CiM-550 IP Enabled Satellite Modem
SNMP interface
13.7.114 A
CIM RP
Name
OID
Full path
Module
Parent
Child
Type
Numerical syntax
Base syntax
Composed syntax
Status
Max-access
Sequences
1
2
3
4
5
Indexes
1
Description
13.7.115 A
CIM RP
Name
OID
Full path
Module
Parent
Next sibling
Type
Numerical syntax
Base syntax
Composed syntax
Status
Max-access
Size list
1
Description
E
NTRY
I
NDEX

cimArpEntry

1.3.6.1.4.1.6247.4.5.2.2.1
iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6
247).cimController(4).cimProtocols(5).cimArpConfig(2).cimArpTabl
e(2).cimArpEntry(1)
CIMController
cimArpTable

cimArpIndex

OBJECT-TYPE
SNMP_SYNTAX_NULL
CimArpEntry
CimArpEntry
current
not-accessible
cimArpIndex - INTEGER(2 - int, int32)
cimArpIpAddress - IpAddress(64 - ipaddr)
cimArpPhysAddress - DisplayString(4 - octets)
cimArpPhysType - INTEGER(2 - int, int32)
cimArpRowStatus - INTEGER(2 - int, int32)
cimArpIndex
CIM ARP Entry
cimArpIndex
1.3.6.1.4.1.6247.4.5.2.2.1.1
iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtech(6
247).cimController(4).cimProtocols(5).cimArpConfig(2).cimArpTabl
e(2).cimArpEntry(1).cimArpIndex(1)
CIMController
cimArpEntry
cimArpIpAddress
OBJECT-TYPE
SNMP_SYNTAX_INT
INTEGER
INTEGER
current
read-write
1..256
ARP Table Index
