CiM-550 IP Enabled Satellite Modem
Remote Control
Parameter Command Arguments for
Command or
Type (Instruction
Response to
Code and
Query
qualifier)
Faults N/A 5 bytes,
and first 3 bytes
Status alpha-numerical
4th and 5th
bytes, value of 0
or 1
Description of arguments
(note that all arguments are ASCII numeric
codes, that is, ASCII codes between 48 and 57)
b defines the IF band, with 1 = 70MHz, 2 =
140MHz
c defines RX only, with 1 = RX/TX, 2 = RX only.
Example: EID=455011 (CiM-550, Rate 3/4 Turbo
Codec, 70 MHz band, RX/TX)
Query only. Unit returns the current fault and status
codes for the Unit (hardware), Tx Traffic and Rx
Traffic, in the form abcde, where:
a = Unit fault status, b = Tx Traffic status,
c = Rx Traffic Status, d = Change in Fault Status
since last poll (0 = none, 1 = change), e = Change
in Unit Configuration since last poll (0 = none, 1 =
change)
Unit faults:
0 = No faults
1 = Power supply fault, 5 volts
2 = Power supply fault , 12 volts
3 = Power supply fault, -5 volts
4 = Power supply fault, 18 volts
5 = Power supply fault, -12 volts
6 = RAM load fail
7 = Tx synthesiser lock
8 = Rx synthesiser
9 = Power cal Checksum error
A = FPGA main chain load fail
B = Turbo FPGA load fail
C = CiM IP Module Fail
Tx Traffic status:
0 = Tx traffic OK
79
Response to Command Query
(target to controller)
(Instruction
Code and
qualifier)
N/A FLT?
Rev. 2
CD/CIM550.IOM
Response to
query
(target to
controller)
FLT=abcde (see
description for
details of
arguments
