTIONAL ESCRIPTION The CiM-550 has two fundamentally different types of interface - IF and data. The data interface is a bi-directional path which connects with the customer’s equipment (assumed to be the DTE) and the modem (assumed to be the DCE). The IF interface provides a bi- directional link with the satellite via the uplink and downlink equipment.

  • Page 108: Offset Qpsk Operation

    CiM-550 IP Enabled Satellite Modem Rev. 2 Theory of Operation CD/CIM550.IOM After decoding, the recovered clock and data pass to the de-framer (if EDMAC is enabled) where the overhead information is removed. Following this, the data passes to the Plesiochronous/Doppler buffer, which has a programmable size, or may be bypassed.

  • Page 109: Async Eia-232 Specifications

    6.3 EIA-232 O PERATION The CiM-550 supports asynchronous EIA-232 in addition to synchronous EIA-232 formats. This is useful, for example, in connecting two computers together, via their serial ports, at opposite ends of a satellite link. There are, however, some restrictions and limitations when using this mode, and the user may have to experiment a little in order to get reliable communication.

  • Page 110: 6.3.3 Clocking

    ST, rather than a clock which may jitter and wander in a random fashion. 6.3.3.1.4 Loop-Timed, RX<>TX (Asymmetric Loop Timing) The CiM-550 incorporates circuitry which permits loop timing when the TX and RX data rates are not the same. In this case the clock frequency appearing at ST will be whatever the TX data rate is programmed to, but phase-locked to the demodulator’s receive symbol...

  • Page 111: Buffer Disabled

    6.3.3.2 R ECEIVE LOCKING There are three receive clocking modes in the CiM-550. 6.3.3.2.1 Buffer Disabled When the buffer is disabled, the receive clock (Receive Timing, or RT) is derived directly from the demodulator, and hence will be subject to plesiochronous and Doppler offsets.

  • Page 112: Transmit And Receive Clocking

    CiM-550 IP Enabled Satellite Modem Rev. 2 Theory of Operation CD/CIM550.IOM 6.3.4 T RANSMIT AND ECEIVE LOCKING INTERNAL TX CLOCK MODE DATA TO MODULATOR CIRCUIT TX DATA CLOCK FIFO CIRCUIT VCXO TX CLO CK TRANSMIT (TT ) DATA INTERFACE DIRECT 14.4 MHz...

  • Page 113: Figure 6-2. Rx Clock Modes

    CiM-550 IP Enabled Satellite Modem Rev. 2 Theory of Operation CD/CIM550.IOM BUFFER DISABLE CLOCK MODE RX DATA DATA FROM FEC DECODER/DEFRAMER BUFFER RX CLOCK RECEIVE (RT) DATA INTERFACE DIRECT CLOCK DIGITAL VCXO CIRCUIT RX SYMBOL SNTHESIZER CLOCK FROM DEMOD BUFFER ENABLE...

  • Page 114: Aupc (Automatic Uplink Power Control)

    CiM-550 IP Enabled Satellite Modem Rev. 2 Theory of Operation CD/CIM550.IOM 6.4 AUPC (A UTOMATIC PLINK OWER ONTROL Automatic Uplink Power Control (AUPC) is a feature whereby a local modem is permitted to adjust its own output power level in order to attempt to maintain the Eb/No at the remote modem.
  • Page 115 CiM-550 IP Enabled Satellite Modem Rev. 2 Theory of Operation CD/CIM550.IOM 6.4.1.1 T ARGET This is value of Eb/No that the user desires to keep constant at the remote modem. If the Eb/No exceeds this value, the AUPC control will reduce the TX output power, but will never drop below the nominal value set.

  • Page 116: Compensation Rate

    AUPC is disabled, this will indicate 0.0 dB. This value is also available via the remote control interface. Comtech EF Data strongly cautions against the use of large values of permitted power level increase under AUPC control. Users should consider using the absolute minimum...

  • Page 117: Chapter 7. Forward Error Correction Options

    Comtech EF Data has performed compatibility testing to ensure inter-operability. As an option, the CiM-550 may be fitted with two additional Forward Error Correction (FEC) devices. The first is a concatenated Reed-Solomon Codec. This is always used in conjunction with, rather than instead of, the main FEC method (Viterbi or Sequential).

  • Page 118: Sequential

    Eb/No). This is not true of the Sequential decoding method, as explained in the section below. Note that in BPSK mode, the CiM-550 only permits a coding rate of 1/2. Because the method of convolutional coding used with Viterbi, the encoder does not preserve the original data intact, and is called non-systematic.

  • Page 119: Turbo Product Codec (Option)

    BER. For delay-sensitive applications this may be unacceptable, and the implementation complexity of the TCC approach is high. For these reasons Comtech EF Data has chosen to implement an FEC codec based on TPC.
  • Page 120 In many cases, FEC methods which provide increased coding gain do so at the expense of increased processing delay. However, with TPC, this increase in delay is very modest. The table below shows, for the CiM-550, the processing delays for the major FEC types, including the three TPC modes:...
  • Page 121 CiM-550 IP Enabled Satellite Modem Rev. 2 Forward Error Correction CD/CIM550.IOM FEC Mode (64 kbps data rate) End-to-end delay, ms Viterbi, Rate 1/2 Sequential, Rate 1/2 Turbo Product Coding, Rate 3/4, QPSK Turbo Product Coding, Rate 21/44, BPSK Turbo Product Coding, Rate 5/16,...

  • Page 122: Uncoded Operation (Nofec)

    There are occasions where a user may wish to operate a satellite link with no forward error correction of any kind. For this reason, the CiM-550 offers this uncoded mode for all three modulation types - BPSK, QPSK and OQPSK. However, the user should be aware of some of the implications of using this approach.
  • Page 123 If uncoded operation is used, there is no way to recognize a data false lock. The demodulator will indicate that it is correctly locked, but the data out will not be correct. Comtech EF Data strongly cautions users when using uncoded operation. If the acquisition sweep width exceeds one quarter of...

  • Page 124: Figure 7-1. Viterbi Decoding

    CiM-550 IP Enabled Satellite Modem Rev. 2 Forward Error Correction CD/CIM550.IOM Eb/No in dB 1E-1 Uncoded BPSK/QPSK 1E-2 Viterbi Decoding Typical Performance 1E-3 1E-4 1E-5 1E-6 Specification limit, Rate 7/8 1E-7 Coding 1E-8 Specification Specification limit Rate 1/2 limit, Rate 3/4...

  • Page 125: Figure 7-2. Sequential Decoding 64 Kbps

    CiM-550 IP Enabled Satellite Modem Rev. 2 Forward Error Correction CD/CIM550.IOM Eb/No in dB 1E-1 Uncoded BPSK/QPSK Sequential 1E-2 Decoding 64 kbps Typical 1E-3 Performance 1E-4 1E-5 1E-6 Specification 1E-7 limit, Rate 7/8 Coding 1E-8 Specification Specification limit Rate 1/2...

  • Page 126: Figure 7-3. Sequential Decoding 1024 Kbps

    CiM-550 IP Enabled Satellite Modem Rev. 2 Forward Error Correction CD/CIM550.IOM Eb/No in dB 1E-1 Uncoded BPSK/QPSK Sequential 1E-2 Decoding 1024 kbps 1E-3 Typical Performance 1E-4 1E-5 1E-6 Specification 1E-7 limit, Rate 7/8 Coding 1E-8 Specification limit Rate 1/2 Specification...

  • Page 127: Figure 7-4. Sequential Decoding 2048 Kbps

    CiM-550 IP Enabled Satellite Modem Rev. 2 Forward Error Correction CD/CIM550.IOM Eb/No in dB 1E-1 Uncoded BPSK/QPSK Sequential 1E-2 Decoding 2048 kbps 1E-3 1E-4 1E-5 1E-6 Typical performance, Rate 7/8 Coding 1E-7 1E-8 Typical Typical performance, performance, Rate 3/4 Rate 1/2...

  • Page 128: Figure 7-5. Comtech Ef Data Turbo Product Codec

    Rate 5/16 BPSK 21/44 BPSK Specification limit - Rate 1E-3 3/4 QPSK Specification limit - Rate 5/16 BPSK 1E-4 1E-5 1E-6 1E-7 Typical performance is approximately 0.3 dB better than shown 1E-8 1E-9 Figure 7-5. Comtech EF Data Turbo Product Codec...

  • Page 129: Figure 7-6. Differential Encoding No Fec

    CiM-550 IP Enabled Satellite Modem Rev. 2 Forward Error Correction CD/CIM550.IOM Eb/No in dB 1E-1 Differential Encoding - No FEC Uncoded BPSK/QPSK 1E-2 1E-3 1E-4 1E-5 1E-6 1E-7 1E-8 1E-9 Figure 7-6. Differential Encoding No FEC...

  • Page 130: Cim-550 Ip Enabled Satellite Modem Rev

    CiM-550 IP Enabled Satellite Modem Rev. 2 Forward Error Correction CD/CIM550.IOM NOTES:...

  • Page 131: Chapter 8. Edmac Channel

    Chapter 8. EDMAC CHANNEL Theory Of Operation M&C Connection Setup Summary 8.1 T HEORY PERATION As explained earlier, EDMAC is an acronym for Embedded Distant-end Monitor And Control. This is a feature which permits the user to access the M&C features of modems which are at the distant-end of a satellite link.

  • Page 132: On The Receive Side

    CiM-550 IP Enabled Satellite Modem Rev. 2 EDMAC CD/CIM550.IOM Adding the extra 5% to the transmitted data rate, the effective Eb/No seen by the user will degrade by a factor of 10log(1.05), or 0.21 dB (0.07dB in the case of the two BPSK Turbo rates).

  • Page 133: M&C Connection

    CiM-550 IP Enabled Satellite Modem Rev. 2 EDMAC CD/CIM550.IOM 8.2 M&C C ONNECTION Data to be transmitted to the distant-end is sent to a local unit via the remote control port. A message for the distant-end is indistinguishable from a ‘local’ message - it has the same structure and content, only the address will identify it as being for a distant-end unit.

  • Page 134: Setup Summary

    CiM-550 IP Enabled Satellite Modem Rev. 2 EDMAC CD/CIM550.IOM 8.3 S ETUP UMMARY To access a distant-end unit: Designate a Master/Slave pair - Master at the local-end, Slave at the distant-end. On the local-end unit, enable framing, and EDMAC, define the unit as MASTER, then enter the bus address of the SLAVE.

  • Page 135: Chapter 9. Eb/No Measurement

    Chapter 9. Eb/No Measurement 9.1 M EASURING Although the CiM-550 calculates and displays the value of receive Eb/No on the front panel of the unit, it is sometimes useful to measure the value using a spectrum analyzer, if one is available.
  • Page 136 CiM-550 IP Enabled Satellite Modem Rev. 2 Eb/No CD/CIM550.IOM Eb/No - Eb/No - Eb/No - Eb/No - Eb/No - Eb/No - (C+N)/N Uncoded Rate 1/2 Uncoded Rate 1/2 Rate 3/4 Rate 7/8 BPSK BPSK QPSK QPSK QPSK QPSK 10.3 10.8 11.4...

  • Page 137: Chapter 10. Connector Pinouts

    Chapter 10. Connector Pinouts Data Connector Alarms Connector Remote Control Connector Auxiliary Serial Connector Console Port COMTECH 25 Watts, 250 mA max RS 422 Remote Control B IP Interface 10/100 BaseT EF DATA CORP 115 Volt operation - T1A fuses (EIA 530) RS232 V.35...

  • Page 138: Alarms Connector - 15 Pin 'D' Type Male

    CiM-550 IP Enabled Satellite Modem Rev. 2 Connector Pinouts CD/CIM550.IOM Generic Signal Direction EIA-422/ V.35 EIA-232 Circuit Description EIA 530 Receive Clock A Modem to DTE RT A SCR A External Carrier Off DTE to Modem (EIA-232 ‘1' or TTL ‘low’ )

  • Page 139: Remote Control Connector - 9 Pin 'D' Type Male

    CiM-550 IP Enabled Satellite Modem Rev. 2 Connector Pinouts CD/CIM550.IOM 10.3 R - 9 P ‘D’ T EMOTE ONTROL ONNECTOR Table 10-3. Remote Control Connector - 9 Pin ‘D’ Type Male Description Ground EIA-232 Transmit Data (Out) EIA-232 Receive Data...

  • Page 140: Async-Serial Console

    CiM-550 IP Enabled Satellite Modem Rev. 2 Connector Pinouts CD/CIM550.IOM 10.5 A SYNC ERIAL ONSOLE The Console Connector is a RJ11-6 modular jack located on the rear panel. The Async- Serial Console interfaces the IP Telnet Configuration Port. This interface is a EIA-232 DCE interface.

  • Page 141: Chapter 11. Cli And Telnet Interface

    Chapter 11. CLI and Telnet Interface Overview Main Menu Page Administration Page SMTP SNMP Interface Configuration Page Receiver HDLC Addresses Page Route Table Configuration Page Protocol Configuration Page Modem Parameters Page Redundancy Configuration Page Operations and Maintenance Page 11.1 O VERVIEW This section defines the user menu system presented to a user connected to the CiM via a Terminal Emulator or telnet.

  • Page 142: Main Menu Page

    CiM-550 IP Enabled Satellite Modem Rev. 2 CLI and Telnet Interface CD/CIM550.IOM 11.2 M Menu pages are followed by a table listing the Menu Options/Fields, required Entry, and Descriptions. The Main Menu page has the following options/fields: Menu Options/Fields Entry...
  • Page 143 CiM-550 IP Enabled Satellite Modem Rev. 2 CLI and Telnet Interface CD/CIM550.IOM Menu Options/Fields Entry Description Save Parameters This option allows a user to save the current configuration of the CiM to permanent storage. This configuration will be restored on each successive power cycle of the CiM.

  • Page 144: Administration Page

    CiM-550 IP Enabled Satellite Modem Rev. 2 CLI and Telnet Interface CD/CIM550.IOM 11.2.1 A DMINISTRATION The Administration page is activated from the Main Menu page. Note: Access to the Administration page is restricted to the Admin user when connecting via the telnet interface.
  • Page 145 CiM-550 IP Enabled Satellite Modem Rev. 2 CLI and Telnet Interface CD/CIM550.IOM Menu Options/Fields Entry Description Exit This option allows a user to exit the current menu and return to its parent menu. 11.2.1.1 N ASSWORD ONFIGURATION The Name/Password Configuration page is activated from the Administration page.
  • Page 146 CiM-550 IP Enabled Satellite Modem Rev. 2 CLI and Telnet Interface CD/CIM550.IOM Menu Options/Fields Entry Description Save Parameters This option allows a user to save the current configuration of the CiM to permanent storage. This configuration will be restored on each successive power cycle of the CiM.
  • Page 147 CiM-550 IP Enabled Satellite Modem Rev. 2 CLI and Telnet Interface CD/CIM550.IOM 11.2.1.3 A CCESS ISTS The Access Lists page is activated from the Administration page. This page allows the operator to configure the CiM to limit monitor and control access to the unit from a specified list of authorized clients.
  • Page 148 If a feature is marked “Unavailable” and it has a letter, Transmit DES Encryption for example, then the feature is a FAST feature. FAST features must be purchased from Comtech EF Data. “Unavailable” features without a letter, Datagram Compression for example, will be available in a follow-on release.
  • Page 149 CiM-550 IP Enabled Satellite Modem Rev. 2 CLI and Telnet Interface CD/CIM550.IOM Menu Options/Fields Entry Description IGMP Toggles [Enabled] and [Disabled] This feature must be purchased. The receive portion of a CiM will utilize the CiM as an IGMP server. The transmit portion of a CiM will utilize the CiM as an IGMP client.
  • Page 150 CiM-550 IP Enabled Satellite Modem Rev. 2 CLI and Telnet Interface CD/CIM550.IOM Menu Options/Fields Entry Description TCP Acceleration Read Unavailable Only Header Compression Read Unavailable Only Unavailable Easy Connect Save Parameters This option allows a user to save the current configuration of the CiM to permanent storage.
  • Page 151 CiM-550 IP Enabled Satellite Modem Rev. 2 CLI and Telnet Interface CD/CIM550.IOM 11.2.1.5 DES E NCRYPT ONFIGURATION The DES Encrypt Configuration page is activated from the Administration page. Note: This menu will only be accessible if the DES FAST feature has been purchased and the license key has been entered through the modem front panel.
  • Page 152 CiM-550 IP Enabled Satellite Modem Rev. 2 CLI and Telnet Interface CD/CIM550.IOM Menu Options/Fields Entry Description The key is entered in HEX (16 digits max) Save Parameters This option allows a user to save the current configuration of the CiM to permanent storage. This configuration will be restored on each successive power cycle of the CiM.
  • Page 153 CiM-550 IP Enabled Satellite Modem Rev. 2 CLI and Telnet Interface CD/CIM550.IOM 11.2.1.6 SMTP The SMTP Configuration page is activated from the Administration page. The SMTP Configuration contains the following options/fields: Menu Options/Fields Entry Description SMTP Server IP Address Not Defined...
  • Page 154 CiM-550 IP Enabled Satellite Modem Rev. 2 CLI and Telnet Interface CD/CIM550.IOM 11.2.1.7 SNMP The SNMP Configuration page is activated from the Administration page. The SNMP Configuration contains the following options/fields: Menu Options/Fields Entry Description SNMP Admin Get/Set Read GET and SET community string for Admin user. This...
  • Page 155 CiM-550 IP Enabled Satellite Modem Rev. 2 CLI and Telnet Interface CD/CIM550.IOM Menu Options/Fields Entry Description SNMP Stats Displays statistics concerning the operation of the SNMP agent (number of IN SNMP packets, number of OUT SNMP packets, number of OUT Traps, etc…)

  • Page 156: Interface Configuration Page

    CiM-550 IP Enabled Satellite Modem Rev. 2 CLI and Telnet Interface CD/CIM550.IOM 11.2.2 I NTERFACE ONFIGURATION The Interface Configuration page is activated from the Main Menu page. The Interface Configuration page contains the following options/fields: Menu Options/Fields Entry Description Ethernet Interface (fei0) Activates Fast Ethernet page.
  • Page 157 CiM-550 IP Enabled Satellite Modem Rev. 2 CLI and Telnet Interface CD/CIM550.IOM 11.2.2.1 F 0) P THERNET NTERFACE The Fast Ethernet Interface page is activated from the Interface Configuration page. The Fast Ethernet Interface page contains the following options/fields: Menu Options/Fields...
  • Page 158 CiM-550 IP Enabled Satellite Modem Rev. 2 CLI and Telnet Interface CD/CIM550.IOM 11.2.2.2 S /HDLC I 1) P ATELLITE NTERFACE The Satellite/HDLC Interface (hdl1) page is activated from the Interface Configuration page. The Satellite/HDLC Interface page contains the following options/fields:...
  • Page 159 CiM-550 IP Enabled Satellite Modem Rev. 2 CLI and Telnet Interface CD/CIM550.IOM Menu Options/Fields Entry Description Enabled tells the CiM to receive and process packets from the Satellite Interface. Disabled tells the CiM to discard and not process packets from the Satellite Interface.
  • Page 160 CiM-550 IP Enabled Satellite Modem Rev. 2 CLI and Telnet Interface CD/CIM550.IOM 11.2.2.3 R HDLC A ECEIVER DDRESSES The Receiver HDLC Addresses page is activated from the Satellite/HDLC Interface page. This page allows the user to define up to four HDLC addresses that can carry user information on the Satellite Interface.

