Neoware c50 - Thin Client User Manual

Teemtalk 5.0 for unix
Hide thumbs Also See for Neoware c50 - Thin Client:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
®
TeemTalk
5.0
for Unix
User's Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Neoware c50 - Thin Client and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Neoware Neoware c50 - Thin Client

Summary of Contents for Neoware Neoware c50 - Thin Client

  • Page 1 ® TeemTalk for Unix User's Guide...
  • Page 2 Neoware, Inc. 3200 Horizon Drive King of Prussia, PA 19406 Tel: +1-610-277-8300 Fax: +1-610-771-4200 Email: info@neoware.com Neoware UK Ltd The Stables, Cosgrove Milton Keynes MK19 7JJ Tel: +44 (0) 1908 267111 Fax: +44 (0) 1908 267112 Email: teem-info@neoware.com...

  • Page 3: Software Support

    TeemTalk Software Support Telephone: +1-610-277-8300 Web: http://www.neoware.com/support/ Software Version 5.0.1 October 2004 Part number: TT5DM-5.0.1 Neoware UK Ltd, The Stables, Cosgrove, Milton Keynes, MK19 7JJ Tel: +44 (0) 1908 267111 Fax: +44 (0) 1908 267112 TeemTalk © 1988-2004 Neoware UK Ltd, All Rights Reserved. This product includes software developed by the OpenSSL Project for use in the OpenSSL Toolkit.
  • Page 4 The material in this user's guide is for information purposes only and is subject to change without notice. Neoware UK Ltd accepts no responsibility for any errors contained herein. Trademarks TeemTalk is a registered trademark of Neoware UK Ltd. ADDS Viewpoint A2 is a trademark of Applied Digital Data Systems Inc. D100, D200 and D410 are trademarks of Data General.

  • Page 5: Table Of Contents

    Contents Contents Introduction ............1-1 What Is TeemTalk for Unix ? ............1-1 The X Window System & TeemTalk ..........1-1 About This User's Guide ............... 1-3 Terms & Conventions ..............1-5 Installing TeemTalk On UNIX Based Products 2-1 Operating System Requirements ........... 2-1 Installing From CD ...............
  • Page 6 Contents Getting Started..........3-1 Loading TeemTalk ................. 3-1 Running TeemTalk In The Background ........... 3-2 Quitting TeemTalk ................. 3-3 Host Communications ..............3-3 Initiating A Telnet Session ..............3-3 Serial Connection ................3-4 Selecting The Terminal Emulation ..........3-6 Viewdata Mode ................. 3-9 Selecting &...
  • Page 7 Contents Hotspots ............6-1 Using Hotspots ................6-1 Defining Hotspots ................6-2 Print Facilities ........... 7-1 Selecting The Print Destination ............ 7-1 Troubleshooting The UNIX Print System........7-5 Setup Menus ............. 8-1 Selecting & Closing Menus ............8-1 Using The Menus ................8-2 Dialog Boxes .................
  • Page 8 Contents Attribute Settings ................8-74 Mouse Button Actions ..............8-77 Help Menu ..................8-79 DEC VT Emulations .......... 9-1 Introduction ................... 9-1 Keyboard Mapping ................ 9-1 The Status Bar ................9-8 BQ 3107 Emulation ......... 10-1 Introduction ................. 10-1 The Status Bar ................10-1 Keyboard Mapping ..............
  • Page 9 Contents The Status Line ................13-4 Keyboard Mapping ..............13-6 Record & Playback Keystrokes Facility ........13-11 Recording Keystrokes ..............13-11 Playback Keystrokes ..............13-12 Error Codes ..................13-12 IBM 5250 Emulation ........14-1 Introduction ................. 14-1 Running The Emulation............... 14-1 Network Virtual Terminal Mode ..........
  • Page 10 Contents Siemens 97801 Emulation ......18-1 Introduction ................. 18-1 Keyboard Mapping ..............18-1 Stratus V102 Emulation ........19-1 Introduction ................. 19-1 The Status Line ................19-1 Keyboard Mapping ..............19-2 TA6530 Emulation ........... 20-1 Introduction ................. 20-1 The Status Line ................20-1 Operating Modes .................
  • Page 11 Contents IBM File Transfer ..........23-1 Introduction ................. 23-1 Disabling Host Messages ............23-1 Sending & Receiving Files ............23-2 Ind$File Settings ................. 23-4 Private Profile File Entries ............23-6 FTP File Transfer ..........24-1 The Transfer Procedure .............. 24-1 Menu Descriptions ..............

  • Page 12: Product Specification D

    Contents Sending Text To The Serial Port ........... C-10 Reading Text From A File ............. C-11 Insert Delay ..................C-11 Product Specification ........D-1 Contents-8...

  • Page 13: Introduction

    Introduction Introduction This chapter introduces the TeemTalk for Unix terminal emulation software and describes the scope of this User's Guide. What Is TeemTalk for Unix ? TeemTalk is the essential connectivity tool for X Window based UNIX environments, enabling non-X based applications to be run in the X environment. TeemTalk provides precise emulation of a wide range of industry standard text and graphics terminals with impressive additional features formulated to increase productivity and reduce network loading.
  • Page 14 Introduction Each window displayed by TeemTalk is, in effect, a separate 'terminal'. Several terminal emulation windows may be displayed simultaneously on the same display server, all running different programs, but only one window may be active at any one time. Relationship Between TeemTalk &...

  • Page 15: About This User's Guide

    Introduction About This User's Guide This User's Guide describes how to install and use TeemTalk for Unix. It assumes the reader is familiar with the X Windows environment and the terminals that TeemTalk emulates. Chapter 1: Introduction Introduces TeemTalk and describes the scope of this User's Guide and various conventions used.

  • Page 16: Mdis Prism Emulations

    Introduction Chapter 12: HP700/92 Emulation Describes features of the Hewlett Packard 700/92 emulation. Chapter 13: IBM 3270 Emulation Describes features of the IBM 3270 emulation. Chapter 14: IBM 5250 Emulation Describes features of the IBM 5250 emulation. Chapter 15: IBM 3151 Emulation Describes features of the IBM 3151 emulation.

  • Page 17: Key Reference Numbers

    Introduction Appendix A: Key Reference Numbers Lists the reference numbers assigned to keys on the British keyboard. Appendix B: Keysyms Describes the use of virtual keysyms and lists all the valid keysyms that may be used to define the function of keys. Appendix C: Virtual Key Names Lists all the virtual key names that enable you to include a specific key function in a user definition for key macros, soft...
  • Page 18 Introduction Notes...

  • Page 19: Installing Teemtalk On Unix Based Products

    Installing TeemTalk On UNIX Based Products Installing TeemTalk On UNIX Based Products This chapter describes the procedure for installin TeemTalk on UNIX based products and how to install fonts on various X terminals. Operating System Requirements The table below shows the operating system versions that are required for each machine type in order for TeemTalk to function correctly, and the tape device that is to be specified when extracting TeemTalk from the supplied media.

  • Page 20: Installing From Cd

    Installing TeemTalk On UNIX Based Products Installing From CD To install TeemTalk from the CD: 1. Log in as root, change to the root directory of the CD and run the TeemTalk installation script. ./install 2. When prompted, specify the product type and Unix system that you are installing to.

