CiM-550 IP Enabled Satellite Modem
Front Panel Menus
4.1.6.2 SELECT\INFO\RX
Rx: 70.0000
B R3/4
The information displayed here is as follows:
Top line:
Bottom line: Demodulation type (Q = QPSK, O= OQPSK, B = BPSK)
4.1.6.3 SELECT\INFO\BUFF
BUFFER: ENABLED (TX=RX)
SIZE: +/-4096 BITS
DISPLAY
512.000 SEQ
D
BUFF +/-23k I
Receive Frequency
Receive Data Rate
FEC Decoder type (VIT = Viterbi, SEQ = Sequential,
VRS=Viterbi + Reed-Solomon, SRS=Sequential + Reed Solomon,
TUR = Turbo, UNC = uncoded)
Code Rate (shows blank in uncoded mode)
Descrambler state (D = Descrambler on, N = off)
Clocking Mode
Demod Sweep Acquisition range
RSI state (I = Receive Spectral Inversion on, N = off)
DISPLAY
SELECTIONS/DESCRIPTION
SELECTIONS/DESCRIPTION
This displays if the buffer is enabled or disabled,
shows the exact clocking mode (TX=RX, or TX<>
RX), and the buffer size.
45
Rev. 2
CD/CIM550.IOM