  • Page 161: Route Table Configuration Page

    CiM-550 IP Enabled Satellite Modem Rev. 2 CLI and Telnet Interface CD/CIM550.IOM 11.2.3 R OUTE ABLE ONFIGURATION The Route Table Configuration page is activated from the Main Menu page. The Route Table Configuration page contains the following options/fields: Menu Options/Fields...
  • Page 162 CiM-550 IP Enabled Satellite Modem Rev. 2 CLI and Telnet Interface CD/CIM550.IOM Menu Options/Fields Entry Description Optionally: If the user enters a multicast address (224.0.0.0-239.255.255.255) as the destination IP address, then the following parameters will be requested: Route MultiCast packets from Ethernet to Satellite?
  • Page 163 Note: QOS and DES features can only be updated if the QOS and/or DES FAST features have been purchased from Comtech EF Data and the appropriate license key has been entered at the front panel.
  • Page 164 CiM-550 IP Enabled Satellite Modem Rev. 2 CLI and Telnet Interface CD/CIM550.IOM Menu Options/Fields Entry Description packets for a route because of a lack in carrier bandwidth. The Min Bandwidth is entered in multiples of 8 Kbps. Max Bandwidth The Max bandwidth field establishes a hard maximum traffic rate that can be processed by the CiM before it starts to silently discard traffic.
  • Page 165 CiM-550 IP Enabled Satellite Modem Rev. 2 CLI and Telnet Interface CD/CIM550.IOM Menu Options/Fields Entry Description Modem Data Rate is given in true 1K blocks (56K is truly 56Kbps). DES Key The DES Key field allows the user to specify which DES Key should be selected for a route.
  • Page 166 CiM-550 IP Enabled Satellite Modem Rev. 2 CLI and Telnet Interface CD/CIM550.IOM 11.2.3.1.1 Example Implementations using QoS and QoS Prioritization The combination of MIN and MAX Bandwidth QoS combined with QoS Prioity allows for multiple levels of QoS implementation. We recommend that QoS is configured using one of the following formats: PRIORITY with MAX BW –...
  • Page 167 CiM-550 IP Enabled Satellite Modem Rev. 2 CLI and Telnet Interface CD/CIM550.IOM Exit................X Route 1 (Vidconf) and Route 2 (VoIP) traffic require that the packets are forwarded with the least amount of latency, so they are designated as Priority 1. Route 1 has a Min B/W of 512 kbps to insure that amount of B/W will always be available for the video traffic.

  • Page 168: Protocol Configuration Page

    CiM-550 IP Enabled Satellite Modem Rev. 2 CLI and Telnet Interface CD/CIM550.IOM 11.2.4 P ROTOCOL ONFIGURATION The Protocol Configuration page is activated from the Main Menu page. The Protocol Configuration page contains the following options/fields: Menu Options/Fields Entry Description IGMP Activates IGMP page.
  • Page 169 CiM-550 IP Enabled Satellite Modem Rev. 2 CLI and Telnet Interface CD/CIM550.IOM 11.2.4.1 IGMP I NFORMATION The page IGMP information page is activated from the Protocol Configuration page. The IGMP Information page allows a user to view the IGMP clients that are actively listening to content being provided by the CiM.
  • Page 170 CiM-550 IP Enabled Satellite Modem Rev. 2 CLI and Telnet Interface CD/CIM550.IOM Menu Options/Fields Entry Description CiM as Server: Defines the number of membership queries that go Number of missed unanswered from LAN clients before the Ehternet responses before leaving...
  • Page 171 CiM-550 IP Enabled Satellite Modem Rev. 2 CLI and Telnet Interface CD/CIM550.IOM Menu Options/Fields Entry Description CiM as Client: Some Cisco Routers may require the definition of a Force Cisco Router Alert Router Alert Option to recognize a report from a Client Option sending V1 reports to join a Multicast group.
  • Page 172 CiM-550 IP Enabled Satellite Modem Rev. 2 CLI and Telnet Interface CD/CIM550.IOM 11.2.4.2 ARP T ABLE TILITIES The ARP Table Utilities page is activated from the Protocol page. The ARP Table Utilities page allows the user to view and edit the ARP table defined by the CiM.
  • Page 173 CiM-550 IP Enabled Satellite Modem Rev. 2 CLI and Telnet Interface CD/CIM550.IOM Menu Options/Fields Entry Description IP Address must be a valid Unicast address (Not Multicast, broadcast, etc.) A MAC Address The MAC Address defines the hardware destination MAC Address that is used when an Ethernet packet destined for an IP machine from the CiM.

  • Page 174: Modem Parameters Page

    CiM-550 IP Enabled Satellite Modem Rev. 2 CLI and Telnet Interface CD/CIM550.IOM 11.2.5 M ODEM ARAMETERS The Modem Parameters page is activated by selecting Satellite Modem Configuration from the Main Menu page. Note: Refer to CDM-550 user manual for detailed explanation of all parameters and settings listed in this menu and sub-menus.
  • Page 175 CiM-550 IP Enabled Satellite Modem Rev. 2 CLI and Telnet Interface CD/CIM550.IOM 11.2.5.1 T RANSMIT ODEM ONFIGURATION The Transmit Modem Configuration page is activated from the Modem Parameters page. The Transmit Modem Configuration page contains the following options/fields: Menu Options/Fields...
  • Page 176 CiM-550 IP Enabled Satellite Modem Rev. 2 CLI and Telnet Interface CD/CIM550.IOM Menu Options/Fields Entry Description 1 - OFF Carrier 2 - ON 3 - RTI Save Parameters This option allows a user to save the current configuration of the CiM to permanent storage. This configuration will be restored on each successive power cycle of the CiM.
  • Page 177 CiM-550 IP Enabled Satellite Modem Rev. 2 CLI and Telnet Interface CD/CIM550.IOM 11.2.5.2 R ECEIVE ODEM ONFIGURATION The Receive Modem Configuration page is activated from the Modem Parameters page. The Receive Modem Configuration Page contains the following options/fields: Menu Options/Fields...
  • Page 178 CiM-550 IP Enabled Satellite Modem Rev. 2 CLI and Telnet Interface CD/CIM550.IOM Menu Options/Fields Entry Description configuration will be restored on each successive power cycle of the CiM. Exit This option allows a user to exit the current menu and...
  • Page 179 CiM-550 IP Enabled Satellite Modem Rev. 2 CLI and Telnet Interface CD/CIM550.IOM 11.2.5.3 AUPC M ODEM ONFIGURATION The AUPC Modem Configuration page is activated from the Modem Parameters page. The AUPC Modem Configuration page contains the following options/fields: Menu Options/Fields...
  • Page 180 CiM-550 IP Enabled Satellite Modem Rev. 2 CLI and Telnet Interface CD/CIM550.IOM 11.2.5.4 M ODEM ISCELLANEOUS ONFIGURATION The Modem Miscellaneous Configuration page is activated from the Modem Parameters page. The Modem Miscellaneous Configuration Page contains the following options/fields: Menu Options/Fields...
  • Page 181 CiM-550 IP Enabled Satellite Modem Rev. 2 CLI and Telnet Interface CD/CIM550.IOM 11.2.5.5 A LARM ASKS ODEM ONFIGURATION The Alarm Masks Modem Configuration page is activated from the Modem Parameters page. The Alarm Masks Modem Configuration page contains the following options/fields:...
  • Page 182 CiM-550 IP Enabled Satellite Modem Rev. 2 CLI and Telnet Interface CD/CIM550.IOM 11.2.5.6 M ODEM TILITIES The Modem Utilities page is activated from the Modem Parameters page. The Modem Utilities page contains the following options/fields: Menu Options/Fields Entry Description Modem Time...
  • Page 183 CiM-550 IP Enabled Satellite Modem Rev. 2 CLI and Telnet Interface CD/CIM550.IOM 11.2.5.7 M ODEM VENTS The Modem Events page is activated from the Modem Parameters page. The Modem Events page contains the following options/fields: Menu Options/Fields Entry Description Statistics Sample Interval...

  • Page 184: Redundancy Configuration Page

    CiM-550 IP Enabled Satellite Modem Rev. 2 CLI and Telnet Interface CD/CIM550.IOM 11.2.6 R EDUNDANCY ONFIGURATION The Redundancy Configuration page is activated from the Main Menu page. Note: This page is not accessible unless the modem is properly connected to a Comtech EF Data qualified Redundancy Switch.
  • Page 185 CiM-550 IP Enabled Satellite Modem Rev. 2 CLI and Telnet Interface CD/CIM550.IOM Redundancy implies the coordination of two CiM’s to provide a redundant link. Each of the CiM’s will be defined as either an Online or Offline. The Online is the unit that will process user traffic.
  • Page 186 CiM-550 IP Enabled Satellite Modem Rev. 2 CLI and Telnet Interface CD/CIM550.IOM The Redundancy Configuration page contains the following options/fields: Menu Options/Fields Entry Description Current State Read Defines the online/offline status of the CiM. Only Management IP Address, IP Address for the Ethernet Interface for the Local Unit.

  • Page 187: Operations And Maintenance Page

    CiM-550 IP Enabled Satellite Modem Rev. 2 CLI and Telnet Interface CD/CIM550.IOM 11.2.7 O PERATIONS AND AINTENANCE The Operations and Maintenance page is activated from the Main Menu page. The Operations and Maintenance page contains the following options/fields: Menu Options/Fields...
  • Page 188 CiM-550 IP Enabled Satellite Modem Rev. 2 CLI and Telnet Interface CD/CIM550.IOM Menu Options/Fields Entry Description in permanent storage 2. Image2 - boot the firmware loaded into the second slot in permanent storage Statistics Activates Statistics Menu page. Database Operations Activates Administrative Database Operations page.

  • Page 189: Cim-550 Ip Enabled Satellite Modem Rev

    CiM-550 IP Enabled Satellite Modem Rev. 2 CLI and Telnet Interface CD/CIM550.IOM 11.2.7.1 U NFORMATION The Unit Information page is activated from the Operations and Maintenance page.
  • Page 190 CiM-550 IP Enabled Satellite Modem Rev. 2 CLI and Telnet Interface CD/CIM550.IOM 11.2.7.2 S TATISTICS The Statistics Menu page is activated from the Operations and Maintenance page. The Statistics Menu page contains the following options/fields: Menu Options/Fields Entry Description Satellite Transmit Statistics Displays Statistics for the Satellite Transmitter and allows counters to be reset.
  • Page 191 CiM-550 IP Enabled Satellite Modem Rev. 2 CLI and Telnet Interface CD/CIM550.IOM 11.2.7.2.1 Satellite Transmit Statistics Page The Satellite Transmit Statistics page is activated from the Statistics Menu page. The Satellite Transmit Statistics page displays counts of the number of packets transmitted on each configured Satellite destined route on the CiM.
  • Page 192 CiM-550 IP Enabled Satellite Modem Rev. 2 CLI and Telnet Interface CD/CIM550.IOM 11.2.7.2.2 IP Routing Statistics Page The IP Routing Statistics page is activated from the Statistics Menu page The IP Routing Statistics page displays the statistics for the number of IP packets routed by the CiM.
  • Page 193 CiM-550 IP Enabled Satellite Modem Rev. 2 CLI and Telnet Interface CD/CIM550.IOM Menu Options/Fields Entry Description Multicast IP Packets routed Read The Multicast Packets routed to Sat counter indicates to Sat Only the number of Multicast packets that were routed to the Satellite Interface.
  • Page 194 CiM-550 IP Enabled Satellite Modem Rev. 2 CLI and Telnet Interface CD/CIM550.IOM Menu Options/Fields Entry Description Dropped – Filtered Read Limits certain types of traffic that should not leak to Only Satellite. For example, broadcasts destined for Satellite LAN Dropped – Multicast Disable...
  • Page 195 CiM-550 IP Enabled Satellite Modem Rev. 2 CLI and Telnet Interface CD/CIM550.IOM 11.2.7.3 A DMINISTRATIVE ATABASE PERATIONS The Administrative Database Operations Page is activated from the Operations and Maintenance Page. The Database Operations option allows the user to view, save, or erase an existing user configuration of the CiM.
  • Page 196 CiM-550 IP Enabled Satellite Modem Rev. 2 CLI and Telnet Interface CD/CIM550.IOM 11.2.7.4 D IAGNOSTICS The Diagnostics Page is activated from the Operations and Maintenance Page. The Diagnostics Page contains the following options/fields: Menu Options/Fields Entry Description Dump Packets transmitted...
  • Page 197 CiM-550 IP Enabled Satellite Modem Rev. 2 CLI and Telnet Interface CD/CIM550.IOM Menu Options/Fields Entry Description Command Line Debug Enter the password to access the debug command Prompt line. Note: This is reserved for Customer Service and engineering use. Save Parameters This option allows a user to save the current configuration of the CiM to permanent storage.
  • Page 198 CiM-550 IP Enabled Satellite Modem Rev. 2 CLI and Telnet Interface CD/CIM550.IOM 11.2.7.5 R EMOTE ONFIGURATION The Remote Port B Configuration page is activated from the Operations and Maintenance page. The Remote Port B Configuration page contains the following options/fields:...

  • Page 199: Telnet - Logout Option

    CiM-550 IP Enabled Satellite Modem Rev. 2 CLI and Telnet Interface CD/CIM550.IOM 11.2.8 T ELNET OGOUT PTION When connecting to the CiM through a telnet session, the menus present another option to logout of the telnet session. This logout option is in all the menus and when selected,...
  • Page 200 CiM-550 IP Enabled Satellite Modem Rev. 2 CLI and Telnet Interface CD/CIM550.IOM NOTES:...

  • Page 201: Chapter 12. Web Server

    The embedded Web Server application provides the user with an easy to use interface to configure and monitor all aspects of the CiM-550 modem. These web pages have been designed for optimal performance when using MicroSoft’s Internet Explorer 5.5 or higher.

  • Page 202: Table 12-1. Cim-550 Web Server Menu Tree

    CiM-550 IP Enabled Satellite Modem Rev. 2 Web Server Pages CD/CIM550.IOM Table 12-1. CiM-550 Web Server Menu Tree Level 2 Level 3 Level 1 ADMINISTRATION System Access Info Administrator Name/PW Read Only Name/PW Read/Write Name/PW Host Access List IP Address/Mask 1 – 4 Access List Enable/Disable Features –...
  • Page 203 CiM-550 IP Enabled Satellite Modem Rev. 2 Web Server Pages CD/CIM550.IOM Level 2 Level 3 Level 1 ODU selection ODU Configuration Up Converter Parameters Down Converter Parameters Unit Parameters Low Noise Amplifier Parameters ODU Circuit ID ODU Utilities ODU Selection...

  • Page 204: Web Server

    The CiM web menu pages are show here in order of appearance in the menu. 12.3.1 H Welcome to the CiM-550 Web Interface. The following sections will give you a brief introduction to each web page available. See the CDM-550 manual, the CiM Usage manual or the CLI section for further detailed explanation of CiM communication options.

  • Page 205: Logoff

    CiM-550 IP Enabled Satellite Modem Rev. 2 Web Server Pages CD/CIM550.IOM 12.3.2 L OGOFF Currently the CiM only allows one connection to the CLI or the Web Interface. Use this option to formally disconnect from the Web Interface. Upon disconnection, you will be...

  • Page 206: Contact Information

    CiM-550 IP Enabled Satellite Modem Rev. 2 Web Server Pages CD/CIM550.IOM 12.3.3 C ONTACT NFORMATION This page provides basic contact information to reach ComTech EF Data Sales and Customer Service via phone or automated e-mail links.