  • Page 21: Creating A Licence Key File

    Installing TeemTalk On UNIX Based Products 5. Refer to the section Installing Fonts On X Terminals later in this chapter for converting fonts if you are using an X terminal. 6. Having verified the installation, all files can be deleted from the temporary directory created in step 1.

  • Page 22: Managing Teemtalk Licence Keys

    Installing TeemTalk On UNIX Based Products Managing TeemTalk Licence Keys For each X display (workstation or terminal) on which TeemTalk is to be used there is a single 12 digit licence key required which is based on the Internet (IP) address of the given X display.

  • Page 23: Licence Manager Errors

    Installing TeemTalk On UNIX Based Products Licence Manager Errors xteemx340: Cannot process host name <display name>... The name of the Display to which TeemTalk is trying to attach cannot be resolved. This is probably because the name of the Display is not included in the /etc/hosts file.

  • Page 24: Installing Fonts On X Terminals

    Installing TeemTalk On UNIX Based Products Installing Fonts On X Terminals The standard TeemTalk installation will convert the Bitmap Distribution Format (BDF) fonts supplied with TeemTalk to the format used by the workstation on which TeemTalk is being installed. When TeemTalk is to be displayed on X terminals the format of the converted fonts may not be compatible with the X terminal.

  • Page 25: Tektronix Tekxpress X Terminals

    Installing TeemTalk On UNIX Based Products catalogue = ibm:/usr/lib/X11/ncd/fonts/misc, /usr/lib/X11/ncd/fonts/ibm-snf Ensure that the directory in which the TeemTalk fonts have been installed is included in this configuration entry. Tektronix TekXpress X Terminals Font Format The TekXpress X terminals can read a number of different formats including: Portable Compiled Fonts (PCF), the standard format used in X11R5.

  • Page 26: Terminals From Other Vendors

    Installing TeemTalk On UNIX Based Products HP Server Natural Format (SNF) prior to X11R5 The HP specific snf fonts can be created by modifying the bdftosnf statement in the install script to: xtbdftosnf and the mkfontdir statement to: xtmkfontdir Both of these utilities are supplied on the HP X terminal boot tape and are located in the /usr/lib/X11/700x directory.

  • Page 27: Installation Stages

    Installing TeemTalk On UNIX Based Products Common problems experienced during this stage of the installation are: There is only one file on the tape and that is called readtape ! After extracting the readtape utility, the tape is positioned at the start of the second tape block.
  • Page 28 Installing TeemTalk On UNIX Based Products 2. The installation must be conducted under the window system which TeemTalk is to be run in. Several environment variables and file search paths are used and these are only set when the window system is running. The installation also uses several X Window utilities which will only work when the X Window system is running.

  • Page 29: Testing The Installation

    Installing TeemTalk On UNIX Based Products Testing The Installation TeemTalk should now be run up and work perfectly - if however you get the error message, Cannot Load Font..., then the font installation has failed. The following tips may be useful: The installation is designed to load the fonts in the format required by the workstation that TeemTalk is being loaded onto.

  • Page 30: Troubleshooting

    Installing TeemTalk On UNIX Based Products Troubleshooting This section describes what you should do if you encounter any of the following error messages during the installation process. Command not found ..(or similar) As it suggests the conversion program cannot be found, reasons may be: The file search path does not include the directory in which the conversion program exists.
  • Page 31 Installing TeemTalk On UNIX Based Products Updating the font database. In each font directory there is a database type file which contains a summary of all the fonts in that directory. When new fonts are moved to the directory the database also has to be updated. Motif Servers: The installation script uses the mkfontdir utility.
  • Page 32 Installing TeemTalk On UNIX Based Products Notes 2-14...

  • Page 33: Getting Started

    Getting Started Getting Started This chapter describes how to run TeemTalk and configure it for compatibility with your hardware and the application. Loading TeemTalk To load TeemTalk, enter one of the following program names at the system prompt: xteemx340 for TeemTalk supporting the graphics emulations. xteemx320 for TeemTalk without the graphics emulations.

  • Page 34: Running Teemtalk In The Background

    Getting Started Running TeemTalk In The Background More than one instance of TeemTalk can be run at the same time by entering one of the following lines at the prompt in a TeemTalk window: xteemx340 any options & xteemx320 any options & where any options can be any of the command line options listed in the Resources &...

  • Page 35: Quitting Teemtalk

    Getting Started Quitting TeemTalk You can quit an instance of TeemTalk by clicking File in the menu bar and selecting Quit in the menu, or by using functions provided by the Window Manager. On UNIX workstations, TeemTalk will also be exited when you log out, for example by typing Ctrl + D (C shell) while the pointer is within the window.

  • Page 36: Serial Connection

    Getting Started Clicking the Configure or Telnet Options buttons will display additional options which are described in the sections Telnet Options, SSL Connection Settings and SSH Connection Settings in the Setup Menus chapter. A list of hosts currently available for connection will be displayed in the Connect To box on UNIX based systems.
  • Page 37 Getting Started other options in this dialog box only apply if TeemTalk is to communicate with a host via an RS232 serial port. If TeemTalk is to communicate to a host via the serial port, you must set the baud rate, stop bits, parity and flow protocol to match that of the host to which you will be communicating.

  • Page 38: The Status Line

    Getting Started Selecting The Terminal Emulation When you load TeemTalk for the first time, the DEC VT400 (7-bit) emulation will be running by default. The current emulation can be changed in one of two ways, either from the status line or by using a setup dialog box. When an indicator status line with six buttons is displayed at the bottom of the window, you can change the current DEC VT terminal emulation to any other DEC VT terminal emulation (VT52, VT100, VT400 7-Bit or VT400 8-Bit) by clicking the button indicating the current...

  • Page 39: Keyboard Mapping

    Getting Started The AT 386 emulation provides compatibility with software designed to drive the AT&T AT 386 terminal. The AT&T4410 emulation provides compatibility with software designed to drive the AT&T Dataspeed 4410 terminal. Refer to the AT&T 4410 Emulation section later. The BQ3107 emulation provides compatibility with software designed to drive the Bull BQ 3107 terminal.
  • Page 40 Getting Started The MDI P9 emulation provides compatibility with software designed to drive the McDonnell Douglas Prism-9 terminal. The PT250 emulation provides compatibility with software designed to drive the Prime PT250 terminal. Refer to the PT250 Emulation chapter for details. SCO-CONSOLE is an emulation of the SCO UNIX box.

  • Page 41: Viewdata Mode

    Getting Started Graphics Emulations The 4010/4014 emulation enables you to run applications written for the Tektronix 4010 and 4014 terminals. The Regis emulation enables you to run applications written for the DEC VT340 terminal in ReGIS mode. The VT640 emulation enables you to run applications written for the Retrographics VT640 terminal.
  • Page 42 Getting Started characters for the equivalent button on the screen. These are followed by the definition line which contains an escape sequence by default. Each definition can contain up to 50 ASCII characters. To program an f-key, press the F1 key to move the cursor to the relevant line and use the cursor keys to move from one section of the line to another.

  • Page 43: Selecting & Using Window Elements

    Getting Started Selecting & Using Window Elements The TeemTalk window consists of various elements which are described in the following sections. The Title Bar The title bar displays the name of your version of TeemTalk software by default. You may change the title displayed by using the title resource or -title command line option followed by a space then the title to be assigned.

