CiM-550 IP Enabled Satellite Modem
Web Server Pages
The Modem Statistics logging interval can be configured from the CiM-550 front Panel.
The User must first set the REMCONT to LOCAL. Then select MONITOR/ STATS/
CONFIGURE.The user is prompted to enter the logging interval (the period of
time over which the statistics will be measured), using the UP/DOWN arrow keys, then
press ENTER. Setting this to a value of 00 disables the feature (no logging).
The user can choose 10, 20, 30, 40, 50, 60, 70, 80, or 90 minutes.
If AUPC is selected, and the modem is not in Framed mode, the following sub-menu is
displayed:
If AUPC is selected, and the modem is in Framed mode, the following sub-menu is
displayed:
The top line displays the value of Eb/No of the demodulator at the distant end of the
satellite link. The Eb/No will display UNLOCK if the remote demod is unlocked. The
bottom line shows how much the AUPC system has increased the output power. If AUPC
is not enabled, the value of TX POWER INCREASE will show as 0.0 dB.
LOGGING INTERVAL:90 MINS
(SET 00 TO DISABLE)(ENT)
(MONITOR) AUPC
FRAMING NOT ENABLED!
(PRESS ENTER)
AUPC: REMOTE EbNo=14.0dB
TX POWER INCREASE=2.2dB