  • Page 207: Support

    CiM-550 IP Enabled Satellite Modem Rev. 2 Web Server Pages CD/CIM550.IOM 12.3.4 S UPPORT The CiM Support page allows you to send an email to a pre-specified location. The email will contain the modem’s serial number and configuration information, which is attached automatically.

  • Page 208: Administration

    Web Server Pages CD/CIM550.IOM 12.3.5 A DMINISTRATION The Adminstration Page provides access to all CiM-550 IP administration features. This includes System Account Information, Host Access Lists, Feature Enable/Disable, etc., as described in the following table: Table 12-2. Admin Fields Field Description Account Names &...
  • Page 209 CiM-550 IP Enabled Satellite Modem Rev. 2 Web Server Pages CD/CIM550.IOM Field Description Optional Features This area allows you to enable or disable certain capabilities of the CiM system. SNMP Use this area to setup SNMP connectivity and security.

  • Page 210: Configuration Summary

    CiM-550 IP Enabled Satellite Modem Rev. 2 Web Server Pages CD/CIM550.IOM 12.3.6 C ONFIGURATION UMMARY This page provides a read only summary of the IP administration parameters.

  • Page 211: Table 12-3. Interface Configuration Fields

    CiM-550 IP Enabled Satellite Modem Rev. 2 Web Server Pages CD/CIM550.IOM 12.3.6.1 I NTERFACE ONFIGURATION This page is used to configure both the Ethernet (LAN) and Satellite (WAN) interfaces. In addition, control of Baud Rate and Character Format for the both the ‘Remote Control B’...
  • Page 212 CiM-550 IP Enabled Satellite Modem Rev. 2 Web Server Pages CD/CIM550.IOM Field Description Satellite (WAN) IP The CiM modem has two network interfaces: the Ethernet interface Address and Mask and the Satellite interface. Each of these network interfaces must be assigned an IP Address. The only requirements on the Satellite IP Address are: 1) that is must not be on the same subnet as the Ethernet Interface;...
  • Page 213 CiM-550 IP Enabled Satellite Modem Rev. 2 Web Server Pages CD/CIM550.IOM Field Description Remote Port B Interface Allows the user to specify which communication standard the Type physical interface will comply to: EIA-232 EIA-485-2W EIA-485-4W CLI Console Port Baud Fixed at 38,4000 Baud...

  • Page 214: Table 12-4. Routes Configuration Fields

    CiM-550 IP Enabled Satellite Modem Rev. 2 Web Server Pages CD/CIM550.IOM 12.3.6.2 R OUTES ONFIGURATION Table 12-4. Routes Configuration Fields Field Description Name Enter the name of the route to add or delete. The route name is case sensative however leading and trailing white space is automatically removed.

  • Page 215: Table 12-5. Multicast Routes Configuration Fields

    CiM-550 IP Enabled Satellite Modem Rev. 2 Web Server Pages CD/CIM550.IOM 12.3.6.3 M ULTICAST OUTES ONFIGURATION Table 12-5. Multicast Routes Configuration Fields Field Description Name Enter a valid route name to add or delete. This field is case sensative, however leading and tailing white space is automatically removed.

  • Page 216: Table 12-6. Arp Table Fields

    CiM-550 IP Enabled Satellite Modem Rev. 2 Web Server Pages CD/CIM550.IOM 12.3.6.4 A (ARP) C DDRESS ESOLUTION ROTOCOL ACHE Table 12-6. ARP Table Fields Field Description IP Address Enter a valid ARP table IP address to add or delete. Link Layer Address Enter a valid Link Layer Address which may be a device MAC address or HDLC address.

  • Page 217: Table 12-7. Qos Fields

    CiM-550 IP Enabled Satellite Modem Rev. 2 Web Server Pages CD/CIM550.IOM 12.3.6.5 QOS (Q UALITY ERVICE ONFIGURATION Table 12-7. QoS Fields Field Description Name Enter a valid Route Table Name. This field is case sensitive. Minimum/Maximum Enter the desired minimum and maximum bandwidth settings for Bandwidth the selected route.

  • Page 218: Table 12-8. Igmp Fields

    CiM-550 IP Enabled Satellite Modem Rev. 2 Web Server Pages CD/CIM550.IOM 12.3.6.6 IGMP C ONFIGURATION Table 12-8. IGMP Fields Field Description Recognize IGMP Queries Set to indicate whether to recognize IGMP queries to the CiM device. IGMP Version Set to indicate whether to send V1 or V2 IGMP reports.

  • Page 219: Table 12-9. Des Encryption Fields

    CiM-550 IP Enabled Satellite Modem Rev. 2 Web Server Pages CD/CIM550.IOM 12.3.6.7 DES E NCRYPTION ONFIGURATION Table 12-9. DES Encryption Fields Field Description DES Status This global setting indicates whether DES is an available option for the CiM. Transmit Key 1 & 2 Enter a valid 16 byte hexidecimal key used for encrypting transmitted packets.

  • Page 220: Table 12-10. Redudancy Configuration Fields

    CiM-550 IP Enabled Satellite Modem Rev. 2 Web Server Pages CD/CIM550.IOM 12.3.6.8 R EDUNDANCY ONFIGURATION Note: This page is not configurable unless the modem is properly connected to a Comtech EF Data qualified Redundancy Switch. Refer to Section 11.2.6 CLI/Telnet Redundancy Configuration for CRS-100/CiM-550 cabling information.
  • Page 221 CiM-550 IP Enabled Satellite Modem Rev. 2 Web Server Pages CD/CIM550.IOM 12.3.6.9 M ODEM ONFIGURATION...
  • Page 222 CiM-550 IP Enabled Satellite Modem Rev. 2 Web Server Pages CD/CIM550.IOM 12.3.6.10 M ODEM TILITIES The modem’s time and date field may be changed on this display as well as the modem’s front panel display identification string (Circuit ID). Please be aware that the CiM is synchronized to the modem’s time and date fields.
  • Page 223 CiM-550 IP Enabled Satellite Modem Rev. 2 Web Server Pages CD/CIM550.IOM 12.3.6.11 ODU C ONFIGURATION Refer to associated ODU/LNA manual for setting options.
  • Page 224 CiM-550 IP Enabled Satellite Modem Rev. 2 Web Server Pages CD/CIM550.IOM 12.3.6.12 ODU U TILITIES Refer to associated ODU manual for setting options.

  • Page 225: Monitoring And Reports

    CiM-550 IP Enabled Satellite Modem Rev. 2 Web Server Pages CD/CIM550.IOM 12.3.7 M ONITORING AND EPORTS Table 12-11. Monitoring and Reports Fields Field Description HDLC Transmit/Receive The Latch and Clock settings report the current alarms and conditions of the CiM.
  • Page 226 CiM-550 IP Enabled Satellite Modem Rev. 2 Web Server Pages CD/CIM550.IOM 12.3.7.1 IP T TATISTICS This page displays the IP transmit statistics for each IP route. Note: Refer to Section 11.2.7.2.1 CLI/Telnet Satellite Transmit Statistics for additional information.
  • Page 227 CiM-550 IP Enabled Satellite Modem Rev. 2 Web Server Pages CD/CIM550.IOM 12.3.7.2 IP R OUTING TATISTICS This page displays the receive IP Routing Statistics for the CiM. Note: Refer to Section 11.2.7.2.2 CLI/Telnet IP Routing Statistics for additional information.
  • Page 228 CiM-550 IP Enabled Satellite Modem Rev. 2 Web Server Pages CD/CIM550.IOM 12.3.7.3 M ODEM TATUS This page provides a read-only summary of various modem status parameters.
  • Page 229 CiM-550 IP Enabled Satellite Modem Rev. 2 Web Server Pages CD/CIM550.IOM 12.3.7.4 M ODEM Field Description Modem Events Log Any occurance of a CiM modem fault will will be time stamped and recorded as an event. Similarly, the time of the fault condition clearing is also logged as an event.
  • Page 230 CiM-550 IP Enabled Satellite Modem Rev. 2 Web Server Pages CD/CIM550.IOM Field Description Modem Statistics Log The user may scroll backwards or forwards through the entries in the statistics log, using the UP/DOWN arrow keys. Pressing ENTER or CLEAR will take the user back to the previous menu.
  • Page 231 Web Server Pages CD/CIM550.IOM The Modem Statistics logging interval can be configured from the CiM-550 front Panel. The User must first set the REMCONT to LOCAL. Then select MONITOR/ STATS/ CONFIGURE.The user is prompted to enter the logging interval (the period of time over which the statistics will be measured), using the UP/DOWN arrow keys, then press ENTER.
  • Page 232 CiM-550 IP Enabled Satellite Modem Rev. 2 Web Server Pages CD/CIM550.IOM 12.3.7.5 ODU S TATUS This page provides a read-only summary of various ODU status parameters.

  • Page 233: Maintenance

    CiM-550 IP Enabled Satellite Modem Rev. 2 Web Server Pages CD/CIM550.IOM 12.3.8 M AINTENANCE 12.3.8.1 U NFORMATION This screen displays the modems uptime, in seconds, serial number and software revision.
  • Page 234 CiM-550 IP Enabled Satellite Modem Rev. 2 Web Server Pages CD/CIM550.IOM 12.3.8.2 F LASH When changes are made to the CiM protocol system, the Flash Save option must be selected in order for these settings to be valid through a power cycle. Without using this option, settings will revert back to their previous states as indicated by the last time the flash was saved.
  • Page 235 CiM-550 IP Enabled Satellite Modem Rev. 2 Web Server Pages CD/CIM550.IOM 12.3.8.3 R ESET The last item on the left-hand menu is “Reset.” This options will force the internal CiM module to reboot. Notes: The main modem will NOT reboot.
  • Page 236 CiM-550 IP Enabled Satellite Modem Rev. 2 Web Server Pages CD/CIM550.IOM NOTES:...

  • Page 237: Chapter 13. Snmp Interface

    The CiM-550 SNMP agent supports both SNMPv1 and v2c. 13.2 MIB-II The CiM-550 agent implements RFC 1213, Management Information Base for Network Management of TCP/IP-based Internets. This is known as “MIB-II support”. The agent implements the following Groups:...

  • Page 238: System Group

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM Table 13-1. MIB-II Support Group Commets System Group Mandatory for RFC1213 Interface Mandatory for RFC1213 Mandatory for RFC1213 ICMP Mandatory for RFC1213 Mandatory for RFC1213 Mandatory for RFC1213 SNMP Mandatory for RFC1213...

  • Page 239: Table 13-3. System Services

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM The system services provided by the cim550 in the OSI network model are: ∑2 where L is the network layer support by the cim550. In the cim550, this is calculated by 2...

  • Page 240: Interface Group

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.2.2 I NTERFACE ROUP This group provides the number of interfaces on a managed device and a table describing all interfaces. The ifNumber OID is the number of network interfaces present on this system. On a cim550 the ifNumber should be 3 corresponding to the Ethernet, Satellite, and Loopback interfaces.
  • Page 241 CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM Description ifInUcastPkts Number of subnetwork-unicast packets received on the interface. This statistic is counted for both the Ethernet and Satellite interfaces. ifInNUcastPkts Number of non-unicast (i.e. broadcast or multicast) packets received on the interface.

  • Page 242: Table 13-5. Address Translation Table Oids

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.2.2.2 AT G ROUP This group contains a table that permits mappings from network addresses (i.e. IP addresses) to physical addresses (i.e. MAC addresses). This group is depreciated. 13.2.2.3 T...
  • Page 243 CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM Description ipForwDatagrams Number of input datagrams for which the cim550 was not their final IP destination, because of which an attempt was made to find a route to forward them to that final destination.

  • Page 244: Table 13-7. Ipaddress Table Oids

    The IP address table contains the cim550’s IP addressing information. Table 13-7. IPAddress Table OIDs Description ipAdEntIfIndex CIM-550’s Interface index value (ifIndex) which uniquely identifies the interface to which the IP address is applicable. ipAdEntNetMask Subnet mask associated with the IP address of this entry. The value of the mask is an IP address with all the network bits set to 1 and all the hosts bits set to 0.

  • Page 245: Table 13-8. Ip Routing Table Oids

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.2.2.6 T IP R OUTING ABLE The IP routing table contains an entry for each route presently known to the cim550. Table 13-8. IP Routing Table OIDs Description ipRouteDest Destination IP address of this route. An entry with a value of 0.0.0.0 is considered a default route.

  • Page 246: Table 13-9. Address Translation Table Oids

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.2.2.7 T DDRESS RANSLATION TABLE The ipNetToMediaTable is the IP Address Translation table used for mapping from IP addresses to physical addresses. Each entry contains one IP address to physical address equivalence.

  • Page 247: Icmp Group

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.2.3 ICMP G ROUP This group contains the Internet Control Message Protocol (ICMP) input and output statistics. ICMP messages are used for out-of-band messages related to network operation. Table 13-10. IP Routing Table OIDs...

  • Page 248: Tcp Group

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.2.4 TCP G ROUP This group contains statistics and control parameters for the TCP protocol. This group contains a table describing the current TCP connections. Note: The instances of object types that represent information about a particular TCP connection are transient;...

  • Page 249: Udp Group

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.2.4.1 T TCP C ONNECTION ABLE The tcpConnTable is a table containing TCP connection-specific information. Each row contains information about a particular current TCP connection. A row is transient, in that it ceases to exist when the connection makes the transition to the CLOSED state.

  • Page 250: Table 13-14. Udp Listener Table Oids

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.2.5.1 T UDP L ISTENER ABLE The UDP listener table contains information about this entity's UDP end-points on which a local application is currently accepting datagrams. A row contains information about a particular current UDP listener.

  • Page 251: Egp Group

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.2.6 EGP G ROUP This group is not implemented in the agent. 13.2.7 T RANSMISSION ROUP This group is not implemented in the agent. 13.2.8 SNMP G ROUP This group provides statistical information regarding the SNMP Protocol.
  • Page 252 CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM Description snmpInTotalSetVars Total number of MIB objects which have been altered successfully by the SNMP agent as the result of receiving valid SNMP Set-Request PDUs. snmpInGetRequests Total number of SNMP Get-Request PDUs which have been accepted and processed by the SNMP agent.

  • Page 253: Private Mib Implementations

    RIVATE MPLEMENTATIONS The agent also implements two private MIBs for the CiM-550. The CiM IP Controller MIB (cimController) holds all the security, feature selection, and IP related parameters and the CiM-550 modem MIB (cim550) which contains all the modem specific parameters.

  • Page 254: Table 13-17. Cim Access Lists Subgroup Oids

    The Access Client List allows an operator to define which remote clients can connect to a CiM-550 when the Access List Enforcement is enabled. Each entry allows an operator to specify an IP address and a subnet mask to define a unique class of clients that are allowed access to the CiM-550.

  • Page 255: Table 13-18. Fast Features

    EATURES VAILABILITY UBGROUP This subgroup tells if a feature is available or unavailable in the CiM-550. The currently supported FAST features are QOS, IGMP, and Encryption. These features must be purchased as additional options. The Datagram Compression, NAPT, TCP Acceleration, Transparent Bridging, and Header Compression features are not yet supported but will be made available in a follow on release.

  • Page 256: Table 13-19. Features Subgroup

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.4.1.4 F EATURES UBGROUP This subgroup allows an operator to enable/disable a feature. Standard features that are supported (telnet, ping response, and multicast routing) can be enabled or disabled by sending a 1 (enable) or 0 (disable).

  • Page 257: Table 13-20. Encryption Subgroup Oids

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.4.1.5 E NCRYPTION UBGROUP Note: This subgroup will only be accessible in the MIB tree if the Encryption FAST feature has been purchased and the license key has been entered through the modem’s front panel.

  • Page 258: Table 13-22. Cim Snmp Community Names

    For example, if the user name is “comtech” and the password is “donttell” then the community string should be “comtechdonttell”. Community strings are used to set up a three-tiered security scheme in the CiM-550. The CiM-550 provides for three types of users in the system: an Admin User, a Read/Write User, and a Read Only User.
  • Page 259 CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.4.1.8 C M SNMP T RAPS The cim550 has the ability to send out SNMP traps when certain events occur in the modem. For example, when the cim550 boots it sends out a coldstart trap and 3 linkup traps, one for each interface that is brought up.

  • Page 260: Table 13-23. Cim Snmp Trap Configuration Oids

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM CiM550 Alarms and Faults SNMPv2 notifications: cim550ModemUnitFaultsTrap 1.3.6.1.4.1.6247.5.1.9.0.624751 cim550ModemTxTrafficFaultsTrap 1.3.6.1.4.1.6247.5.1.9.0.624752 cim550ModemRxTrafficFaultsTrap 1.3.6.1.4.1.6247.5.1.9.0.624753 13.4.1.9 C M SNMP T ONFIGURATION Table 13-23. CIM SNMP Trap COnfiguration OIDs Description cimSnmpTrapDestinationIpAddress Specifies where the trap should be sent to. This is...

  • Page 261: Interface Group

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.4.2 I NTERFACE ROUP This Group controls the parameters of the modem’s Ethernet and HDLC interfaces. 13.4.2.1 E THERNET NTERFACE UBGROUP The subgroup defines the modem’s Ethernet interface. These include parameters for setting the Ethernet speed, IP address, and IP address subnet prefix length.

  • Page 262: Table 13-25. Satellite Ijnterface Subgroup Oids

    OID is set to 1 (enabled), the CiM-550 allows routing of packets from its Ethernet interface to its Satellite interface. If the OID is set to 0 (disabled), the CiM-550 will not route packets from its Ethernet interface to its Satellite interface.