  • Page 44: Window Resize Commands

    Getting Started Window Resize Commands The menu bar includes two commands labelled < and > which enable the window size to be decreased or increased, respectively. When the < command is clicked, TeemTalk will scan a list of known fonts and select the next smallest font to that currently being used.

  • Page 45: The Dec Vt Status Line

    Getting Started Scrolling Using The Keyboard When you are running one of the DEC 'VT' terminal emulations, you can scroll vertically by holding down the Ctrl key and pressing the Up or Down Cursor keys. When you are running one of the DEC 'VT' terminal emulations, it is possible to make the width of display memory larger than the width of the window by using the Page Width option in the VT/ANSI/ SCO Settings dialog box.

  • Page 46: The Soft Buttons

    Getting Started different DEC VT alpha terminal emulation mode without having to display the Emulation Settings dialog box, which will be updated automatically with the new setting. Button 5: Indicates whether you are Online to the host or in Local mode. Clicking the button will toggle between the two modes.

  • Page 47: The Emulation Workspace

    Getting Started The Emulation Workspace The emulation workspace is the area which emulates the display of the terminal specified in setup (the DEC VT400 terminal by default) and where work is carried out with an application. The number of text lines displayed in the emulation workspace is set to 24 lines with an indicator status line on the 25th line by default.
  • Page 48 Getting Started Notes 3-16...

  • Page 49: Keyboard Configuration

    Keyboard Configuration Keyboard Configuration This chapter describes how to configure TeemTalk for your particular keyboard, remap key functions and compose special characters. Introduction TeemTalk maps the keyboard to be as near as possible to the terminal being emulated. Illustrations showing the mapping of functions on Enhanced AT, Sun 5, Sun 4 and HP 9000 keyboard layouts are shown in each terminal emulation chapter.

  • Page 50: Keyboard Nationality

    Keyboard Configuration Keyboard Nationality The keyboard nationality is set to North American by default. You can specify a different nationality in the Emulation Settings dialog box which is displayed by selecting Settings in the menu bar then Emulation..It is important that the setting of the Keyboard Language option matches that of the keyboard being used, otherwise the characters displayed may not match the legends on the key caps.

  • Page 51: Changing The Function Of A Key

    Keyboard Configuration You can find the keysym value of a key by placing TeemTalk in debug mode using the -debug command line option or debugMode resource, then pressing a key or key combination. The following information will be displayed when the F2 key on a Sun 4 keyboard is pressed: Keycode = 13, State = 0, Keysym = 65471 The Keysym value can be directly used in Translation tables as shown in the following...
  • Page 52 Keyboard Configuration Translation Resource Examples The following example shows how to use the Translations resource to modify the translation table so that the Compose Character function is assigned to the key that has the keysym Meta_R. xteemx340*vt220.Translations: #override \n\ <Key>Meta_R: value(-166) This will cause the line <Key>Meta_R: value(-166) to be added to the beginning of the standard translation table.

  • Page 53: Compose Character Sequences

    Keyboard Configuration Compose Character Sequences Compose character sequences can be used to generate codes for characters not shown on your keyboard when you are in VT320 mode. The characters that can be composed depend on the setting of the Multinational Mode and Preferred Font options in the Emulation Settings dialog box.
  • Page 54 Keyboard Configuration The following tables use several conventions: The keys bearing the characters used to compose a special character may be pressed in any order unless (in order) is specified. (DEC Multinat.) indicates that the character can only be composed if the Multinational Mode option in the Emulation Settings dialog box is selected and the DEC MCS option is unselected.
  • Page 55 Keyboard Configuration COMPOSE CHARACTER SEQUENCES feminine ordinal " ª ¨ space quotation mark indicator double open « < < number sign angle brackets (Multinational) ° ' space apostrophe degree sign ° space (National) plus or ± commercial at minus sign (Multinational) superscript 2 (National)
  • Page 56 Keyboard Configuration COMPOSE CHARACTER SEQUENCES (continued) Û Ä A " ¨ A A umlaut U circumflex ° Ü Å U " ¨ U A ring U umlaut (degree sign) Y umlaut Ÿ Æ Y " ¨ Y A E diphthong (DEC Multinat.) (in order) German small...
  • Page 57 Keyboard Configuration COMPOSE CHARACTER SEQUENCES (continued) soft (syllable) ó — o acute hyphen (Latin-1) registered trade- ô o circumflex mark (Latin-1) macron õ – o tilde (Latin-1) three quarters ö o " ¨ o o umlaut (Latin-1) (in order) division sign o e diphthong œ...
  • Page 58 Keyboard Configuration Notes 4-10...

  • Page 59: Mouse Functions

    Mouse Functions Mouse Functions This chapter describes the special functions assigned to the mouse buttons by TeemTalk and how to redefine the buttons. Introduction TeemTalk assigns a variety of special functions to the mouse buttons. Each button can be used to action up to five functions when pressed in conjunction with modifier keys. The following table lists the functions assigned to each button and key combination by default.

  • Page 60: Graphic Copy & Paste

    Mouse Functions The default method for selecting text is as follows. Place the cursor at the start of the text to be copied, hold down the Left mouse button (with Shift if a rectangular area is to be selected) then drag the cursor across to the end of the required text. Releasing the mouse button will cause the selected text to be saved in the global cut buffer.

  • Page 61: Send Keyword

    Mouse Functions Hotspots are supported in ALL terminal emulation modes. TeemTalk provides a set of default hotspot keywords for each mode. These relate to key functions specific to the emulation. For example, in VT320 mode you can click on the word Help displayed on the screen and TeemTalk will execute the function associated with the Help key.
  • Page 62 Mouse Functions You can also enter a definition of your own in the text box associated with each button and key combination. Definitions are entered in the same way as for keyboard macros and soft buttons, as described in the Setup Menus chapter. The setting of the Highlight When Actioned option determines whether or not a visual indication is given that a function has been actioned when a hotspot is clicked.

  • Page 63: Hotspots

    Hotspots Hotspots This chapter describes the hotspot facility which enables functions to be performed by clicking on keywords displayed on the screen. Using Hotspots TeemTalk incorporates a user-definable hotspot facility which enables you to invoke a function by clicking the mouse pointer over a keyword displayed on the screen. For example, an application may display information relating to keys you can press to perform a particular function.

  • Page 64: Defining Hotspots

    Hotspots Defining Hotspots Hotspot keywords and associated functions are specified in a text file which has the same name (and is in the same directory) as the current save settings file but with the extension .hot instead of .nv. For example, the default hotspot definitions supplied with TeemTalk (with graphics emulations) are stored in the file teemx340.hot.

  • Page 65: Entering Control Characters

    Hotspots The function that will be performed when the keyword is selected is specified in the same way as for key macros, soft buttons and script language programming. Entering Control Characters You can enter a control character in a keyword definition either as the control key character equivalent or the decimal value of the ASCII character.
  • Page 66 Hotspots To define a keyword so that it will perform the same function as pressing a sequence of keys one after the other, enter each virtual key name in the order required, enclosing each name with the < and > characters. Each enclosed virtual key name must immediately follow the previous enclosed virtual key name with no spaces.

