CiM-550 IP Enabled Satellite Modem
Front Panel Menus
4.1.6.4 SELECT\INFO\MASK
ALARMS MASKED:
RX-AIS
4.1.6.5 SELECT\INFO\EDMAC
FRAMING: ON
EDMAC MODE: ON
4.1.6.6 SELECTINFO\ID
CIRCUIT ID
________________________
4.1.6.7 SELECTINFO\FW
FIRMWARE: M&C VER 1.22
IP MODULE VER 1. 1. 0_
DISPLAY
TX-AIS
DISPLAY
(SLAVE)
DISPLAY
DISPLAY
SELECTIONS/DESCRIPTION
This shows, in the same format as the CONFIG,
MASK sub menu, which alarms are currently
masked. If an alarm is not masked, a blank is
displayed in the relevant screen position.
SELECTIONS/DESCRIPTION
This screen shows the framing mode, EDMAC
mode, and shows if the unit is an EDMAC MASTER
or SLAVE.
SELECTIONS/DESCRIPTION
This displays the user-defined Circuit ID string,
which is entered via the UTIL, ID screen.
SELECTIONS/DESCRIPTION
46
Rev. 2
CD/CIM550.IOM