  • Page 263: Table 13-26. Route Table Group Oids

    ABLE ROUP Note: In order for the CiM-550 to properly pass packets over the satellite interface, the user MUST provide the appropriate IP to HDLC address mapping in the ARP table. Please see the ARP Configuration Group for more details.
  • Page 264 Establishes a hard maximum traffic rate that can be cimIpRouteMaxQosBandwidth processed by the CiM-550. A value of 0 for this field implies that no maximum limit is assigned to a route. This value should be in multiples of 8 Kbps.

  • Page 265: Table 13-28. Igmp Configuration Subgroup Oids

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.4.2.4 P ROTOCOLS ROUP 13.4.2.4.1 IGMP Configuration Subgroup Note: This subgroup will only be accessible in the MIB tree if the IGMP FAST feature has been purchased and activated. Otherwise, both gets and sets on these OIDs will return errors.

  • Page 266: Table 13-29. Arp Configuration Subgroup Oids

    ARP entries. The Static ARP entries provided by the CiM-550 fall into two categories: IP-to-MAC and IP-to-HDLC. Note: For the CiM-550 to properly route packets over the Satellite Interface, all of the Next Hop Addresses in the route table MUST have an IP-to-HDLC mapping in the static ARP table.
  • Page 267 CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM Description cimArpRowStatus Used for to create or delete an ARP entry. This OID returns 1 (active) to indicate that an ARP entry is available for use by the managed device. The values of 2 (notInService) and 3 (notReady) are not supported.

  • Page 268: Table 13-31. Redundancy Oids

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.4.2.5 R EDUNDANCY ROUP Table 13-31. Redundancy OIDs Description cimCurrentRedundantState Displays if the modem is Online and Offline. The Online modem is the one that will process traffic. The Offline modem monitors the health of the online unit and will take over if it detects a failure.

  • Page 269: Table 13-33. Remote Port B Configuration Subgroup Oids

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.4.2.6.1 Remote Port B Configuration Subgroup This subgroup defines the Remote Port B configuration. Table 13-33. Remote Port B Configuration Subgroup OIDs Description cimRemotePortBDeviceAddress Defines the device address. Valid addresses are in the range from 0 to 9999.

  • Page 270: Table 13-34. Satellite Transmit Statistics Subgroup Oids

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.4.2.6.2 Satellite Transmit Statistics Subgroup This subgroup contains a table to show the number of packets transmitted on each route destined for the satellite interface. It also contains the number of packets dropped and the route’s data rate.

  • Page 271: Table 13-35. Ip Routing Statistics Subgroup Oids

    Number of packets that were discarded because their Time-To-Live value reached zero. cimDroppedPacketsBadIpHeader Total number of packets that were received by the CiM-550 that contained CRC errors. If received packets contain CRC errors, then the CiM-550 discards the packet.
  • Page 272 Number of packets that were dropped in the buffer. cimDroppedPacketsBadIpVersion Indicates that the packet had an IPv6 header and was dropped. The CiM-550 only supports IPv4. cimDroppedPacketsMiscellaneous Number of packets dropped for an unspecified or miscellaneous reason. cimDroppedPacketsQos...

  • Page 273: Cim 550 Private Mib

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.5 C M 550 P RIVATE 13.5.1 C M 550 O BJECTS ROUP 13.5.1.1 S YSTEM NFORMATION Table 13-36. ARP Configuration Subgroup OIDs Description cim550EquipmentID Unit’s equipment ID. Unit’s serial number.
  • Page 274 CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM Description cim550TxFECType Transmit forward error correction coding type. Valid values are: None Vit RS Seq RS Turbo Q 3/4 Turbo B 21/44 Turbo B 5/16 cim550TxFECCodeRate Transmit forward error correction code rate. Can be set to:...

  • Page 275: Table 13-38. Rx Parameters Oids

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.5.1.3 R ARAMETERS Table 13-38. Rx Parameters OIDs Description cim550RxFrequency Receive frequency in Hz. Can be set from 52,000,000 Hz to 88,000,000 Hz and 104,000,000 Hz to 188,000,000 Hz. cim550RxDataRate Receive data rate in bps.

  • Page 276: Table 13-39. Interface Parameters Oids

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM Description cim550RxClockMode Receive clock mode. Can be set to: Disabled Enabled cim550RxBufferSize Receive buffer size in bits. Can be set to: 256 bits 512 bits 1024 bits 2048 bits 4096 bits cim550RxAcqSweepRange Receive +/- acquisition sweep range of deomulation in KHz.
  • Page 277 CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM Description cim550EdmacAddress The EDMAC slave address will set the range of addresses of distant-end units (modems and transceivers) which this unit will forward messages for. Only values that are integer multiples of ten are permitted.

  • Page 278: Aupc (Automatic Uplink Power Control)

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.5.1.6 T “”AUPC P ARAMETERS Table 13-41. AUPC Parameter OIDs Description cim550AupcEnable Enables or disables AUPC (Automatic Uplink Power Control). Can be set to: Disable Enable cim550AupcControlParameters Defines AUPC (Automatic Uplink Power Control) operating parameters.

  • Page 279: Table 13-42. Status Parameter Oids

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.5.1.7 S TATUS ARAMETERS Table 13-42. Status Parameter OIDs Description cim550RxEbno Value of Ebi/No, can be between 0 and 160 in 0.1 dB where 0 = 0.0 dB to 160 = 16.0 dB and 999 = Demod Unlocked Vaue of Coarse AGC setting, can be between 0 and 99.
  • Page 280 CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM Description cim550ModemTxTrafficFaults Returns the current fault and status codes for the Tx Traffic. The value will be an integer between 0 and 31 where the bit that is set indicates the fault that has...

  • Page 281: Table 13-43. Logs Oids

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.5.1.8 L Table 13-43. Logs OIDs Description cim550ClearEventsLog Instructs the unit to clear all Stored Events. A value of 1 (yes) is used to clear the event log. cim550NumberUnreadEvents Returns the number of Stored Events which remain unread.

  • Page 282: Table 13-44. Odu System Information Oids

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM Description cim550RetrieveNext5Statistics Unit returns the oldest 5 Stored Statistics which have not yet been read over the remote control. Reply format: {CR}Sub-body{CR}Sub-body{CR}Sub- body{CR}Subbody{CR}Sub-body, where Sub-body= AA.ABB.BC.CD.Dddmmyyhhmmss, AA.A = Minimum Eb/No during sample period.

  • Page 283: Table 13-45. Odu Unit Oids

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.5.1.11 ODU U ARAMETERS Table 13-45. ODU Unit OIDs Description oduUnitMuteMode Unit mute. Can be set to: Unmute Mute oduUnitColdStart Unit cold start. Can be set to: Disabled Enabled oduUnitAutoFaultRecovery Auto fault recovery.

  • Page 284: Table 13-46. Odu Tx Parameters Oids

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.5.1.12 ODU T ARAMETERS Table 13-46. ODU Tx Parameters OIDs Description OduTxFrequency Transmit frequency in KHz. Can be set between 5,845,000 KHz and 181,00,000 KHz. OduTxAttenuation Transmit attenuation. Can be between 0 and 2000 in 0.01 dB, where 0 = 0.00dB to 2000 = 20.00dB.

  • Page 285: Table 13-47. Odu Rx Parameters Oids

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.5.1.13 ODU R ARAMETERS Table 13-47. ODU Rx Parameters OIDs Description OduRxFequency Receive frequency in KHz. Can be between 3,625,000 KHz and 14,100,000 KHz. oduRxAttenuation Receive attenuation. Can be between 0..2500 in 0.01dB where 0=0.00dB to 2500=25.00dB.

  • Page 286: Table 13-48. Odu Unit Status Oids

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.5.1.14 ODU U TATUS Table 13-48. ODU Unit Status OIDs Description Online state. Can be set to: OduOnlineState Offline Online oduMaintenanceParameters Used to Query the maintenance status of the CSAT.

  • Page 287: Table 13-49. Odu Logs Oids

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM Description OduUnitFaults Used to Query the Alarm status of the CSAT. A integer value will be returned between 0..262143 where the bits that are set indicate the faults which have occurred:...

  • Page 288: Cim Ip Controller Mib Tree

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.6 C M IP C MIB T ONTROLLER MIB Tree: 1 --- iso 1.3 --- org 1.3.6 --- dod 1.3.6.1 --- internet 1.3.6.1.4 --- private 1.3.6.1.4.1 --- enterprises 1.3.6.1.4.1.6247 --- comtech 1.3.6.1.4.1.6247.4 --- cimController...
  • Page 289 CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 1.3.6.1.4.1.6247.4.2.5.1 --- cimDatagramCompressionOption (Availability) 1.3.6.1.4.1.6247.4.2.5.2 --- cimNaptOption (Availability) 1.3.6.1.4.1.6247.4.2.5.3 --- cimQosOption (Availability) 1.3.6.1.4.1.6247.4.2.5.4 --- cimTcpAccelerationOption (Availability) 1.3.6.1.4.1.6247.4.2.5.5 --- cimTransparentBridgeOption (Availability) 1.3.6.1.4.1.6247.4.2.5.6 --- cimEncryptionOption (Availability) 1.3.6.1.4.1.6247.4.2.5.7 --- cimIgmpOption (Availability) 1.3.6.1.4.1.6247.4.2.5.8 --- cimHeaderCompressionOption (Availability) 1.3.6.1.4.1.6247.4.2.6 --- cimFeaturesConfig...
  • Page 290 CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 1.3.6.1.4.1.6247.4.2.8.3 --- cimSmtpDestinationName(DisplayString) 1.3.6.1.4.1.6247.4.2.9 --- cimSnmp 1.3.6.1.4.1.6247.4.2.9.1 --- cimSnmpTrapDestinationIpAddress (IpAddress) 1.3.6.1.4.1.6247.4.2.9.2 --- cimSnmpTrapCommunity (DisplayString) 1.3.6.1.4.1.6247.4.2.9.3 --- cimSnmpTrapVersion (INTEGER) 1.3.6.1.4.1.6247.4.2.9.4 --- cimSnmpAuthenticationFailureCommunity (DisplayString) 1.3.6.1.4.1.6247.4.2.9.5 --- cimSnmpAuthenticationFailureAddress (IpAddress) 1.3.6.1.4.1.6247.4.3 --- cimInterfaces 1.3.6.1.4.1.6247.4.3.1 --- cimEthernetInterface 1.3.6.1.4.1.6247.4.3.1.1 --- cimEthernetMacAddress (DisplayString)
  • Page 291 CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 1.3.6.1.4.1.6247.4.4.3.1.6 --- cimIpRouteMulticastOptions (INTEGER) 1.3.6.1.4.1.6247.4.4.3.1.7 --- cimIpRouteMinQosBandwidth (INTEGER) 1.3.6.1.4.1.6247.4.4.3.1.8 --- cimIpRouteMaxQosBandwidth (INTEGER) 1.3.6.1.4.1.6247.4.4.3.1.9 --- cimIpRouteDesKey (INTEGER) 1.3.6.1.4.1.6247.4.4.3.1.10 --- cimIpRouteRowStatus (INTEGER) 1.3.6.1.4.1.6247.4.4.3.1.11 --- cimIpRoutePriority (INTEGER32) 1.3.6.1.4.1.6247.4.5 --- cimProtocols 1.3.6.1.4.1.6247.4.5.1 --- cimIgmpConfig 1.3.6.1.4.1.6247.4.5.1.1 --- cimIgmpTable (SEQUENCE OF CimIgmpEntry)
  • Page 292 CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 1.3.6.1.4.1.6247.4.5.2.2.1.4 --- cimArpPhysType (INTEGER) 1.3.6.1.4.1.6247.4.5.2.2.1.5 --- cimArpRowStatus (INTEGER) 1.3.6.1.4.1.6247.4.6 --- cimRedundancy 1.3.6.1.4.1.6247.4.6.1 --- cimCurrentRedundantState (INTEGER) 1.3.6.1.4.1.6247.4.6.2 --- cimLocalUnitManagementIpAddress (IpAddress) 1.3.6.1.4.1.6247.4.6.3 --- cimRedundantUnitManagementIpAddress (IpAddress) 1.3.6.1.4.1.6247.4.6.4 --- cimRedundantTrafficIpAddress (IpAddress) 1.3.6.1.4.1.6247.4.6.5 --- cimRedundantTrafficSubnetMaskLen (INTEGER) 1.3.6.1.4.1.6247.4.6.6 --- cimForceUnitOffline (YesNo)
  • Page 293 CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 1.3.6.1.4.1.6247.4.8.2 --- cimIpRoutingStatistics 1.3.6.1.4.1.6247.4.8.2.1 --- cimUnicastIpPacketsToSatellite (Counter32) 1.3.6.1.4.1.6247.4.8.2.2 --- cimUnicastIpPacketsToEthernet (Counter32) 1.3.6.1.4.1.6247.4.8.2.3 --- cimMulticastIpPacketsToSatellite (Counter32) 1.3.6.1.4.1.6247.4.8.2.4 --- cimMulticastIpPacketsToEthernet (Counter32) 1.3.6.1.4.1.6247.4.8.2.5 --- cimBroadcastIpPacketsToSatellite (Counter32) 1.3.6.1.4.1.6247.4.8.2.6 --- cimBroadcastIpPacketsToEthernet (Counter32) 1.3.6.1.4.1.6247.4.8.2.7 --- cimPacketsFromSatellite (Counter32) 1.3.6.1.4.1.6247.4.8.2.8 --- cimTotalIpPacketsToSatellite (Counter32)

  • Page 294: Cim Ip Controller Mib

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7 C M IP C ONTROLLER 13.7.1 ONTROLLER Name cimController 1.3.6.1.4.1.6247.4 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4) Module CIMController Parent comtech Child cimControllerIdentity Type MODULE-IDENTITY Organization Comtech EF Data Last updated 200204180800Z...

  • Page 295: Cimmibversion

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.4 ERSION Name cimMibVersion 1.3.6.1.4.1.6247.4.2.1 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimAdministration(2).cimMibVersion(1) Module CIMController Parent cimAdministration Next sibling cimNamePasswordConfig Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER Composed syntax INTEGER Status current Max-access...

  • Page 296: Cimadminname

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.6 DMIN Name cimAdminName 1.3.6.1.4.1.6247.4.2.3.1 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimAdministration(2).cimNamePasswordConf ig(3).cimAdminName(1) Module CIMController Parent cimNamePasswordConfig Next sibling cimAdminPassword Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_OCTETS Base syntax OCTET STRING Composed syntax DisplayString Status...

  • Page 297: Cimreadwritename

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.8 RITE Name cimReadWriteName 1.3.6.1.4.1.6247.4.2.3.3 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimAdministration(2).cimNamePasswordConf ig(3).cimReadWriteName(3) Module CIMController Parent cimNamePasswordConfig Prev sibling cimAdminPassword Next sibling cimReadWritePassword Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_OCTETS Base syntax OCTET STRING Composed syntax...

  • Page 298: Cimreadonlyname

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.10 Name cimReadOnlyName 1.3.6.1.4.1.6247.4.2.3.5 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimAdministration(2).cimNamePasswordConf ig(3).cimReadOnlyName(5) Module CIMController Parent cimNamePasswordConfig Prev sibling cimReadWritePassword Next sibling cimReadOnlyPassword Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_OCTETS Base syntax OCTET STRING Composed syntax...

  • Page 299: Cimaccesslists

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.12 CCESS ISTS Name cimAccessLists 1.3.6.1.4.1.6247.4.2.4 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimAdministration(2).cimAccessLists(4) Module CIMController Parent cimAdministration Prev sibling cimNamePasswordConfig Next sibling cimFeaturesAvailability Child cimAccessIpAddress1 Type OBJECT-IDENTIFIER 13.7.13 CCESS DDRESS Name cimAccessIpAddress1 1.3.6.1.4.1.6247.4.2.4.1 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6...

  • Page 300: Cimaccesssubnetmasklen1

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.14 CCESS UBNET Name cimAccessSubnetMaskLen1 1.3.6.1.4.1.6247.4.2.4.2 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimAdministration(2).cimAccessLists(4).cimA ccessSubnetMaskLen1(2) Module CIMController Parent cimAccessLists Prev sibling cimAccessIpAddress1 Next sibling cimAccessIpAddress2 Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER Composed syntax...

  • Page 301: Cimaccesssubnetmasklen2

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.16 CCESS UBNET Name cimAccessSubnetMaskLen2 1.3.6.1.4.1.6247.4.2.4.4 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimAdministration(2).cimAccessLists(4).cimA ccessSubnetMaskLen2(4) Module CIMController Parent cimAccessLists Prev sibling cimAccessIpAddress2 Next sibling cimAccessIpAddress3 Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER Composed syntax...

  • Page 302: Cimaccesssubnetmasklen3

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.18 CCESS UBNET Name cimAccessSubnetMaskLen3 1.3.6.1.4.1.6247.4.2.4.6 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimAdministration(2).cimAccessLists(4).cimA ccessSubnetMaskLen3(6) Module CIMController Parent cimAccessLists Prev sibling cimAccessIpAddress3 Next sibling cimAccessIpAddress4 Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER Composed syntax...

  • Page 303: Cimaccesssubnetmask4

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.20 CCESS UBNET Name cimAccessSubnetMask4 1.3.6.1.4.1.6247.4.2.4.8 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimAdministration(2).cimAccessLists(4).cimA ccessSubnetMask4(8) Module CIMController Parent cimAccessLists Prev sibling cimAccessIpAddress4 Next sibling cimAccessListEnforcement Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER Composed syntax...