  • Page 67: Print Facilities

    Print Facilities Print Facilities This chapter describes how to use the facilities provided by TeemTalk for specifying where print data is directed, and also provides a useful debugging guide for the UNIX print system itself. Selecting The Print Destination TeemTalk has the ability to print to :- 1.
  • Page 68 Print Facilities When the NULL string is specified, the printer device is selected using the Printer Setup dialog box, which is displayed from the File menu. Note that the Printer Setup option in the File menu will be disabled if either of these commands are used to specify where print data is to be directed.
  • Page 69 Print Facilities To select a printer, just click on the name in the Available Printers list box then click Ok. Further print requests (e.g. Autoprint or Print Screen) will be directed towards that printer. Any error messages from the UNIX print service will appear in the window in which TeemTalk was invoked and/or in the system console.
  • Page 70 Print Facilities Note: A pathname can also be included if desired, otherwise the file will be placed in the directory from which TeemTalk was invoked, the user's current working directory. You can specify lp or lpr print options (described in your UNIX operating system manual) on the with options line.

  • Page 71: Troubleshooting The Unix Print System

    Print Facilities Troubleshooting The UNIX Print System Most of the information in the remainder of this chapter is documented in your operating system manuals, so if in difficulty refer to the manuals (especially as specific UNIX operating systems often have subtle differences to trap the unwary!). The UNIX print system varies according to the UNIX operating system that you are using.

  • Page 72: Troubleshooting Checklist

    Print Facilities If the file will print via this method then you should be able to print to the same printer within TeemTalk. If however the file does not print, look up the message from the lpq or lpstat com- mand (or any error message given when invoking lp or lpr) in your UNIX system administrator's guide.
  • Page 73 Print Facilities 7. Does the remote host have the lpd daemon running? Check using ps -aux | grep lpd (BSD) or ps -e | grep lpd (System 8. Have you set up the privilege files /etc/hosts.equiv and/or /etc/ hosts.lpd (BSD) using lpsystem (on most system V machines) on both ends of the printer system (the remote printer host and the local host)? Look at the files on both remote printer host and local for entries...
  • Page 74 Print Facilities Notes...

  • Page 75: Setup Menus

    Setup Menus Setup Menus This chapter describes the options available in the setup menus and dialog boxes. Selecting & Closing Menus Four menus labelled File, Edit, Settings and Help can be displayed from the menu bar by clicking on the relevant buttons. A menu is closed by moving the pointer away from the menu then clicking the left mouse button.

  • Page 76: Using The Menus

    Setup Menus Using The Menus Option Selection There are several ways of selecting or actioning the various options displayed in the menus. The quickest way is to click the option required. Another way is to place the pointer over the button on the first option, hold down the left mouse button then move the pointer up or down the menu until the button rests over the option required then release the left mouse button.

  • Page 77: Default Settings

    Setup Menus When there are more options that can be comfortably displayed in the dialog box, these will be shown in a list box with a scroll bar. The scroll bar functions in the same way as the scroll bar in the main window. To make a selection, display the required option in the list box then click the pointer on it so that it is highlighted.

  • Page 78: Menu Descriptions

    Setup Menus Menu Descriptions The following pages describe the options available in all the menus and associated dialog boxes. The descriptions begin by showing the menu or dialog box as it is displayed on the screen. The factory default setting is shown below each option title where applicable.

  • Page 79: Reset Terminal

    Setup Menus Reset Terminal This will reset the current terminal emulation mode. Save Settings This will save the current setup configuration so that it is reasserted when TeemTalk is subsequently reset or loaded, overriding any changes which have been made but not saved.
  • Page 80 Setup Menus A telnet session can be initiated from a dialog box while TeemTalk is running or by using resources or command line options. Note that TeemTalk must be configured so that it is running the required terminal emulation before initiating a telnet session. The Type list box is used to specify the type of host connection that is to be made: TCP/IP, SSH2 or SSL/TLS.

  • Page 81: Replay File

    Setup Menus The file for storing captured data may be selected either by clicking the pointer over the filename in the Files list box then clicking the Ok button, or by clicking the pointer in the Selection text box, typing the directory path and name of the file, then clicking The Filter text box enables you to select the directory for display in the Directories list box.
  • Page 82 Setup Menus To select a printer, just click on the name in the Printers Available list box then click the Ok button. Further print requests (e.g. Autoprint or Print Screen) will be directed towards that printer. Any error messages from the UNIX print service will appear in the window in which TeemTalk was invoked and/or in the system console.
  • Page 83 Setup Menus You can specify lp or lpr print options (described in your UNIX operating system manual) in the with options text box. The Graphic Printer Driver setting specifies how the print data is formatted. The default setting /usr/bin/X11/xpr will convert the xwd (X window dump) format data into postscript.

  • Page 84: Print Screen

    Setup Menus to the printer when the cursor moves to the next line. Auto print mode lets you print each line as it is received from the host. Selecting Controller will enable the host to to send text directly to the printer, without displaying it on the screen. Refer to the Print Facilities chapter for more information on printing.

  • Page 85: Script Recorder

    Setup Menus Stop Auto Print This will disable auto print mode when Start Auto Print has been enabled. Run Script... This option will display a dialog box similar to that shown for the Capture File option in which you can specify the name of a script file to run. You can cancel the script file while it is running by selecting the Cancel Script option.

  • Page 86: Telnet Options

    Setup Menus Telnet Options This dialog box is displayed when you click the Telnet Options button in the New Connection dialog box. Note that the options available and the default settings depend on the current terminal emulation. The '3270' and '5250' options are only applicable when running the IBM 3270 or IBM 5250 emulations, respectively.
  • Page 87 Setup Menus Suppress TN3270E When running the IBM 3270 emulation, the setting of this option determines whether or not support of TN3270E is suppressed. When this option is not selected (i.e. TN3270E is not suppressed), additional options are available by clicking the 3270 Options button.

  • Page 88: 3270 Options

    Setup Menus 3270 Options This dialog box is displayed by clicking the 3270 Options button in the Telnet Options dialog box when TN3270 is not suppressed. Connect This specifies the name of the device which the server will be requested to assign to the Telnet session;...
  • Page 89 Setup Menus When you achieve a TN3270E connection, the LU device name that you are con- nected as will be displayed on the status line. If the specified device is rejected by the server or host, then an error message box will be displayed indicating the reason. Associate This is available when the Model option in the IBM 3270 Settings dialog box is set to 3287-1 (a printer).

  • Page 90: 5250 Options

    Setup Menus 5250 Options This dialog box is displayed by clicking the 5250 Options button in the Telnet Options dialog box when TN5250 is not suppressed and the Model option in the IBM 5250 Settings dialog box is not set to 3812-1 (a printer). Refer to the next section for 5250 Printer Options.
  • Page 91 Setup Menus Where a device name collision occurs (i.e. the device name is already in use on the host) the host will ask again for the device name during the same connection. In this case TEST1, TEST2, ... may all be tried in one connection until the host accepts one, or all possibilities have been tried.

