CiM-550 IP Enabled Satellite Modem
SNMP interface
13.4.1.5 E
NCRYPTION
Note: This subgroup will only be accessible in the MIB tree if the Encryption FAST feature has
been purchased and the license key has been entered through the modem's front panel.
Otherwise, both GETS and SETS on these OIDs will return errors.
This subgroup controls the parameters for the DES feature.
OID
cimTransmitEncryptEnabled
cimReceiveDecryptEnabled
cimTransmitKey1
cimTransmitKey2
cimReceiveKey1
cimReceiveKey2
13.4.1.6 C M SMTP
I
The cimSmtp subsection sets up the cim550 to use a SMTP mail server to send a problem
report back to CiM Support. Along with the problem report, the cim550 sends the
equipment serial number and configuration, which is attached to the email message. By
default, the problem report is sent to cimfss@comtechefdata.com. In order for this to
work, the user is required to enter the IP address of their outgoing SMTP mail server and
the domain name for that server.
OID
cimSmtpServerIpAddress
cimSmtpDomain
cimSmtpDestinationName
S
UBGROUP

Table 13-20. Encryption Subgroup OIDs

Description
Enables/disables encryption on the transmit side.
Enables/disables encryption on the receive side.
Allows the operator to specify the value of Key1 used to
encrypt packets transmitted to the sattelite.
Allows the operator to specify the value of Key2 used to
encrypt transmitted packets transmitted to the sattelite.
Allows the operator to specify the value of Key1 used to
decrypt traffic being received from the Satellite Interface.
Allows the operator to specify the value of Key2 used to
decrypt traffic being received from the Satellite Interface.

Table 13-21. CIM SMTP OIDs

Description
Specifics user's outgoing SMTP server's IP address.
Specifics the SMTP Domain of the mail server.
Specifies the SMTP destination user name.
231
Rev. 2
CD/CIM550.IOM