  • Page 304: Cimfeaturesavailability

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.22 EATURES VAILABILITY Name cimFeaturesAvailability 1.3.6.1.4.1.6247.4.2.5 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimAdministration(2).cimFeaturesAvailability( Module CIMController Parent cimAdministration Prev sibling cimAccessLists Next sibling cimFeaturesConfig Child cimDatagramCompressionOption Type OBJECT-IDENTIFIER 13.7.23 ATAGRAM OMPRESSION PTION Name cimDatagramCompressionOption 1.3.6.1.4.1.6247.4.2.5.1...

  • Page 305: Cimnaptoption

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.24 PTION Name cimNaptOption 1.3.6.1.4.1.6247.4.2.5.2 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimAdministration(2).cimFeaturesAvailability( 5).cimNaptOption(2) Module CIMController Parent cimFeaturesAvailability Prev sibling cimDatagramCompressionOption Next sibling cimQosOption Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER Composed syntax...

  • Page 306: Cimtcpaccelerationoption

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.26 CCELERATION PTION Name cimTcpAccelerationOption 1.3.6.1.4.1.6247.4.2.5.4 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimAdministration(2).cimFeaturesAvailability( 5).cimTcpAccelerationOption(4) Module CIMController Parent cimFeaturesAvailability Prev sibling cimQosOption Next sibling cimTransparentBridgeOption Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER Composed syntax...

  • Page 307: Cimencryptionoption

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.28 NCRYPTION PTION Name cimEncryptionOption 1.3.6.1.4.1.6247.4.2.5.6 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimAdministration(2).cimFeaturesAvailability( 5).cimEncryptionOption(6) Module CIMController Parent cimFeaturesAvailability Prev sibling cimTransparentBridgeOption Next sibling cimIgmpOption Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER Composed syntax...

  • Page 308: Cimheadercompressionoption

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.30 EADER OMPRESSION PTION Name cimHeaderCompressionOption 1.3.6.1.4.1.6247.4.2.5.8 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimAdministration(2).cimFeaturesAvailability( 5).cimHeaderCompressionOption(8) Module CIMController Parent cimFeaturesAvailability Prev sibling cimIgmpOption Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER Composed syntax Availability...

  • Page 309: Cimtelnetfeature

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.33 ELNET EATURE Name cimTelnetFeature 1.3.6.1.4.1.6247.4.2.6.2 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimAdministration(2).cimFeaturesConfig(6).ci mTelnetFeature(2) Module CIMController Parent cimFeaturesConfig Prev sibling cimMidasFeature Next sibling cimPingResponseFeature Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER Composed syntax...

  • Page 310: Cimdownlinkmulticastroutingfeature

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.35 OWNLINK ULTICAST OUTING EATURE Name cimDownlinkMulticastRoutingFeature 1.3.6.1.4.1.6247.4.2.6.4 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimAdministration(2).cimFeaturesConfig(6).ci mDownlinkMulticastRoutingFeature(4) Module CIMController Parent cimFeaturesConfig Prev sibling cimPingResponseFeature Next sibling cimDatagramCompressionOpt Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax...

  • Page 311: Cimnaptopt

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.37 Name cimNaptOpt 1.3.6.1.4.1.6247.4.2.6.6 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimAdministration(2).cimFeaturesConfig(6).ci mNaptOpt(6) Module CIMController Parent cimFeaturesConfig Prev sibling cimDatagramCompressionOpt Next sibling cimQosOpt Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER Composed syntax EnableDisable...

  • Page 312: Cimtcpaccelerationopt

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.39 CCELERATION Name cimTcpAccelerationOpt 1.3.6.1.4.1.6247.4.2.6.8 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimAdministration(2).cimFeaturesConfig(6).ci mTcpAccelerationOpt(8) Module CIMController Parent cimFeaturesConfig Prev sibling cimQosOpt Next sibling cimTransparenetBridgeOpt Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER Composed syntax...

  • Page 313: Cimtransmitdesencryptionopt

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.41 RANSMIT NCRYPTION Name cimTransmitDesEncryptionOpt 1.3.6.1.4.1.6247.4.2.6.10 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimAdministration(2).cimFeaturesConfig(6).ci mTransmitDesEncryptionOpt(10) Module CIMController Parent cimFeaturesConfig Prev sibling cimTransparenetBridgeOpt Next sibling cimReceiveDesEncryptionOpt Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER Composed syntax...

  • Page 314: Cimigmpopt

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.43 Name cimIgmpOpt 1.3.6.1.4.1.6247.4.2.6.12 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimAdministration(2).cimFeaturesConfig(6).ci mIgmpOpt(12) Module CIMController Parent cimFeaturesConfig Prev sibling cimReceiveDesEncryptionOpt Next sibling cimHeaderCompressionOpt Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER Composed syntax EnableDisable...

  • Page 315: Cimdesencryptconfig

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.45 NCRYPT ONFIG Name cimDesEncryptConfig 1.3.6.1.4.1.6247.4.2.7 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimAdministration(2).cimDesEncryptConfig(7 Module CIMController Parent cimAdministration Prev sibling cimFeaturesConfig Next sibling cimSmtp Child cimTransmitEncryptEnabled Type OBJECT-IDENTIFIER 13.7.46 RANSMIT NCRYPT NABLED Name cimTransmitEncryptEnabled 1.3.6.1.4.1.6247.4.2.7.1...

  • Page 316: Cimreceivedecryptenabled

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.47 ECEIVE ECRYPT NABLED Name cimReceiveDecryptEnabled 1.3.6.1.4.1.6247.4.2.7.2 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimAdministration(2).cimDesEncryptConfig(7 ).cimReceiveDecryptEnabled(2) Module CIMController Parent cimDesEncryptConfig Prev sibling cimTransmitEncryptEnabled Next sibling cimTransmitKey1 Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER...

  • Page 317: Cimtransmitkey2

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.49 RANSMIT Name cimTransmitKey2 1.3.6.1.4.1.6247.4.2.7.4 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimAdministration(2).cimDesEncryptConfig(7 ).cimTransmitKey2(4) Module CIMController Parent cimDesEncryptConfig Prev sibling cimTransmitKey1 Next sibling cimReceiveKey1 Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_OCTETS Base syntax OCTET STRING Composed syntax...

  • Page 318: Cimreceivekey2

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.51 ECEIVE Name cimReceiveKey2 1.3.6.1.4.1.6247.4.2.7.6 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimAdministration(2).cimDesEncryptConfig(7 ).cimReceiveKey2(6) Module CIMController Parent cimDesEncryptConfig Prev sibling cimReceiveKey1 Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_OCTETS Base syntax OCTET STRING Composed syntax DisplayString Status...

  • Page 319: Cimsmtpserveripaddress

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.53 ERVER DDRESS Name cimSmtpServerIpAddress 1.3.6.1.4.1.6247.4.2.8.1 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimAdministration(2).cimSmtp(8).cimSmtpSe rverIpAddress(1) Module CIMController Parent cimSmtp Next sibling cimSmtpDomain Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_IPADDR Base syntax IpAddress Composed syntax IpAddress Status...

  • Page 320: Cimsmtpdestinationname

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.55 ESTINATION Name cimSmtpDestination 1.3.6.1.4.1.6247.4.2.8.3 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimAdministration(2).cimSmtp(8).cimSmtpDe stinationName(3) Module CIMController Parent cimSmtp Prev sibling cimSmtpServerDomain Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_OCTETS Base syntax OCTET STRING Composed syntax DisplayString Status...

  • Page 321: Cimsnmptrapdestinationipaddress

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.57 ESTINATION DDRESS Name cimSnmpTrapDestinationIpAddress 1.3.6.1.4.1.6247.4.2.9.1 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimAdministration(2).cimSnmp(9).cimSnmpT rapDestinationIpAddress(1) Module CIMController Parent cimSnmp Next sibling cimSnmpTrapCommunity Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_IPADDR Base syntax IpAddress Composed syntax IpAddress Status...

  • Page 322: Cimsnmptrapversion

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.59 ERSION Name cimSnmpTrapVersion 1.3.6.1.4.1.6247.4.2.9.3 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimAdministration(2).cimSnmp(9).cimSnmpT rapVersion(3) Module CIMController Parent cimSnmp Prev sibling cimSnmpTrapCommunity Next sibling cimSnmpAuthenticationFailureCommunity Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER Composed syntax...

  • Page 323: Cimsnmpauthenticationfailureaddress

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.61 UTHENTICATION AILURE DDRESS Name cimSnmpAuthenticationFailureAddress 1.3.6.1.4.1.6247.4.2.9.5 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimAdministration(2).cimSnmp(9).cimSnmpA uthenticationFailureAddress(5) Module CIMController Parent cimSnmp Prev sibling cimSnmpAuthenticationFailureCommunity Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_IPADDR Base syntax IpAddress Composed syntax IpAddress...

  • Page 324: Cimethernetmacaddress

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.64 THERNET DDRESS Name cimEthernetMacAddress 1.3.6.1.4.1.6247.4.3.1.1 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimInterfaces(3).cimEthernetInterface(1).cim EthernetMacAddress(1) Module CIMController Parent cimEthernetInterface Next sibling cimEthernetSpeed Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_OCTETS Base syntax OCTET STRING Composed syntax DisplayString...

  • Page 325: Cimethernetipaddress

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.66 THERNET DDRESS Name cimEthernetIpAddress 1.3.6.1.4.1.6247.4.3.1.3 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimInterfaces(3).cimEthernetInterface(1).cim EthernetIpAddress(3) Module CIMController Parent cimEthernetInterface Prev sibling cimEthernetSpeed Next sibling cimEthernetSubnetPrefixLen Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_IPADDR Base syntax IpAddress Composed syntax...

  • Page 326: Cimsatelliteinterface

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.68 ATELLITE NTERFACE Name cimSatelliteInterface 1.3.6.1.4.1.6247.4.3.2 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimInterfaces(3).cimSatelliteInterface(2) Module CIMController Parent cimInterfaces Prev sibling cimEthernetInterface Child cimSatelliteIpAddress Type OBJECT-IDENTIFIER 13.7.69 ATELLITE DDRESS Name cimSatelliteIpAddress 1.3.6.1.4.1.6247.4.3.2.1 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimInterfaces(3).cimSatelliteInterface(2).cim...

  • Page 327: Cimsatellitesubnetprefixlen

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.70 ATELLITE UBNET REFIX Name cimSatelliteSubnetPrefixLen 1.3.6.1.4.1.6247.4.3.2.2 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimInterfaces(3).cimSatelliteInterface(2).cim SatelliteSubnetPrefixLen(2) Module CIMController Parent cimSatelliteInterface Prev sibling cimSatelliteIpAddress Next sibling cimSatelliteReceiveEnable Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER...

  • Page 328: Cimsatellitetransmitenable

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.72 ATELLITE RANSMIT NABLE Name cimSatelliteTransmitEnable 1.3.6.1.4.1.6247.4.3.2.4 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimInterfaces(3).cimSatelliteInterface(2).cim SatelliteTransmitEnable(4) Module CIMController Parent cimSatelliteInterface Prev sibling cimSatelliteReceiveEnable Next sibling cimSatelliteHdlcAddress1 Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER...

  • Page 329: Cimsatellitehdlcaddress2

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.74 ATELLITE DDRESS Name cimSatelliteHdlcAddress2 1.3.6.1.4.1.6247.4.3.2.6 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimInterfaces(3).cimSatelliteInterface(2).cim SatelliteHdlcAddress2(6) Module CIMController Parent cimSatelliteInterface Prev sibling cimSatelliteHdlcAddress1 Next sibling cimSatelliteHdlcAddress3 Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER Composed syntax...

  • Page 330: Cimsatellitehdlcaddress4

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.76 ATELLITE DDRESS Name cimSatelliteHdlcAddress4 1.3.6.1.4.1.6247.4.3.2.8 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimInterfaces(3).cimSatelliteInterface(2).cim SatelliteHdlcAddress4(8) Module CIMController Parent cimSatelliteInterface Prev sibling cimSatelliteHdlcAddress3 Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER Composed syntax INTEGER Status...

  • Page 331: Cimglobalqosenable

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.78 LOBAL NABLE Name cimGlobalQosEnable 1.3.6.1.4.1.6247.4.4.1 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimRouteTable(4).cimGlobalQosEnable(1) Module CIMController Parent cimRouteTable Next sibling cimIpRouteTable Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER Composed syntax EnableDisable Status current...

  • Page 332: Cimiprouteentry

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.80 OUTE NTRY Name cimIpRouteEntry 1.3.6.1.4.1.6247.4.4.3.1 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimRouteTable(4).cimIpRouteTable(3).cimIp RouteEntry(1) Module CIMController Parent cimIpRouteTable Child cimIpRouteIndex Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_NULL Base syntax CimIpRouteEntry Composed syntax CimIpRouteEntry Status current...

  • Page 333: Cimiprouteindex

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.81 OUTE NDEX Name cimIpRouteIndex 1.3.6.1.4.1.6247.4.4.3.1.1 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimRouteTable(4).cimIpRouteTable(3).cimIp RouteEntry(1).cimIpRouteIndex(1) Module CIMController Parent cimIpRouteEntry Next sibling cimIpRouteName Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER Composed syntax INTEGER Status...

  • Page 334: Cimiproutedestaddress

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.83 OUTE DDRESS Name cimIpRouteDestAddress 1.3.6.1.4.1.6247.4.4.3.1.3 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimRouteTable(4).cimIpRouteTable(3).cimIp RouteEntry(1).cimIpRouteDestAddress(3) Module CIMController Parent cimIpRouteEntry Prev sibling cimIpRouteName Next sibling cimIpRouteDestMaskLen Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_IPADDR Base syntax IpAddress Composed syntax...

  • Page 335: Cimiproutenexthopaddress

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.85 OUTE DDRESS Name cimIpRouteNextHopAddress 1.3.6.1.4.1.6247.4.4.3.1.5 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimRouteTable(4).cimIpRouteTable(3).cimIp RouteEntry(1).cimIpRouteNextHopAddress(5) Module CIMController Parent cimIpRouteEntry Prev sibling cimIpRouteDestMaskLen Next sibling cimIpRouteMulticastOptions Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_IPADDR Base syntax IpAddress Composed syntax...

  • Page 336: Cimiprouteminqosbandwidth

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.87 OUTE ANDWIDTH Name cimIpRouteMinQosBandwidth 1.3.6.1.4.1.6247.4.4.3.1.7 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimRouteTable(4).cimIpRouteTable(3).cimIp RouteEntry(1).cimIpRouteMinQosBandwidth(7) Module CIMController Parent cimIpRouteEntry Prev sibling cimIpRouteMulticastOptions Next sibling cimIpRouteMaxQosBandwidth Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER Composed syntax...

  • Page 337: Cimiproutedeskey

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.89 OUTE Name cimIpRouteDesKey 1.3.6.1.4.1.6247.4.4.3.1.9 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimRouteTable(4).cimIpRouteTable(3).cimIp RouteEntry(1).cimIpRouteDesKey(9) Module CIMController Parent cimIpRouteEntry Prev sibling cimIpRouteMaxQosBandwidth Next sibling cimIpRouteRowStatus Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER Composed syntax...

  • Page 338: Cimiprouterowstatus

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.90 OUTE TATUS Name cimIpRouteRowStatus 1.3.6.1.4.1.6247.4.4.3.1.10 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimRouteTable(4).cimIpRouteTable(3).cimIp RouteEntry(1).cimIpRouteRowStatus(10) Module CIMController Parent cimIpRouteEntry Prev sibling cimIpRouteDesKey Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER Composed syntax INTEGER Status...

  • Page 339: Cimiproutepriority

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.91 OUTE RIORITY Name cimIpRoutePriority 1.3.6.1.4.1.6247.4.4.3.1.11 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(62 47).cimController(4).cimRouteTable(4).cimIpRouteTable(3).cimIpRo uteEntry(1).cimIpRoutePriority(11) Module CIMController Parent cimIpRouteEntry Prev sibling cimIpRouteRowStatus Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax Integer32 Composed syntax Integer32 Status...

  • Page 340: Cimigmptable

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.94 ABLE Name cimIgmpTable 1.3.6.1.4.1.6247.4.5.1.1 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimProtocols(5).cimIgmpConfig(1).cimIgmpT able(1) Module CIMController Parent cimIgmpConfig Next sibling cimIgmpReceiver Child cimIgmpEntry Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_SEQUENCE Base syntax SEQUENCE OF CimIgmpEntry Composed syntax...

  • Page 341: Cimigmpindex

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.96 NDEX Name cimIgmpIndex 1.3.6.1.4.1.6247.4.5.1.1.1.1 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimProtocols(5).cimIgmpConfig(1).cimIgmpT able(1).cimIgmpEntry(1).cimIgmpIndex(1) Module CIMController Parent cimIgmpEntry Next sibling cimIgmpTTL Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER Composed syntax INTEGER Status current...

  • Page 342: Cimigmpclientstate

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.98 LIENT TATE Name cimIgmpClientState 1.3.6.1.4.1.6247.4.5.1.1.1.3 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimProtocols(5).cimIgmpConfig(1).cimIgmpT able(1).cimIgmpEntry(1).cimIgmpClientState(3) Module CIMController Parent cimIgmpEntry Prev sibling cimIgmpTTL Next sibling cimIgmpSrc Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER Composed syntax...

  • Page 343: Cimigmpgroupipaddress

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.100 ROUP DDRESS Name cimIgmpGroupIpAddress 1.3.6.1.4.1.6247.4.5.1.1.1.5 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimProtocols(5).cimIgmpConfig(1).cimIgmpT able(1).cimIgmpEntry(1).cimIgmpGroupIpAddress(5) Module CIMController Parent cimIgmpEntry Prev sibling cimIgmpSrc Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_IPADDR Base syntax IpAddress Composed syntax IpAddress Status...