  • Page 92: 5250 Printer Options

    Setup Menus 5250 Printer Options This dialog box is displayed by clicking the 5250 Options button in the Telnet Options dialog box when TN5250 is not suppressed and the Model option in the IBM 5250 Settings dialog box is set to 3812-1 (a printer). Device Name Specifies the name of the printer device.
  • Page 93 Setup Menus Mfg. Type and Model Specifies the manufacturer, type and model of the printer. The entry must exactly match an AS400 printer type string, including the * (asterisk) character. The following valid entries are for the IBM AS/400 V3R1. Note that the list can change according to AS/400 settings.
  • Page 94 Setup Menus Formfeed This is always set to Don't Report. The Paper Source 1 option is used to specify the paper format to be used. Paper Source 1 & 2 These options specify the paper format to be used. The possible settings are: Don't Report No value returned.
  • Page 95 Setup Menus ASCII 899 Support Specifies whether the single-byte printer has ASCII code page 899 installed. Selecting Don't Report will cause no value to be returned. WSCST Name Specifies the name of the object containing pointers to the work station customizing tables.

  • Page 96: Ssl Connection Settings

    Setup Menus SSL Connection Settings The optional SSL (Secure Sockets Layer) protocol enables authenticated and encrypted communication between clients and servers. Before anyone can connect to a server the system administrator must make available a copy of the root certificate used to sign the server’s identity certificate and the number of the telnet port the server is listening on.

  • Page 97: Error Messages

    Setup Menus 7. In the New Connection dialog box, select the host to connect to in the Connect To list box. 8. Click the Connect button. TeemTalk will attempt to connect to the host. If this is unsuccessful it will display an error message (see below). All the information entered in the SSL Connection dialog box is stored in the .nv file on a per session basis.

  • Page 98: Ssh Connection Settings

    Setup Menus SSH Connection Settings The optional SSH (Secure Shell) client/server protocol is used to encrypt and transmit data securely over a network, with authentication (proof of client identity) provided by a password and/or key. TeemTalk sets the telnet host port number to 22 by default. To make an SSH connection: 1.
  • Page 99 Setup Menus Key File Authentication Key authentication uses a randomly generated pair of keys, one private, one public, consisting of unique strings of binary data. A copy of the public key is placed in all the accounts to be accessed on the SSH server machines. Your private key, which is protected using a Passphrase, is stored on your local SSH client machine.

  • Page 100: Password Authentication

    Setup Menus Enter a passphrase and then a pair of keys will be generated. The private key is encrypted and stored in a file with the extension .key. The public key is stored in two files, one in OpenSSH format and one in Draft SSH2 format. Password Authentication Password authentication enables you to use your login password as proof of identity.

  • Page 101: Edit Menu

    Setup Menus Edit Menu Graphics Copy Mode The Graphics Copy Mode options are used in conjunction with the graphics copy facility provided by TeemTalk. The graphics copy facility enables you to copy any part of the TeemTalk display (text and graphics) and paste the information in any TeemTalk window.

  • Page 102: Settings Menu

    Setup Menus Settings Menu The Language option enables you to select the language that will be used in all menus and dialog boxes. The following dialog boxes can be displayed from this menu. Note that the dialog boxes used to configure specific emulations can only be displayed when the relevant emulation is running.
  • Page 103 Setup Menus Wyse Settings - for configuring the Wyse emulations. IBM 3270 Settings - for configuring the IBM 3270 emulation. IBM 5250 Settings - for configuring the IBM 5250 emulation. BQ 3107/7107 Settings - for configuring the BQ 3107 emulation. Keyboard Macros - for defining the function of keys and soft buttons.

  • Page 104: Emulation Settings

    Setup Menus Emulation Settings This dialog box is displayed by selecting Emulation in the Settings menu. Alpha Emulation Factory default: VT320-7 The setting of this option determines the current alpha emulation mode. The ADDS A2 emulation provides compatibility with software designed to drive the ADDS Viewpoint A2 terminal, as emulated by the Wyse WY-50/50+/60 terminals.
  • Page 105 Setup Menus DOC18 emulates VT220+ (DOC-18). It runs the VT300 8-bit emulation, sets the numeric keypad to application mode, sets the display to 25 lines and enables a special character set. The function of the keys F1 to F4 on the numeric keypad are mapped to the first four function keys in the set of F1 to F12 function keys, and F5 to F12 perform the same functions as the equivalent keys on the VT220 keyboard.
  • Page 106 Setup Menus The STRATUS V102 emulation provides compatibility with software designed to drive the Stratus V102 terminal. The TA6530 emulation provides compatibility with software designed to drive the Tandem 6526 and 6530 terminals. You must make a host connection using the Telnet facility supplied with TeemTalk in order for this mode to function correctly in block mode applications.
  • Page 107 Setup Menus Terminal ID Factory default: VT340 (with graphics), VT420 (no graphics) This specifies what is reported back to the host in response to a terminal identification request. (Note that not all features of the specified terminal may be supported.) The M2200 setting enables TeemTalk to be treated as a Microcolour M2200 series termi- nal.
  • Page 108 Setup Menus Display Control Codes Factory default: Unselected When selected, a representation of received control codes will be displayed on the screen instead of actioned. Multinational Mode Factory default: Selected The setting of this option determines the type of character set that is used. When Mul- tinational Mode is selected, a character set consisting of two tables of characters is used.

  • Page 109: Serial Settings

    Setup Menus Serial Settings This dialog box is displayed by selecting Serial in the Settings menu. Baud Rate Factory default: 9600 This option specifies the transmit and receive baud rates for the port selected for host communications. Stop Bits Factory default: 1 This option specifies the number of stop bits sent for each transmitted character.

  • Page 110: Serial Port

    Setup Menus Serial Port Factory default: Unspecified This option specifies the name of the serial port device which will be used for host communications when the Use Serial Port option is selected. Click the pointer on the line then enter the name of the device, for example: Sun: /dev/ttya /dev/tty0...

  • Page 111: Terminal Settings

    Setup Menus Terminal Settings This dialog box is displayed by selecting Terminal in the Settings menu. Cursor Type Factory default: Flashing Block This enables you to specify how the text cursor is displayed. Select from the following: Flashing Underline Static Underline Hidden Flashing Block Static Block...

  • Page 112: Greyscale Display

    Setup Menus When the option is selected, resizing the window will cause the number of visible lines to be increased or decreased to fill the new window size without adjusting the character size. When this option is unselected, resizing the window will cause TeemTalk to search a list of known fonts and select the one which allows the same number of rows and columns as before to fill the new window size.
  • Page 113 Setup Menus Local Echo Factory default: Unselected The setting of this option determines whether characters sent to the host are displayed at the same time, or only displayed if the host echoes them back. When local echo is enabled, TeemTalk will display each character as it is sent to the host. Jump Scroll Factory default: Unselected The setting of this option determines whether data is scrolled one or several lines at a...

