CiM-550 IP Enabled Satellite Modem
SNMP interface
CiM550 Alarms and Faults SNMPv2 notifications:
cim550ModemUnitFaultsTrap
cim550ModemTxTrafficFaultsTrap
cim550ModemRxTrafficFaultsTrap
13.4.1.9 C M SNMP T
I
OID
cimSnmpTrapDestinationIpAddress
cimSnmpTrapCommunity
cimSnmpTrapVersion
C
RAP ONFIGURATION

Table 13-23. CIM SNMP Trap COnfiguration OIDs

1.3.6.1.4.1.6247.5.1.9.0.624751
1.3.6.1.4.1.6247.5.1.9.0.624752
1.3.6.1.4.1.6247.5.1.9.0.624753
Description
Specifies where the trap should be sent to. This is
usually the IP address of a network management
application (such as HP Openview or Castlerock
SNMPc). It could also be the IP address of a trap
ringer console (such as MG-SOFT MIB Browser).
Community name that is sent with the trap. This
community name is checked by the network
management application or MIB browser to
determine if it should accept or discard the trap
being sent to it.
Tells the agent if it should send out version 1 or
version 2 traps. The trap formats differs depending
on which version is used but contain the same type
of information. The choice of which trap version to
use should depend of which SNMP version the
managing application is expecting. The OID can
be sent to the following values:
1 SNMPv1
2 SNMPv2