  • Page 344: Cimigmpenable

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.102 NABLE Name cimIgmpEnable 1.3.6.1.4.1.6247.4.5.1.2.1 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimProtocols(5).cimIgmpConfig(1).cimIgmpR eceiver(2).cimIgmpEnable(1) Module CIMController Parent cimIgmpReceiver Next sibling cimIgmpQueryPeriod Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER Composed syntax EnableDisable Status current...

  • Page 345: Cimigmpmaxresptime

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.104 Name cimIgmpMaxRespTime 1.3.6.1.4.1.6247.4.5.1.2.3 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimProtocols(5).cimIgmpConfig(1).cimIgmpR eceiver(2).cimIgmpMaxRespTime(3) Module CIMController Parent cimIgmpReceiver Prev sibling cimIgmpQueryPeriod Next sibling cimIgmpMaxMissBeforeDrop Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER Composed syntax INTEGER...

  • Page 346: Cimigmptransmiter

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.106 RANSMITER Name cimIgmpTransmiter 1.3.6.1.4.1.6247.4.5.1.3 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimProtocols(5).cimIgmpConfig(1).cimIgmpTr ansmiter(3) Module CIMController Parent cimIgmpConfig Prev sibling cimIgmpReceiver Child cimIgmpRecognizeQueries Type OBJECT-IDENTIFIER 13.7.107 ECOGNIZE UERIES Name cimIgmpRecognizeQueries 1.3.6.1.4.1.6247.4.5.1.3.1 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimProtocols(5).cimIgmpConfig(1).cimIgmpTr...

  • Page 347: Cimigmpversionunsolicitedreports

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.108 ERSION NSOLICITED EPORTS Name cimIgmpVersionUnsolicitedReports 1.3.6.1.4.1.6247.4.5.1.3.2 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimProtocols(5).cimIgmpConfig(1).cimIgmpTr ansmiter(3).cimIgmpVersionUnsolicitedReports(2) Module CIMController Parent cimIgmpTransmiter Prev sibling cimIgmpRecognizeQueries Next sibling cimIgmpForceAlertOption Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER...

  • Page 348: Cimigmpunsolicitedreportinterval

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.110 NSOLICITED EPORT NTERVAL Name cimIgmpUnsolicitedReportInterval 1.3.6.1.4.1.6247.4.5.1.3.4 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimProtocols(5).cimIgmpConfig(1).cimIgmpTr ansmiter(3).cimIgmpUnsolicitedReportInterval(4) Module CIMController Parent cimIgmpTransmiter Prev sibling cimIgmpForceAlertOption Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER Composed syntax INTEGER...

  • Page 349: Cimflusharptable

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.112 LUSH ABLE Name cimFlushArpTable 1.3.6.1.4.1.6247.4.5.2.1 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimProtocols(5).cimArpConfig(2).cimFlushAr pTable(1) Module CIMController Parent cimArpConfig Next sibling cimArpTable Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER Composed syntax YesNo Status...

  • Page 350: Cimarpentry

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.114 NTRY Name cimArpEntry 1.3.6.1.4.1.6247.4.5.2.2.1 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimProtocols(5).cimArpConfig(2).cimArpTabl e(2).cimArpEntry(1) Module CIMController Parent cimArpTable Child cimArpIndex Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_NULL Base syntax CimArpEntry Composed syntax CimArpEntry Status current Max-access...

  • Page 351: Cimarpipaddress

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.116 DDRESS Name cimArpIpAddress 1.3.6.1.4.1.6247.4.5.2.2.1.2 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimProtocols(5).cimArpConfig(2).cimArpTabl e(2).cimArpEntry(1).cimArpIpAddress(2) Module CIMController Parent cimArpEntry Prev sibling cimArpIndex Next sibling cimArpPhysAddress Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_IPADDR Base syntax IpAddress Composed syntax...

  • Page 352: Cimarpphystype

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.118 Name cimArpPhysType 1.3.6.1.4.1.6247.4.5.2.2.1.4 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimProtocols(5).cimArpConfig(2).cimArpTabl e(2).cimArpEntry(1).cimArpPhysType(4) Module CIMController Parent cimArpEntry Prev sibling cimArpPhysAddress Next sibling cimArpRowStatus Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER Composed syntax INTEGER...

  • Page 353: Cimarprowstatus

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.119 TATUS Name cimArpRowStatus 1.3.6.1.4.1.6247.4.5.2.2.1.5 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimProtocols(5).cimArpConfig(2).cimArpTabl e(2).cimArpEntry(1).cimArpRowStatus(5) Module CIMController Parent cimArpEntry Prev sibling cimArpPhysType Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER Composed syntax INTEGER Status current...

  • Page 354: Cimredundancy

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.120 EDUNDANCY Name cimRedundancy 1.3.6.1.4.1.6247.4.6 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimRedundancy(6) Module CIMController Parent cimController Prev sibling cimProtocols Next sibling cimOperMaint Child cimCurrentRedundantState Type OBJECT-IDENTIFIER 13.7.121 URRENT EDUNDANT TATE Name cimCurrentRedundantState 1.3.6.1.4.1.6247.4.6.1 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6...

  • Page 355: Cimlocalunitmanagementipaddress

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.122 OCAL ANAGEMENT DDRESS Name cimLocalUnitManagementIpAddress 1.3.6.1.4.1.6247.4.6.2 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimRedundancy(6).cimLocalUnitManagemen tIpAddress(2) Module CIMController Parent cimRedundancy Prev sibling cimCurrentRedundantState Next sibling cimRedundantUnitManagementIpAddress Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_IPADDR Base syntax IpAddress...

  • Page 356: Cimredundanttrafficipaddress

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.124 EDUNDANT RAFFIC DDRESS Name cimRedundantTrafficIpAddress 1.3.6.1.4.1.6247.4.6.4 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimRedundancy(6).cimRedundantTrafficIpAd dress(4) Module CIMController Parent cimRedundancy Prev sibling cimRedundantUnitManagementIpAddress Next sibling cimRedundantTrafficSubnetMaskLen Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_IPADDR Base syntax IpAddress...

  • Page 357: Cimforceunitoffline

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.126 ORCE FFLINE Name cimForceUnitOffline 1.3.6.1.4.1.6247.4.6.6 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimRedundancy(6).cimForceUnitOffline(6) Module CIMController Parent cimRedundancy Prev sibling cimRedundantTrafficSubnetMaskLen Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER Composed syntax YesNo Status current...

  • Page 358: Cimappversion

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.128 ERSION Name cimAppVersion 1.3.6.1.4.1.6247.4.7.1 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimOperMaint(7).cimAppVersion(1) Module CIMController Parent cimOperMaint Next sibling cimSaveConfiguration Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_OCTETS Base syntax OCTET STRING Composed syntax DisplayString Status current...

  • Page 359: Cimreset

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.130 ESET Name cimReset 1.3.6.1.4.1.6247.4.7.3 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimOperMaint(7).cimReset(3) Module CIMController Parent cimOperMaint Prev sibling cimSaveConfiguration Next sibling cimRemotePortBConfig Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER Composed syntax TrueFalse...

  • Page 360: Cimremoteportbdeviceaddress

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.132 EMOTE EVICE DDRESS Name cimRemotePortBDeviceAddress 1.3.6.1.4.1.6247.4.7.4.1 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimOperMaint(7).cimRemotePortBConfig(4). cimRemotePortBDeviceAddress(1) Module CIMController Parent cimRemotePortBConfig Next sibling cimRemotePortBBaudRate Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER Composed syntax INTEGER...

  • Page 361: Cimremoteportbformat

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.134 EMOTE ORMAT Name cimRemotePortBFormat 1.3.6.1.4.1.6247.4.7.4.3 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimOperMaint(7).cimRemotePortBConfig(4). cimRemotePortBFormat(3) Module CIMController Parent cimRemotePortBConfig Prev sibling cimRemotePortBBaudRate Next sibling cimRemotePortBInterface Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER Composed syntax...

  • Page 362: Cimstatistics

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.136 TATISTICS Name cimStatistics 1.3.6.1.4.1.6247.4.8 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimStatistics(8) Module CIMController Parent cimController Prev sibling cimOperMaint Child cimSatelliteTransmitStatistics Type OBJECT-IDENTIFIER 13.7.137 ATELLITE RANSMIT TATISTICS Name cimSatelliteTransmitStatistics 1.3.6.1.4.1.6247.4.8.1 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimStatistics(8).cimSatelliteTransmitStatistics...

  • Page 363: Cimsatellitetransmitentry

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.139 ATELLITE RANSMIT NTRY Name cimSatelliteTransmitEntry 1.3.6.1.4.1.6247.4.8.1.1.1 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimStatistics(8).cimSatelliteTransmitStatistics (1).cimSatelliteTransmitTable(1).cimSatelliteTransmitEntry(1) Module CIMController Parent cimSatelliteTransmitTable Child cimSatelliteTransmitIndex Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_NULL Base syntax CimSatelliteTransmitEntry Composed syntax CimSatelliteTransmitEntry Status...

  • Page 364: Cimsatellitetransmitindex

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.140 ATELLITE RANSMIT NDEX Name cimSatelliteTransmitIndex 1.3.6.1.4.1.6247.4.8.1.1.1.1 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimStatistics(8).cimSatelliteTransmitStatistics (1).cimSatelliteTransmitTable(1).cimSatelliteTransmitEntry(1).cimS atelliteTransmitIndex(1) Module CIMController Parent cimSatelliteTransmitEntry Next sibling cimSatelliteTransmitRouteName Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax Integer32 Composed syntax...

  • Page 365: Cimsatellitetransmittotalpacketstransmitted

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.142 ATELLITE RANSMIT OTAL ACKETS RANSMITTED Name cimSatelliteTransmitTotalPacketsTransmitted 1.3.6.1.4.1.6247.4.8.1.1.1.3 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimStatistics(8).cimSatelliteTransmitStatistics (1).cimSatelliteTransmitTable(1).cimSatelliteTransmitEntry(1).cimS atelliteTransmitTotalPacketsTransmitted(3) Module CIMController Parent cimSatelliteTransmitEntry Prev sibling cimSatelliteTransmitRouteName Next sibling cimSatelliteTransmitTotalPacketsDropped Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_CNTR32...

  • Page 366: Cimsatellitetransmitmindatarate

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.144 ATELLITE RANSMIT Name cimSatelliteTransmitMinDataRate 1.3.6.1.4.1.6247.4.8.1.1.1.5 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimStatistics(8).cimSatelliteTransmitStatistics (1).cimSatelliteTransmitTable(1).cimSatelliteTransmitEntry(1).cimS atelliteTransmitMinDataRate(5) Module CIMController Parent cimSatelliteTransmitEntry Prev sibling cimSatelliteTransmitTotalPacketsDropped Next sibling cimSatelliteTransmitMaxDataRate Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER...

  • Page 367: Cimsatellitetransmitavgdatarate

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.146 ATELLITE RANSMIT Name cimSatelliteTransmitAvgDataRate 1.3.6.1.4.1.6247.4.8.1.1.1.7 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimStatistics(8).cimSatelliteTransmitStatistics (1).cimSatelliteTransmitTable(1).cimSatelliteTransmitEntry(1).cimS atelliteTransmitAvgDataRate(7) Module CIMController Parent cimSatelliteTransmitEntry Prev sibling cimSatelliteTransmitMaxDataRate Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER Composed syntax INTEGER...

  • Page 368: Cimunicastippacketstosatellite

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.148 NICAST ACKETS ATELLITE Name cimUnicastIpPacketsToSatellite 1.3.6.1.4.1.6247.4.8.2.1 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimStatistics(8).cimIpRoutingStatistics(2).cim UnicastIpPacketsToSatellite(1) Module CIMController Parent cimIpRoutingStatistics Next sibling cimUnicastIpPacketsToEthernet Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_CNTR32 Base syntax Counter32 Composed syntax Counter32...

  • Page 369: Cimmulticastippacketstosatellite

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.150 ULTICAST ACKETS ATELLITE Name cimMulticastIpPacketsToSatellite 1.3.6.1.4.1.6247.4.8.2.3 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimStatistics(8).cimIpRoutingStatistics(2).cim MulticastIpPacketsToSatellite(3) Module CIMController Parent cimIpRoutingStatistics Prev sibling cimUnicastIpPacketsToEthernet Next sibling cimMulticastIpPacketsToEthernet Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_CNTR32 Base syntax Counter32...

  • Page 370: Cimbroadcastippacketstosatellite

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.152 ROADCAST ACKETS ATELLITE Name cimBroadcastIpPacketsToSatellite 1.3.6.1.4.1.6247.4.8.2.5 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimStatistics(8).cimIpRoutingStatistics(2).cim BroadcastIpPacketsToSatellite(5) Module CIMController Parent cimIpRoutingStatistics Prev sibling cimMulticastIpPacketsToEthernet Next sibling cimBroadcastIpPacketsToEthernet Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_CNTR32 Base syntax Counter32...

  • Page 371: Cimpacketsfromsatellite

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.154 ACKETS ATELLITE Name cimPacketsFromSatellite 1.3.6.1.4.1.6247.4.8.2.7 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimStatistics(8).cimIpRoutingStatistics(2).cim PacketsFromSatellite(7) Module CIMController Parent cimIpRoutingStatistics Prev sibling cimBroadcastIpPacketsToEthernet Next sibling cimTotalIpPacketsToSatellite Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_CNTR32 Base syntax Counter32 Composed syntax...

  • Page 372: Cimtotalippacketstoethernet

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.156 OTAL ACKETS THERNET Name cimTotalIpPacketsToEthernet 1.3.6.1.4.1.6247.4.8.2.9 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimStatistics(8).cimIpRoutingStatistics(2).cim TotalIpPacketsToEthernet(9) Module CIMController Parent cimIpRoutingStatistics Prev sibling cimTotalIpPacketsToSatellite Next sibling cimIgmpPacketsReceived Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_CNTR32 Base syntax Counter32...

  • Page 373: Ipoptionpacketsreceived

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.159 I PTION ACKETS ECEIVED Name cimIpOptionPacketsReceived 1.3.6.1.4.1.6247.4.8.2.11 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimStatistics(8).cimIpRoutingStatistics(2).cim IpOptionPacketsReceived(11) Module CIMController Parent cimIpRoutingStatistics Prev sibling cimIgmpPacketsReceived Next sibling cimDroppedPacketsTotal Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_CNTR32 Base syntax...

  • Page 374: Cimdroppedpacketsttlexpired

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.161 TTLE ROPPED ACKETS XPIRED Name cimDroppedPacketsTTLExpired 1.3.6.1.4.1.6247.4.8.2.13 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimStatistics(8).cimIpRoutingStatistics(2).cim DroppedPacketsTTLExpired(13) Module CIMController Parent cimIpRoutingStatistics Prev sibling cimDroppedPacketsTotal Next sibling cimDroppedPacketsBadIpHeader Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_CNTR32 Base syntax...

  • Page 375: Cimdroppedpacketsnoroute

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.163 ROPPED ACKETS OUTE Name cimDroppedPacketsNoRoute 1.3.6.1.4.1.6247.4.8.2.15 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimStatistics(8).cimIpRoutingStatistics(2).cim DroppedPacketsNoRoute(15) Module CIMController Parent cimIpRoutingStatistics Prev sibling cimDroppedPacketsBadIpHeader Next sibling cimDroppedPacketsMulticastNoStoe Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_CNTR32 Base syntax Counter32...

  • Page 376: Cimdroppedpacketsfiltered

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.165 ROPPED ACKETS ILTERED Name cimDroppedPacketsFiltered 1.3.6.1.4.1.6247.4.8.2.17 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimStatistics(8).cimIpRoutingStatistics(2).cim DroppedPacketsFiltered(17) Module CIMController Parent cimIpRoutingStatistics Prev sibling cimDroppedPacketsMulticastNoStoe Next sibling cimDroppedPacketsMulticastDisableGroup Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_CNTR32 Base syntax Counter32...

  • Page 377: Cimdroppedpacketsnoarpentry

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.167 ROPPED ACKETS NTRY Name cimDroppedPacketsNoArpEntry 1.3.6.1.4.1.6247.4.8.2.19 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimStatistics(8).cimIpRoutingStatistics(2).cim DroppedPacketsNoArpEntry(19) Module CIMController Parent cimIpRoutingStatistics Prev sibling cimDroppedPacketsMulticastDisableGroup Next sibling cimDroppedPacketsBadBufferLength Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_CNTR32 Base syntax Counter32...

  • Page 378: Cimdroppedpacketsbadipversion

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.169 ROPPED ACKETS ERSION Name cimDroppedPacketsBadIpVersion 1.3.6.1.4.1.6247.4.8.2.21 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimStatistics(8).cimIpRoutingStatistics(2).cim DroppedPacketsBadIpVersion(21) Module CIMController Parent cimIpRoutingStatistics Prev sibling cimDroppedPacketsBadBufferLength Next sibling cimDroppedPacketsMiscellaneous Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_CNTR32 Base syntax Counter32...

  • Page 379: Cimdroppedpacketsqos

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.171 ROPPED ACKETS Name cimDroppedPacketsQos 1.3.6.1.4.1.6247.4.8.2.23 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimStatistics(8).cimIpRoutingStatistics(2).cim DroppedPacketsQos(23) Module CIMController Parent cimIpRoutingStatistics Prev sibling cimDroppedPacketsMiscellaneous Next sibling cimDroppedPacketsQosBuffers Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_CNTR32 Base syntax Counter32 Composed syntax...