  • Page 114: Tek Graphics Settings

    Setup Menus Tek Graphics Settings This dialog box is available in versions of TeemTalk that support graphics emulations. It can be displayed when running the 4010/4014 emulation by selecting Tek Graphics in the Settings menu. Gin Terminator Factory default: CR/EOT This option determines the termination character(s) that follow a GIN address trans- mission, and can be set to one of the following: CR/EOT GIN terminator (default)

  • Page 115: Vt/Ansi/Sco Settings

    Setup Menus VT/ANSI/SCO Settings This dialog box is displayed by selecting VT/ANSI/SCO in the Settings menu. The options available depend on the emulation you are running. Status Line Factory default: Indicator The last line in the window can be used to display a status line when running any of the DEC VT terminal emulations.
  • Page 116 Setup Menus Vertical VT420 Coupling Factory default: Selected The setting of this VT420 emulation option determines what happens when the application moves the cursor to a line not currently displayed in the window when the number of displayed lines is less than the page size. When selected, the display will automatically scroll vertically to keep the cursor in view.
  • Page 117 Setup Menus When unselected, the keys will generate characters corresponding to the legends on the keycaps (or their stored strings if they have been programmed). When this option is selected, the keys will generate control functions when pressed. Note: On some keyboards these keys act as both a numeric keypad and a cursor key block depending on the setting of a modifier, for example the Num Lock key.
  • Page 118 Setup Menus Answerback String Factory default: Unspecified This option enables you to specify the Answerback string that is sent to the host in response to an emulation enquiry command. The string may be up to 30 characters long. Concealed Factory default: Unselected Selecting this option will cause the Answerback string to be locked from change and displayed as asterisks.

  • Page 119: Hp700/92 Settings

    'echoes' them back. ENQ/ACK Pacing Factory default: Selected The setting of this option determines whether the Hewlett-Packard ENQ/ACK hand- shake is used or not. When selected, the host can send an ASCII ENQ (enquiry) control code at the end of transmission asking if the data has been processed, to which TeemTalk will reply by sending an ACKnowledge code when it has.
  • Page 120 Setup Menus EscXfer Factory default: Unselected The setting of this option determines whether escape sequences relating to the display are sent when the display memory is transferred to the printer. When unselected, escape sequences relating to the display are not sent to the printer. When selected, each line transferred to the printer will begin with an escape sequence to select the primary character set and stop any character enhancements.
  • Page 121 Setup Menus InhEolWrp (C) Factory default: Unselected The Inhibit End of line Wrap option determines whether characters wrap to the next line when the right margin is reached. When selected (i.e. inhibited), on reaching the right margin, the last character position will be overwritten with every new character received until a carriage return or other cursor movement command is issued.
  • Page 122 Setup Menus Typeahead Enabled Factory default: Unselected When TeemTalk is connected to an HP 3000, you normally have to wait for the host to send a prompt before you can enter new data at the keyboard, otherwise the data is ignored.
  • Page 123 Setup Menus Return Definition Factory default: ^M (i.e. CR) This option enables the function of the Return key to be defined. Up to two characters may be used to define the key. If a second character is a space, it will be ignored. To change the current definition, delete the definition displayed in the text box and type in the new one, either as the control key character equivalent or the decimal value of the ASCII character.

  • Page 124: Pt250 Settings

    Setup Menus PT250 Settings This dialog box is displayed by selecting PT 250 in the Settings menu. Block Mode Factory default: Unselected This option determines how data is transmitted to the host. When this option is unselected each character entered from the keyboard is immedi- ately sent to the host which processes it then echoes it back to the display.
  • Page 125 Setup Menus When unselected, the character set for the keyboard nationality specified in the Mode Settings dialog box is mapped to G0, the default character set mode (as indicated on the status line). In effect, national characters from the Additional character set are swapped with Standard (ASCII) characters to form the National set mapped to G0, so the Additional set contains the missing ASCII characters.
  • Page 126 Setup Menus Received LF is CR/LF Factory default: Unselected The setting of this option determines how the emulation interprets received line feed characters. Selecting it will cause a carriage return command to be appended to every line feed command received. Received CR is CR/LF Factory default: Unselected The setting of this option determines how the emulation interprets received carriage...

  • Page 127: Ta6530 Settings

    Setup Menus TA6530 Settings This dialog box is displayed by selecting TA 6530 in the Settings menu. Power On Mode Factory default: Conversational This option determines the operating mode that is in effect when the TA6530 emulation is entered after loading TeemTalk. Note: Changing the current setting will not take effect until you re- load TeemTalk, so you will need to save the new setting before exiting TeemTalk.
  • Page 128 Setup Menus the listed 128-byte increments, or, by setting this option to Off, the default size of 260 bytes. Status Border Factory default: Unselected This option enables you to display a thin border which separates the status line from the rest of the lines on the display. Return Function Factory default: Unselected This option specifies whether or not the function of the Enter key is defined by the...

  • Page 129: Ibm 3151 Settings

    Setup Menus IBM 3151 Settings This dialog box is displayed by selecting IBM 3151 in the Settings menu. Operating Mode Factory default: Echo The setting of this option determines how keyboard entered data is sent to the host and displayed on the screen. In Echo mode, keyboard entered data is sent only to the host.
  • Page 130 Setup Menus Turnaround Char Factory default: CR This option specifies the line turnaround character (LTC) that is generated when a Read command is received or one of the block data transmission keys is pressed. Note that selecting DC3 will disable the XON/XOFF inbound and outbound pacing charac- ters.
  • Page 131 Setup Menus Enter Key Factory default: Return This option enables you to specify whether the Enter key performs the same function as the Return key or the Send key. Return Key Factory default: Field This option specifies whether or not the cursor can enter a line within a protected field when the Return key is pressed.
  • Page 132 Setup Menus When selected, the cursor will automatically move to the beginning of the next line. Note that this will always be the case in block mode or in a formatted page regardless of the setting of this option. When unselected, the cursor will remain at the end of the current line and each new character sent to the display will overwrite the character already occupying the cursor position.

  • Page 133: Wyse Settings

    Setup Menus Wyse Settings This dialog box is displayed by selecting Wyse in the Settings menu. Note that some of the settings apply to the TVI 910+, TVI 920, TVI 925, ADDS A2 and HZ 1500 emulations in addition to the Wyse emulations. Also, some settings may not apply to the particular Wyse emulation currently running.
  • Page 134 Setup Menus The 1 + Rest setting will divide the display memory into two pages, the first containing the number of lines specified by the Lines option, the second containing all the remaining lines. Note that changing the page format will cause the entire display memory to be cleared, the cursor will move to the home position and the scroll margin will be reset.
  • Page 135 Setup Menus WPRT Attribute Factory default: Dim This option applies to all emulations and enables you to specify the appearance of write-protected characters on the display. They can be displayed in reverse video, dimmed or blinking. The WY-50+ and WY-60 emulations also support the underline and invisible attributes.
  • Page 136 Setup Menus When selected, a new page of memory will be displayed. Note: The other emulations do not support multiple pages, so the cursor moves according to the Auto Scroll option. DEL = DestBS Factory default: Unselected This option applies to the WY-50+ and WY-60 emulations and determines what effect an ASCII DEL character has on displayed characters.
  • Page 137 Setup Menus Colour Support Factory default: Unselected When this option is selected, TeemTalk will recognize an additional set of host com- mands which determine the colours used for the display. Wyse 350 colour commands will be recognized in all modes except Wyse 60, which will use Wyse 60 colour com- mands.

  • Page 138: Ibm 3270 Settings

    Setup Menus IBM 3270 Settings This dialog box is displayed by selecting IBM 3270 in the Settings menu. Model Factory default: 3278-2-E This specifies what is reported back to the host in response to a terminal identification request. (Note that not all features of the specified terminal may be supported.) It also determines the size of the display and whether or not extended attributes are supported when the current alpha emulation is set to IBM 3270.
  • Page 139 Setup Menus Print By Pass This option is available when the Model option is set to a printer. The Start Seq box enables you to enter the character or sequence of characters that initiate a print bypass. The end sequence that terminates the print bypass can be specified either by entering the actual characters in the End Seq box when Specify End Sequence is selected, or by specifying the number of characters that make up the end sequence in the End Length box when End On Non-Hex is selected.