  • Page 380: Cimdroppedpacketsdroppedbuffers

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.7.173 ROPPED ACKETS ROPPED UFFERS Name cimDroppedPacketsDroppedBuffers 1.3.6.1.4.1.6247.4.8.2.25 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cimController(4).cimStatistics(8).cimIpRoutingStatistics(2).cim DroppedPacketsDroppedBuffers(25) Module CIMController Parent cimIpRoutingStatistics Prev sibling cimDroppedPacketsQosBuffers Next sibling cimResetCounters Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_CNTR32 Base syntax...
  • Page 381 CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.8 C M-550 MIB T 1 --- iso 1.3 --- org 1.3.6 --- dod 1.3.6.1 --- internet 1.3.6.1.4 --- private 1.3.6.1.4.1 --- enterprises 1.3.6.1.4.1.6247 --- comtech 1.3.6.1.4.1.6247.5 --- cim550 1.3.6.1.4.1.6247.5.1 --- cim550Objects 1.3.6.1.4.1.6247.5.1.1 --- cim550SystemInfo...
  • Page 382 CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 1.3.6.1.4.1.6247.5.1.3.3 --- cim550RxDemodType (INTEGER) 1.3.6.1.4.1.6247.5.1.3.4 --- cim550RxFECType (INTEGER) 1.3.6.1.4.1.6247.5.1.3.5 --- cim550RxFECCodeRate (INTEGER) 1.3.6.1.4.1.6247.5.1.3.6 --- cim550RxSpecInv (INTEGER) 1.3.6.1.4.1.6247.5.1.3.7 --- cim550RxDescrambler (INTEGER) 1.3.6.1.4.1.6247.5.1.3.8 --- cim550RxClockMode (INTEGER) 1.3.6.1.4.1.6247.5.1.3.9 --- cim550RxBufferSize (INTEGER) 1.3.6.1.4.1.6247.5.1.3.10 --- cim550RxAcqSweepRange (INTEGER) 1.3.6.1.4.1.6247.5.1.3.11 --- cim550RxEbnoAlarmPoint (INTEGER)
  • Page 383 CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 1.3.6.1.4.1.6247.5.1.7.6 --- cim550RedundancyState (INTEGER) 1.3.6.1.4.1.6247.5.1.7.7 --- cim550ModemUnitFaults (INTEGER) 1.3.6.1.4.1.6247.5.1.7.8 --- cim550ModemTxTrafficFaults (INTEGER) 1.3.6.1.4.1.6247.5.1.7.9 --- cim550ModemRxTrafficFaults (INTEGER) 1.3.6.1.4.1.6247.5.1.8 --- cim550Logs 1.3.6.1.4.1.6247.5.1.8.1 --- cim550ClearEventsLog (INTEGER) 1.3.6.1.4.1.6247.5.1.8.2 --- cim550NumberUnreadEvents (INTEGER) 1.3.6.1.4.1.6247.5.1.8.3 --- cim550RetrieveNext5Events (DisplayString) 1.3.6.1.4.1.6247.5.1.8.4 --- cim550SetStatisticInterval (INTEGER)
  • Page 384 CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 1.3.6.1.4.1.6247.5.2.3.8 --- oduUnitLNAFaultLogic (INTEGER) 1.3.6.1.4.1.6247.5.2.3.9 --- oduUnitRedundancyMode (INTEGER) 1.3.6.1.4.1.6247.5.2.3.10 --- oduUnitRedForceSwitch (INTEGER) 1.3.6.1.4.1.6247.5.2.4 --- oduTxParameters 1.3.6.1.4.1.6247.5.2.4.1 --- oduTxFrequency (INTEGER) 1.3.6.1.4.1.6247.5.2.4.2 --- oduTxAttenuation (INTEGER) 1.3.6.1.4.1.6247.5.2.4.3 --- oduTxAmplifier (INTEGER) 1.3.6.1.4.1.6247.5.2.4.4 --- oduTxMute (INTEGER) 1.3.6.1.4.1.6247.5.2.4.5 --- oduTxSlopeMode (INTEGER)

  • Page 385: Cim550

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.9 C M-550 MIB 13.9.1 Name cim550 1.3.6.1.4.1.6247.5 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cim550(5) Module CIM550 Parent comtech Child cim550Objects Type MODULE-IDENTITY Organization Comtech EF Data Last updated 200205071700Z Contact info 2114 West 7th Street Tempe, AZ 85281 USA...

  • Page 386: Cim550Equipmentid

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.9.4 550E QUIPMENT Name cim550EquipmentID 1.3.6.1.4.1.6247.5.1.1.1 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cim550(5).cim550Objects(1).cim550SystemInfo(1).cim550Eq uipmentID(1) Module CIM550 Parent cim550SystemInfo Next sibling cim550UnitSerialNumber Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER Composed syntax INTEGER Status...

  • Page 387: Cim550Softwarerevision

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.9.6 550S OFTWARE EVISION Name cim550SoftwareRevision 1.3.6.1.4.1.6247.5.1.1.3 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cim550(5).cim550Objects(1).cim550SystemInfo(1).cim550Sof twareRevision(3) Module CIM550 Parent cim550SystemInfo Prev sibling cim550UnitSerialNumber Next sibling cim550DeviceTime Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_OCTETS Base syntax OCTET STRING...

  • Page 388: Cim550Devicedate

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.9.8 550D EVICE Name cim550DeviceDate 1.3.6.1.4.1.6247.5.1.1.5 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cim550(5).cim550Objects(1).cim550SystemInfo(1).cim550De viceDate(5) Module CIM550 Parent cim550SystemInfo Prev sibling cim550DeviceTime Next sibling cim550CircuitID Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_OCTETS Base syntax OCTET STRING...

  • Page 389: Cim550Localremotestate

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.9.10 550L OCAL EMOTE TATE Name cim550LocalRemoteState 1.3.6.1.4.1.6247.5.1.1.7 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cim550(5).cim550Objects(1).cim550SystemInfo(1).cim550Loc alRemoteState(7) Module CIM550 Parent cim550SystemInfo Prev sibling cim550CircuitID Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER Composed syntax...

  • Page 390: Cim550Txfrequency

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.9.12 550T REQUENCY Name cim550TxFrequency 1.3.6.1.4.1.6247.5.1.2.1 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cim550(5).cim550Objects(1).cim550TxParameters(2).cim550 TxFrequency(1) Module CIM550 Parent cim550TxParameters Next sibling cim550TxDataRate Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER Composed syntax INTEGER Status...

  • Page 391: Cim550Txmodtype

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.9.14 550T Name cim550TxModType 1.3.6.1.4.1.6247.5.1.2.3 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cim550(5).cim550Objects(1).cim550TxParameters(2).cim550 TxModType(3) Module CIM550 Parent cim550TxParameters Prev sibling cim550TxDataRate Next sibling cim550TxFECType Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER Composed syntax...

  • Page 392: Cim550Txfectype

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.9.15 550T FECT Name cim550TxFECType 1.3.6.1.4.1.6247.5.1.2.4 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cim550(5).cim550Objects(1).cim550TxParameters(2).cim550 TxFECType(4) Module CIM550 Parent cim550TxParameters Prev sibling cim550TxModType Next sibling cim550TxFECCodeRate Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER Composed syntax...

  • Page 393: Cim550Txfeccoderate

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.9.16 550T FECC Name cim550TxFECCodeRate 1.3.6.1.4.1.6247.5.1.2.5 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cim550(5).cim550Objects(1).cim550TxParameters(2).cim550 TxFECCodeRate(5) Module CIM550 Parent cim550TxParameters Prev sibling cim550TxFECType Next sibling cim550TxSpecInv Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER Composed syntax...

  • Page 394: Cim550Txscrambler

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.9.18 550T CRAMBLER Name cim550TxScrambler 1.3.6.1.4.1.6247.5.1.2.7 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cim550(5).cim550Objects(1).cim550TxParameters(2).cim550 TxScrambler(7) Module CIM550 Parent cim550TxParameters Prev sibling cim550TxSpecInv Next sibling cim550TxClockSource Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER Composed syntax...

  • Page 395: Cim550Txpowerlevel

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.9.20 550T OWER EVEL Name cim550TxPowerLevel 1.3.6.1.4.1.6247.5.1.2.9 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cim550(5).cim550Objects(1).cim550TxParameters(2).cim550 TxPowerLevel(9) Module CIM550 Parent cim550TxParameters Prev sibling cim550TxClockSource Next sibling cim550TxCarrierState Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER...

  • Page 396: Cim550Rxparameters

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.9.22 550R ARAMETERS Name cim550RxParameters 1.3.6.1.4.1.6247.5.1.3 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cim550(5).cim550Objects(1).cim550RxParameters(3) Module CIM550 Parent cim550Objects Prev sibling cim550TxParameters Next sibling cim550InterfaceParameters Child cim550RxFrequency Type OBJECT-IDENTIFIER 13.9.23 550R REQUENCY Name cim550RxFrequency 1.3.6.1.4.1.6247.5.1.3.1 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6...

  • Page 397: Cim550Rxdatarate

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.9.24 550R Name cim550RxDataRate 1.3.6.1.4.1.6247.5.1.3.2 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cim550(5).cim550Objects(1).cim550RxParameters(3).cim550 RxDataRate(2) Module CIM550 Parent cim550RxParameters Prev sibling cim550RxFrequency Next sibling cim550RxDemodType Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER Composed syntax...

  • Page 398: Cim550Rxfectype

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.9.26 550R FECT Name cim550RxFECType 1.3.6.1.4.1.6247.5.1.3.4 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cim550(5).cim550Objects(1).cim550RxParameters(3).cim550 RxFECType(4) Module CIM550 Parent cim550RxParameters Prev sibling cim550RxDemodType Next sibling cim550RxFECCodeRate Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER Composed syntax...

  • Page 399: Cim550Rxfeccoderate

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.9.27 550R FECC Name cim550RxFECCodeRate 1.3.6.1.4.1.6247.5.1.3.5 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cim550(5).cim550Objects(1).cim550RxParameters(3).cim550 RxFECCodeRate(5) Module CIM550 Parent cim550RxParameters Prev sibling cim550RxFECType Next sibling cim550RxSpecInv Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER Composed syntax...

  • Page 400: Cim550Rxdescrambler

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.9.29 550R ESCRAMBLER Name cim550RxDescrambler 1.3.6.1.4.1.6247.5.1.3.7 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cim550(5).cim550Objects(1).cim550RxParameters(3).cim550 RxDescrambler(7) Module CIM550 Parent cim550RxParameters Prev sibling cim550RxSpecInv Next sibling cim550RxClockMode Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER Composed syntax...

  • Page 401: Cim550Rxbuffersize

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.9.31 550R UFFER Name cim550RxBufferSize 1.3.6.1.4.1.6247.5.1.3.9 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cim550(5).cim550Objects(1).cim550RxParameters(3).cim550 RxBufferSize(9) Module CIM550 Parent cim550RxParameters Prev sibling cim550RxClockMode Next sibling cim550RxAcqSweepRange Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER Composed syntax...

  • Page 402: Cim550Rxebnoalarmpoint

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.9.33 550R LARM OINT Name cim550RxEbnoAlarmPoint 1.3.6.1.4.1.6247.5.1.3.11 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cim550(5).cim550Objects(1).cim550RxParameters(3).cim550 RxEbnoAlarmPoint(11) Module CIM550 Parent cim550RxParameters Prev sibling cim550RxAcqSweepRange Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER Composed syntax INTEGER...

  • Page 403: Cim550Ifimpedance

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.9.35 550I MPEDANCE Name cim550IfImpedance 1.3.6.1.4.1.6247.5.1.4.1 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cim550(5).cim550Objects(1).cim550InterfaceParameters(4).ci m550IfImpedance(1) Module CIM550 Parent cim550InterfaceParameters Next sibling cim550InterfaceType Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER Composed syntax INTEGER Status...

  • Page 404: Cim550Utilityparameters

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.9.37 550U TILITY ARAMETERS Name cim550UtilityParameters 1.3.6.1.4.1.6247.5.1.5 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cim550(5).cim550Objects(1).cim550UtilityParameters(5) Module CIM550 Parent cim550Objects Prev sibling cim550InterfaceParameters Next sibling cim550AupcParameters Child cim550UnitFramingMode Type OBJECT-IDENTIFIER 13.9.38 550U RAMING Name cim550UnitFramingMode 1.3.6.1.4.1.6247.5.1.5.1...

  • Page 405: Cim550Edmacaddress

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.9.39 550E DMAC DDRESS Name cim550EdmacAddress 1.3.6.1.4.1.6247.5.1.5.2 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cim550(5).cim550Objects(1).cim550UtilityParameters(5).cim5 50EdmacAddress(2) Module CIM550 Parent cim550UtilityParameters Prev sibling cim550UnitFramingMode Next sibling cim550UnitTestMode Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER...

  • Page 406: Cim550Recenterbuffer

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.9.41 550R ECENTER UFFER Name cim550RecenterBuffer 1.3.6.1.4.1.6247.5.1.5.4 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cim550(5).cim550Objects(1).cim550UtilityParameters(5).cim5 50RecenterBuffer(4) Module CIM550 Parent cim550UtilityParameters Prev sibling cim550UnitTestMode Next sibling cim550ForceRedundentSwitch Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER...

  • Page 407: Cim550Unitalarmmask

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.9.43 550U LARM Name cim550UnitAlarmMask 1.3.6.1.4.1.6247.5.1.5.6 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cim550(5).cim550Objects(1).cim550UtilityParameters(5).cim5 50UnitAlarmMask(6) Module CIM550 Parent cim550UtilityParameters Prev sibling cim550ForceRedundentSwitch Next sibling cim550UnitConfigStore Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER Composed syntax...

  • Page 408: Cim550Unitconfigload

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.9.45 550U ONFIG Name cim550UnitConfigLoad 1.3.6.1.4.1.6247.5.1.5.8 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cim550(5).cim550Objects(1).cim550UtilityParameters(5).cim5 50UnitConfigLoad(8) Module CIM550 Parent cim550UtilityParameters Prev sibling cim550UnitConfigStore Next sibling cim550OduCommEnable Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER Composed syntax...

  • Page 409: Cim550Aupcparameters

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.9.47 550A ARAMETERS Name cim550AupcParameters 1.3.6.1.4.1.6247.5.1.6 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cim550(5).cim550Objects(1).cim550AupcParameters(6) Module CIM550 Parent cim550Objects Prev sibling cim550UtilityParameters Next sibling cim550StatusParameters Child cim550AupcEnable Type OBJECT-IDENTIFIER 13.9.48 550A NABLE Name cim550AupcEnable 1.3.6.1.4.1.6247.5.1.6.1 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6...

  • Page 410: Cim550Aupccontrolparameters

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.9.49 550A ONTROL ARAMETERS Name cim550AupcControlParameters 1.3.6.1.4.1.6247.5.1.6.2 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cim550(5).cim550Objects(1).cim550AupcParameters(6).cim5 50AupcControlParameters(2) Module CIM550 Parent cim550AupcParameters Prev sibling cim550AupcEnable Next sibling cim550RemoteEbno Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_OCTETS Base syntax OCTET STRING...

  • Page 411: Cim550Txpowerlevelincrease

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.9.51 550T OWER EVEL NCREASE Name cim550TxPowerLevelIncrease 1.3.6.1.4.1.6247.5.1.6.4 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cim550(5).cim550Objects(1).cim550AupcParameters(6).cim5 50TxPowerLevelIncrease(4) Module CIM550 Parent cim550AupcParameters Prev sibling cim550RemoteEbno Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER Composed syntax...

  • Page 412: Cim550Rxebno

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.9.53 550R Name cim550RxEbno 1.3.6.1.4.1.6247.5.1.7.1 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cim550(5).cim550Objects(1).cim550StatusParameters(7).cim 550RxEbno(1) Module CIM550 Parent cim550StatusParameters Next sibling cim550RxCoarseAGC Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER Composed syntax INTEGER Status current...

  • Page 413: Cim550Rxfrequencyoffset

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.9.55 550R REQUENCY FFSET Name cim550RxFrequencyOffset 1.3.6.1.4.1.6247.5.1.7.3 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cim550(5).cim550Objects(1).cim550StatusParameters(7).cim 550RxFrequencyOffset(3) Module CIM550 Parent cim550StatusParameters Prev sibling cim550RxCoarseAGC Next sibling cim550BufferFillState Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER...

  • Page 414: Cim550Rxber

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.9.57 550R Name cim550RxBER 1.3.6.1.4.1.6247.5.1.7.5 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cim550(5).cim550Objects(1).cim550StatusParameters(7).cim 550RxBER(5) Module CIM550 Parent cim550StatusParameters Prev sibling cim550BufferFillState Next sibling cim550RedundancyState Type OBJECT-TYPE Numerical syntax bad syntax Base syntax Unsigned32 Composed syntax...

  • Page 415: Cim550Modemunitfaults

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.9.59 550M ODEM AULTS Name cim550ModemUnitFaults 1.3.6.1.4.1.6247.5.1.7.7 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cim550(5).cim550Objects(1).cim550StatusParameters(7).cim 550ModemUnitFaults(7) Module CIM550 Parent cim550StatusParameters Prev sibling cim550RedundancyState Next sibling cim550ModemTxTrafficFaults Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER...

  • Page 416: Cim550Modemrxtrafficfaults

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.9.61 550M ODEM RAFFIC AULTS Name cim550ModemRxTrafficFaults 1.3.6.1.4.1.6247.5.1.7.9 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cim550(5).cim550Objects(1).cim550StatusParameters(7).cim 550ModemRxTrafficFaults(9) Module CIM550 Parent cim550StatusParameters Prev sibling cim550ModemTxTrafficFaults Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER Composed syntax...