  • Page 140: Ibm 5250 Settings

    Setup Menus IBM 5250 Settings This dialog box is displayed by selecting IBM 5250 in the Settings menu. Model Factory default: 3179_2 This specifies what is reported back to the host in response to a terminal identification request. (Note that not all features of the specified terminal may be supported.) The terminal types supported and their display characteristics are listed below.
  • Page 141 Setup Menus Ruler Line Style Factory default: Cross A rule can be displayed across the emulation workspace at the cursor position by holding down the modifier key Alt, Meta or Extend Char and pressing Page Down, which toggles it on and off. The setting of this option determines whether it is displayed as a horizontal rule, vertical rule or both (cross).

  • Page 142: Bq 3107 Settings

    Setup Menus BQ 3107 Settings This dialog box is displayed by selecting BQ 3107 in the Settings menu. Rendition Mode Factory default: VIP The setting of this option determines whether VIP or SDP display attributes are used. VIP Mode Factory default: 7760 The VIP mode can be set to 7700 or 7760.
  • Page 143 Setup Menus Message Row Factory default: At Row 25 The setting of this option determines whether the message row (Partition 0) is at the top or bottom of the display. Fill Character Factory default: Asterix When inserting or deleting characters, the setting of this option determines whether a Space or Asterisk character is displayed.
  • Page 144 Setup Menus Auto Wrap Tabbing Factory default: Unselected When the last unprotected field on the screen is filled, the setting of this option deter- mines whether or not the cursor automatically moves back to the first field on the screen. Function Keys The keys mapped as FKC1 to FKC12 on your keyboard can be programmed to send control sequences or messages when pressed.

  • Page 145: Keyboard Macros

    Setup Menus Keyboard Macros This dialog box is displayed by selecting Keyboard Macros in the Settings menu. Key Expansion Enabled Factory default: Selected This option specifies whether programmed keys on the keyboard can be expanded (i.e. transmit their programmed contents to the host) when pressed. When selected, a pro- grammed key will send its programmed string instead of its normal character.
  • Page 146 Setup Menus Program Key With Factory default: Soft Button Level 1 definitions correspond to functions found on a DEC VT320 keyboard as follows: Soft Button 1: Help Soft Button 7: Previous Soft Button 2: Soft Button 8: Next Soft Button 3: Find Soft Button 9: Soft Button 4:...

  • Page 147: Running A Script File

    Setup Menus When the definition is complete, decide if you wish the key or soft button contents to be saved so that it will be asserted each time TeemTalk is reset or loaded, then click the Program Volatile or Program NonVolatile button. Clicking the Program Volatile button will cause TeemTalk to only remember the definition until it is reset or exited.

  • Page 148: Attribute Settings

    Setup Menus Attribute Settings This dialog box is displayed by selecting Attributes in the Settings menu. This enables you to specify the colours used in the window and how text with attributes and graphics line styles (except ReGIS) are displayed. To change the way a screen element is displayed, select the relevant item from the Screen Element list box, for example, Bold for characters with the bold attribute.
  • Page 149 Setup Menus Colour and specify the foreground and background colours on the palettes. To display text assigned with an attribute with both attribute and a particular colour, select Colour, specify the foreground and background colours on the palettes and specify the applicable attribute(s) from the With Attribute list.
  • Page 150 Setup Menus Colours Cleared With Attribute Factory default: Selected The setting of this option determines whether or not the foreground and background colours are cleared to the default colours when an ANSI clear attributes command is received. Attributes Use Normal Background Factory default: Unselected This option only applies to the IBM 3270 and TA6530 emulations.

  • Page 151: Mouse Button Actions

    Setup Menus Mouse Button Actions This dialog box is displayed by selecting Mouse Button Actions in the Settings menu. This enables you to specify the function of mouse buttons 1, 2 and 3 when they are pressed on their own or in conjunction with modifier keys. You can assign up to five functions for each button.
  • Page 152 Setup Menus The Show Hotspots and Action Hotspots functions are described in the Hotspots chapter. The Send Keyword function is very similar to the hotspot feature. It enables you to send delimited text displayed on the screen to the host just by clicking on it. Delimiters are the same as for hotspots.

  • Page 153: Help Menu

    Setup Menus Help Menu Clicking the About TeemTalk button in the Help menu will display information on this version of TeemTalk. 8-79...
  • Page 154 Setup Menus Notes 8-80...

  • Page 155: Dec Vt Emulations

    DEC VT Emulations DEC VT Emulations This chapter describes features of the DEC VT terminal emulations. Introduction To run a DEC VT terminal emulation, display the Emulation Settings dialog box from the Settings menu and set the Alpha Emulation to one of the emulation options described below, then click OK.

  • Page 156: Normal Mode

    DEC VT Emulations Enhanced AT & Sun 5* Keyboard Layouts Normal Mode Note: The Sun 5 keyboard has additional keys not shown in this illustration but which are unaffected by TeemTalk.

  • Page 157: Dec Mode

    DEC VT Emulations Enhanced AT & Sun 5* Keyboard Layouts DEC Mode Note: The Sun 5 keyboard has additional keys not shown in this illustration but which are unaffected by TeemTalk.
  • Page 158 DEC VT Emulations Sun 4 Keyboard Layout Normal Mode...
  • Page 159 DEC VT Emulations Sun 4 Keyboard Layout DEC Mode...
  • Page 160 DEC VT Emulations HP 9000 Series Keyboard Layout Normal Mode...
  • Page 161 DEC VT Emulations HP 9000 Series Keyboard Layout DEC Mode...

  • Page 162: The Status Bar

    DEC VT Emulations The Status Bar A status line can be displayed on the last line in the window when running any of the DEC VT terminal emulations. An indicator status line is displayed by default on the 25th line the first time you load TeemTalk. You may choose not to display a status line, or enable a host-writable status line to be displayed instead.
  • Page 163 DEC VT Emulations Not Ready signifies that the printer is not ready to receive data for printing. Ready signifies that the printer is ready to receive data for printing. Auto signifies that the emulation is in Auto Print mode in which the current cursor line is sent to the printer when a command for the cursor to move to the next line is issued.
  • Page 164 DEC VT Emulations Notes 9-10...

  • Page 165: Bq 3107 Emulation

    BQ 3107 Emulation BQ 3107 Emulation This chapter describes the Bull BQ 3107 terminal emulation. Introduction To run the Bull BQ 3107 terminal emulation, display the Emulation Settings dialog box from the Settings menu and set the Alpha Emulation to BQ 3107, then click The Status Bar The status bar displayed along the bottom of the window will show the status of various operations.