  • Page 417: Cim550Cleareventslog

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.9.63 550C LEAR VENTS Name cim550ClearEventsLog 1.3.6.1.4.1.6247.5.1.8.1 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cim550(5).cim550Objects(1).cim550Logs(8).cim550ClearEve ntsLog(1) Module CIM550 Parent cim550Logs Next sibling cim550NumberUnreadEvents Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER Composed syntax INTEGER...

  • Page 418: Cim550Retrievenext5Events

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.9.65 550R ETRIEVE VENTS Name cim550RetrieveNext5Events 1.3.6.1.4.1.6247.5.1.8.3 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(624 7).cim550(5).cim550Objects(1).cim550Logs(8).cim550RetrieveNext5 Events(3) Module CIM550 Parent cim550Logs Prev sibling cim550NumberUnreadEvents Next sibling cim550SetStatisticInterval Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_OCTETS Base syntax OCTET STRING...

  • Page 419: Cim550Clearstatisticslog

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.9.67 550C LEAR TATISTICS Name cim550ClearStatisticsLog 1.3.6.1.4.1.6247.5.1.8.5 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cim550(5).cim550Objects(1).cim550Logs(8).cim550ClearStati sticsLog(5) Module CIM550 Parent cim550Logs Prev sibling cim550SetStatisticInterval Next sibling cim550NumberUnreadStatistics Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER...

  • Page 420: Cim550Retrievenext5Statistics

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.9.69 550R ETRIEVE TATISTICS Name cim550RetrieveNext5Statistics 1.3.6.1.4.1.6247.5.1.8.7 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cim550(5).cim550Objects(1).cim550Logs(8).cim550RetrieveN ext5Statistics(7) Module CIM550 Parent cim550Logs Prev sibling cim550NumberUnreadStatistics Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_OCTETS Base syntax OCTET STRING Composed syntax...

  • Page 421: Cim550Modemunitfaultsnotification

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.9.72 550M ODEM AULTS OTIFICATION Name cim550ModemUnitFaultsNotification 1.3.6.1.4.1.6247.5.1.9.0.624751 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cim550(5).cim550Objects(1).cim550Notifications(9).cim550N otificationsPrefix(0).cim550ModemUnitFaultsNotification(624751) Module CIM550 Parent cim550NotificationsPrefix Next sibling cim550ModemTxTrafficFaultsNotification Type NOTIFICATION-TYPE Objects cim550ModemUnitFaults Description Modem Unit Faults Trap 13.9.73...

  • Page 422: Oduobjects

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.9.75 BJECTS Name oduObjects 1.3.6.1.4.1.6247.5.2 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cim550(5).oduObjects(2) Module CIM550 Parent cim550 Prev sibling cim550Objects Child oduSelect Type OBJECT-IDENTIFIER 13.9.76 ELECT Name oduSelect 1.3.6.1.4.1.6247.5.2.1 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cim550(5).oduObjects(2).oduSelect(1) Module...

  • Page 423: Odumodelnumbersoftwarever

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.9.78 ODEL UMBER OFTWARE Name oduModelNumberSoftwareVer 1.3.6.1.4.1.6247.5.2.2.1 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cim550(5).oduObjects(2).oduSystemInfo(2).oduModelNumber SoftwareVer(1) Module CIM550 Parent oduSystemInfo Next sibling oduUnitSerialNumber Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_OCTETS Base syntax OCTET STRING Composed syntax...

  • Page 424: Odudevicetime

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.9.80 EVICE Name oduDeviceTime 1.3.6.1.4.1.6247.5.2.2.3 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).co mtech(6247).cim550(5).oduObjects(2).oduSystemInfo(2).od uDeviceTime(3) Module CIM550 Parent oduSystemInfo Prev sibling oduUnitSerialNumber Next sibling oduDeviceDate Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_OCTETS Base syntax OCTET STRING Composed syntax...

  • Page 425: Oducircuitid

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.9.82 IRCUIT Name oduCircuitID 1.3.6.1.4.1.6247.5.2.2.5 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cim550(5).oduObjects(2).oduSystemInfo(2).oduCircuitID(5) Module CIM550 Parent oduSystemInfo Prev sibling oduDeviceDate Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_OCTETS Base syntax OCTET STRING Composed syntax DisplayString Status current...

  • Page 426: Oduunitmutemode

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.9.84 Name oduUnitMuteMode 1.3.6.1.4.1.6247.5.2.3.1 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cim550(5).oduObjects(2).oduUnitParameters(3).oduUnitMute Mode(1) Module CIM550 Parent oduUnitParameters Next sibling oduUnitColdStart Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER Composed syntax INTEGER Status current Max-access...

  • Page 427: Oduunitautofaultrecovery

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.9.86 AULT ECOVERY Name oduUnitAutoFaultRecovery 1.3.6.1.4.1.6247.5.2.3.3 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cim550(5).oduObjects(2).oduUnitParameters(3).oduUnitAuto FaultRecovery(3) Module CIM550 Parent oduUnitParameters Prev sibling oduUnitColdStart Next sibling oduUnitExtRefFaultLogic Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER Composed syntax...

  • Page 428: Oduunitrefoscadjust

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.9.88 DJUST Name oduUnitRefOscAdjust 1.3.6.1.4.1.6247.5.2.3.5 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cim550(5).oduObjects(2).oduUnitParameters(3).oduUnitRefO scAdjust(5) Module CIM550 Parent oduUnitParameters Prev sibling oduUnitExtRefFaultLogic Next sibling oduUnitLNACurrentSource Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER Composed syntax...

  • Page 429: Oduunitlnacurrentwindow

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.9.90 LNAC URRENT INDOW Name oduUnitLNACurrentWindow 1.3.6.1.4.1.6247.5.2.3.7 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cim550(5).oduObjects(2).oduUnitParameters(3).oduUnitLNA CurrentWindow(7) Module CIM550 Parent oduUnitParameters Prev sibling oduUnitLNACurrentSource Next sibling oduUnitLNAFaultLogic Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER...

  • Page 430: Oduunitlnafaultlogic

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.9.91 LNAF AULT OGIC Name oduUnitLNAFaultLogic 1.3.6.1.4.1.6247.5.2.3.8 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cim550(5).oduObjects(2).oduUnitParameters(3).oduUnitLNAF aultLogic(8) Module CIM550 Parent oduUnitParameters Prev sibling oduUnitLNACurrentWindow Next sibling oduUnitRedundancyMode Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER...

  • Page 431: Oduunitredforceswitch

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.9.93 ORCE WITCH Name oduUnitRedForceSwitch 1.3.6.1.4.1.6247.5.2.3.10 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cim550(5).oduObjects(2).oduUnitParameters(3).oduUnitRedF orceSwitch(10) Module CIM550 Parent oduUnitParameters Prev sibling oduUnitRedundancyMode Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER Composed syntax INTEGER Status...

  • Page 432: Odutxfrequency

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.9.95 REQUENCY Name oduTxFrequency 1.3.6.1.4.1.6247.5.2.4.1 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cim550(5).oduObjects(2).oduTxParameters(4).oduTxFrequen cy(1) Module CIM550 Parent oduTxParameters Next sibling oduTxAttenuation Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER Composed syntax INTEGER Status current...

  • Page 433: Odutxamplifier

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.9.97 MPLIFIER Name oduTxAmplifier 1.3.6.1.4.1.6247.5.2.4.3 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cim550(5).oduObjects(2).oduTxParameters(4).oduTxAmplifier Module CIM550 Parent oduTxParameters Prev sibling oduTxAttenuation Next sibling oduTxMute Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER Composed syntax INTEGER...

  • Page 434: Odutxslopemode

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.9.99 LOPE Name oduTxSlopeMode 1.3.6.1.4.1.6247.5.2.4.5 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cim550(5).oduObjects(2).oduTxParameters(4).oduTxSlopeM ode(5) Module CIM550 Parent oduTxParameters Prev sibling oduTxMute Next sibling oduTxSlopeValue Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER Composed syntax...

  • Page 435: Odutxgainoffset

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.9.101 FFSET Name oduTxGainOffset 1.3.6.1.4.1.6247.5.2.4.7 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cim550(5).oduObjects(2).oduTxParameters(4).oduTxGainOff set(7) Module CIM550 Parent oduTxParameters Prev sibling oduTxSlopeValue Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER Composed syntax INTEGER Status current...

  • Page 436: Odurxfrequency

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.9.103 REQUENCY Name oduRxFrequency 1.3.6.1.4.1.6247.5.2.5.1 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cim550(5).oduObjects(2).oduRxParameters(5).oduRxFreque ncy(1) Module CIM550 Parent oduRxParameters Next sibling oduRxAttenuation Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER Composed syntax INTEGER Status current...

  • Page 437: Odurxmute

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.9.105 Name oduRxMute 1.3.6.1.4.1.6247.5.2.5.3 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cim550(5).oduObjects(2).oduRxParameters(5).oduRxMute(3) Module CIM550 Parent oduRxParameters Prev sibling oduRxAttenuation Next sibling oduRxSlopeMode Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER Composed syntax INTEGER Status...

  • Page 438: Odurxslopevalue

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.9.107 LOPE ALUE Name oduRxSlopeValue 1.3.6.1.4.1.6247.5.2.5.5 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cim550(5).oduObjects(2).oduRxParameters(5).oduRxSlopeV alue(5) Module CIM550 Parent oduRxParameters Prev sibling oduRxSlopeMode Next sibling oduRxGainOffset Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER Composed syntax...

  • Page 439: Oduunitstatus

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.9.109 TATUS Name oduUnitStatus 1.3.6.1.4.1.6247.5.2.6 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cim550(5).oduObjects(2).oduUnitStatus(6) Module CIM550 Parent oduObjects Prev sibling oduRxParameters Next sibling oduLogs Child oduOnlineState Type OBJECT-IDENTIFIER 13.9.110 NLINE TATE Name oduOnlineState 1.3.6.1.4.1.6247.5.2.6.1 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6...

  • Page 440: Odumaintenanceparameters

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.9.111 AINTENANCE ARAMETERS Name oduMaintenanceParameters 1.3.6.1.4.1.6247.5.2.6.2 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cim550(5).oduObjects(2).oduUnitStatus(6).oduMaintenanceP arameters(2) Module CIM550 Parent oduUnitStatus Prev sibling oduOnlineState Next sibling oduUnitFaults Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_OCTETS Base syntax OCTET STRING...

  • Page 441: Odulogs

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.9.113 Name oduLogs 1.3.6.1.4.1.6247.5.2.7 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cim550(5).oduObjects(2).oduLogs(7) Module CIM550 Parent oduObjects Prev sibling oduUnitStatus Next sibling oduNotifications Child oduClearEventsLog Type OBJECT-IDENTIFIER 13.9.114 LEAR VENTS Name oduClearEventsLog 1.3.6.1.4.1.6247.5.2.7.1 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6...

  • Page 442: Odunumberunreadevents

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.9.115 UMBER NREAD VENTS Name oduNumberUnreadEvents 1.3.6.1.4.1.6247.5.2.7.2 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cim550(5).oduObjects(2).oduLogs(7).oduNumberUnreadEven ts(2) Module CIM550 Parent oduLogs Prev sibling oduClearEventsLog Next sibling oduRetrieveNext5Events Type OBJECT-TYPE Numerical syntax SNMP_SYNTAX_INT Base syntax INTEGER...

  • Page 443: Odunotifications

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM 13.9.117 OTIFICATIONS Name oduNotifications 1.3.6.1.4.1.6247.5.2.8 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cim550(5).oduObjects(2).oduNotifications(8) Module CIM550 Parent oduObjects Prev sibling oduLogs Child oduNotificationsPrefix Type OBJECT-IDENTIFIER 13.9.118 OTIFICATIONS REFIX Name oduNotificationsPrefix 1.3.6.1.4.1.6247.5.2.8.0 Full path iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6 247).cim550(5).oduObjects(2).oduNotifications(8).oduNotifications...

  • Page 444: Cim-550 Ip Enabled Satellite Modem Rev

    CiM-550 IP Enabled Satellite Modem Rev. 2 SNMP interface CD/CIM550.IOM NOTES:...

  • Page 445: Introduction

    Chapter 14. CiM IP Module Checkout and Fault Isolation 14.1 I NTRODUCTION This equipment contains parts and assemblies sensitive to damage by ESD. Use ESD precautionary procedures when touching, removing, or inserting PCBs. CAUTION This Chapter is for testing and troublshooting CiM IP module and assumes that the base satellite modem is correctly configured and functioning properly.

  • Page 446: Pc Coniguration

    Provided by customer PC with NIC and a terminal Provided by customer emulation program Console cable (DB-9 to RJ-11) Can be procured from Comtech EF Data Ethernet cables Provided by customer IF cables Provided by customer (For IF loopback only. Additional equipment required for RF connectivity.)
  • Page 447 CiM-550 IP Enabled Satellite Modem Rev. 2 CiM IP Module Checkout & Fault Isolation CD/CIM550.IOM 14.2.3 T IF C RANSMIT AND ECEIVE ONFIGURATION Step Procedure Configure the transmit and receive IF parameters on CiM 1 and CiM 2 via the front panel.

  • Page 448: Figure 14-1. Main Menu

    CiM-550 IP Enabled Satellite Modem Rev. 2 CiM IP Module Checkout & Fault Isolation CD/CIM550.IOM 14.2.5 M Figure 14-1. Main Menu To use this onterface, select the appropriate sub-menu or the entry by pressing the character indicated at the right. Enter x to return to the previous menu.
  • Page 449 CiM-550 IP Enabled Satellite Modem Rev. 2 CiM IP Module Checkout & Fault Isolation CD/CIM550.IOM At this point you should be able to ping CiM 1 from PC 1: ping 172.16.10.10 ping 10.1.1.1 14.2.1.2 R OUTE ABLE Step Procedure From Main Menu, select Route Table sub-menu.

  • Page 450: Verification

    CiM-550 IP Enabled Satellite Modem Rev. 2 CiM IP Module Checkout & Fault Isolation CD/CIM550.IOM 14.2.8 C M 2 C ONFIGURATION Disconnect RJ-11 end of the console cable from CiM 1 and connect it to CiM 2. 14.2.8.1 S IP A...
  • Page 451 CiM-550 IP Enabled Satellite Modem Rev. 2 CiM IP Module Checkout & Fault Isolation CD/CIM550.IOM 14.3 T IP M ROUBLESHOOTING ODULE Use the following troubleshooting steps if unable to succesfully complete “CiM IP Module Checkout”. Step Problem Action No Ping response from the 1) Verify correct IP address/subnet on PC and CiM.
  • Page 452 CiM-550 IP Enabled Satellite Modem Rev. 2 CiM IP Module Checkout & Fault Isolation CD/CIM550.IOM 3) Continue sending constant ping from the PC 1 to PC 2. In the CiM 2, go to Operations Maintenance/Diagnostics. Enable ‘Dump Packets received from Satellite Interface”. Verify that the Pings are being received by observing 1 packet on CLI every second.

  • Page 453: Configuration Parameters

    CiM-550 Satellite Modems Many Comtech EF Data modems use "flash memory" internally, eliminating the need for physically replacing firmware. The advantages of using flash are many, but perhaps the greatest benefit is realized by not having to disassemble the modems to replace an integrated circuit.
  • Page 454 Base Modem (M&C or BULK Firmware) The latest firmware releases and a free software utility are available on the Comtech EF Data web site (http://www.comtechefdata.com). This utility is designed to run under Windows 95/98 or Windows NT/2000/XP and provides all of the support required to perform a Comtech EF Data firmware reflash.
  • Page 455 Perform the CiM IP Module upgrade by using an FTP (File Transfer Protocol) utility program. The latest firmware releases are available on the Comtech EF Data web site (http://www.comtechefdata.com). An FTP utility is required to perform a Comtech EF Data firmware reflash. If web downloading is not available or practical, contact the Network Customer Support department (cimfss@comtechefdata.com) to obtain the firmware via an alternate method.
  • Page 456 The CiM300L.mib (fw9630-4x.mib) file is required required if you are using CiM300L modems. The CIM550Traps.mib (fw9630-5x.mib) is required if you are only using the CiM-550 and using SNMP v1 traps. The CIM300LTraps.mib (fw9630-6x.mib) is required if you are only using the CiM-300L and using SNMP v1 traps.

  • Page 457: Index

    INSTALLATION ........13 CiM IP Controller MIB......211 Instruction Code Qualifier .......436 CIM IP Controller Private MIB ....167 Instruction Code........436 CiM-550 MIB Tree ........329 Interface Configuration Page .....74 CiM-550 MIB ..........335 Interface Group ........154 CLI AND TELNET INTERFACE ....57 Interface Group ........175 CLOCKING..........466...
  • Page 458 CiM-550 IP Enabled Satellite Modem Rev. 2 Index CD/CIM550.IOM Menu Tree..........23 Setup ............465 Message Arguments.........438 SNMP Group ...........165 Methods of Operation ........17 SNMP INTERFACE........151 METRIC CONVERSIONS .....503 SNMP Interface ........151 MIB-II ............151 SNMP Operations ........18 Modem Parameters Page......89 Software ............3 MODEMS ..........499...

  • Page 459: Metric Conversions

    METRIC CONVERSIONS Units of Length Unit Centimeter Inch Foot Yard Mile Meter Kilometer Millimeter 1 centimeter — 0.3937 0.03281 0.01094 0.01 — — 6.214 x 10 1 inch 2.540 — 0.08333 0.2778 1.578 x 10 0.254 — 25.4 1 foot 30.480 12.0 —...
  • Page 460 2114 85281 WEST TH STREET TEMPE ARIZONA 480 • 333 • 2200 PHONE 480 • 333 • 2161...

Table of Contents