  • Page 166: Keyboard Mapping

    BQ 3107 Emulation Field 7: This is used to display warning messages. Field 8: Not used. Field 9: Not used. Field 10: This will display P.DISCT when the printer is disconnected. Field 11: This will display OVERFLOW when there is a data overflow. Field 12: Indicates the current line and column position of the cursor relative to the top left corner of the display, which is L01:C01.
  • Page 167 BQ 3107 Emulation Enhanced AT & Sun 5* Keyboard Layout Note: The Sun 5 keyboard has additional keys not shown in this illustration but which are unaffected by TeemTalk. 10-3...
  • Page 168 BQ 3107 Emulation Sun 4 Keyboard Layout 10-4...
  • Page 169 BQ 3107 Emulation HP 9000 Series Keyboard Layout 10-5...
  • Page 170 BQ 3107 Emulation Notes 10-6...

  • Page 171: Dg410 Emulation

    DG410 Emulation DG410 Emulation This chapter describes features of the Data General D410 terminal emulation. Introduction The emulation of the Data General D410 terminal is entered by displaying the Emulation Settings dialog box from the Settings menu and setting the Alpha Emulation option to DG410.
  • Page 172 DG410 Emulation Enhanced AT & Sun 5* Keyboard Layout Note: The Sun 5 keyboard has additional keys not shown in this illustration but which are unaffected by TeemTalk. 11-2...
  • Page 173 DG410 Emulation Sun 4 Keyboard Layout 11-3...
  • Page 174 DG410 Emulation HP 9000 Series Keyboard Layout 11-4...

  • Page 175: Cursor Type

    DG410 Emulation Cursor Type This key enables you to change the appearance of the cursor. By default the cursor is displayed as a reverse video block. Pressing and releasing the Cursor Type key one or more times will cause the cursor display to change in the following order: Blinking underline Invisible cursor Blinking reverse video block...

  • Page 176: Key Codes

    DG410 Emulation Key Codes The following table lists the decimal value of codes generated when keys that emulate those found on the Data General keyboard are pressed alone or in conjunction with the Shift and/or Ctrl keys. Note that each code shown is the second code generated when the key or key combina- tion is pressed, the first always being the code RS (Hex 1E).

  • Page 177: Hp700/92 Emulation

    HP700/92 Emulation HP700/92 Emulation This chapter describes features of the Hewlett Packard 700/92 terminal emulation. Introduction The emulation of the Hewlett Packard 700/92 terminal is entered by displaying the Emulation Settings dialog box from the Settings menu and setting the Alpha Emulation option to HP70092.
  • Page 178 HP700/92 Emulation Enhanced AT & Sun 5* Keyboard Layout Note: The Sun 5 keyboard has additional keys not shown in this illustration but which are unaffected by TeemTalk. 12-2...
  • Page 179 HP700/92 Emulation Sun 4 Keyboard Layout 12-3...
  • Page 180 HP700/92 Emulation HP 9000 Series Keyboard Layout 12-4...

  • Page 181: Buttons & Function Keys

    HP700/92 Emulation Buttons & Function Keys The buttons along the bottom of the HP700/92 window, except for the middle button, indicate the current function of keys F1 through F8 on the keyboard, each key and equivalent button having several functions within the emulation. The buttons and equivalent function keys enable selection of various operating modes and display configurations.
  • Page 182 HP700/92 Emulation Modify All - F2 This is similar to the Line Modify F1 function described previously, the only difference being that the editing mode is not exited when Return or Enter is pressed. F2 and its equivalent button acts as a toggle key, switching the mode on or off. The setting may be saved by selecting Save Settings in the File menu.
  • Page 183 HP700/92 Emulation Terminal Test - F5 When this button or F5 key is pressed, the HP700/92 emulation will perform a self-test and display a test screen showing all the displayable characters. Memory Lock - F6 This enables data to be locked on the display so that it is not scrolled off the top of the window when display memory is full.

  • Page 184: Configuration Selection

    HP700/92 Emulation Note: If the XmitFnctn (A) option is selected in the HP70092 Settings dialog box, the button and F7 key will not deactivate Display Functions mode. Auto LF - F8 This button and the F8 key enables or disables Auto Line Feed mode. When enabled, a line feed command is automatically appended to every carriage return command generated from the keyboard.
  • Page 185 HP700/92 Emulation Device Modes - F1 Clicking this button or pressing F1 will cause the Device Modes function labels to be displayed. The keys F1 through F8 will function as described in the following section entitled Device Modes. To Ext Dev - F2 This toggle function determines whether data is sent to the printer or not.

  • Page 186: Device Modes

    HP700/92 Emulation Copy Line - F8 When a printer is connected and enabled by the To Ext Dev function, clicking this button or pressing F8 will cause a copy of the line containing the cursor to be sent to the printer. The cursor will move to the leftmost column on the next line when the line has been printed.

  • Page 187: Margins, Tabs & Start Column

    HP700/92 Emulation Log Bottom remains activated until either this button or F3 is pressed again, Log Top is activated, a reset is performed, or the emulation is exited. Log Top - F4 When the display memory becomes full and more data is received from the host or keyboard, lines of data from the top of the display are deleted to make way for the new data.
  • Page 188 HP700/92 Emulation Set Tab - F2 This function enables tab stops to be defined. To define a tab stop, move the cursor to the column to contain the tab and click this button or press F2. Note: Tab stops that do not lie within the left and right margins will be ignored when the Tab key is pressed.

  • Page 189: Key Programming

    HP700/92 Emulation To specify the right margin, place the cursor in the column for the margin location and click this button or press F6. The right margin can be reset to column 80 by pressing F7 (this will also reset the left margin to column 1). Note: Margins are disregarded when data is transferred from display memory to the host.

  • Page 190: Key String Treatment

    HP700/92 Emulation Key String Treatment Each f-key and button definition displayed in the menu consists of two lines. The first line begins with the f-key number followed by space then a one-character attribute field. This field will contain either an uppercase L, T or N. These characters indicate the following: The key string is executed locally.

  • Page 191: Character Display Attributes

    HP700/92 Emulation Key String Definition The second line of each f-key definition contains the character string that is to be displayed, executed, and/or transmitted to the host when the key or button is pressed. The string may contain alphanumeric characters, control characters, and explicit escape sequence characters entered when Display Functions mode is enabled by pressing F7 or the Display Functns button.
  • Page 192 HP700/92 Emulation label for the key, for example, Under in the first field and Line in the second for Under Line. Press Tab to move down to the next line. Press F7 to enable Display Functions mode then press Ctrl + [ together or the Esc key, followed by the charac- ters &d and the attribute character, which for underline is D.

  • Page 193: Ibm 3270 Emulation

    IBM 3270 Emulation IBM 3270 Emulation This chapter describes features of the IBM 3270 terminal emulation. Introduction The IBM 3270 emulator provides emulation of all four models of the IBM 3278 alphanumeric terminal and also supports the IBM 3287-1 printer. The terminal emulation supports Extended Attribute mode which allows different representation of highlighted fields and permits host definition of text colours.
  • Page 194 IBM 3270 Emulation Settings with the -E extension provide support for the following extended attributes: 3270 field attributes, extended highlighting (blink, flash and under- score, but not in combination), foreground colour, and query reply inbound structured fields. These attributes are also supported by the 3279. Click Ok to close the dialog box.

  • Page 195: Ibm 3287-1 Printer Support

    IBM 3270 Emulation IBM 3287-1 Printer Support TN3287 printing is supported by setting the Model option in the IBM 3270 Settings dialog box to 3287-1. When a new Telnet connection is made, the TeemTalk window display will change to show a message box which will indicate the current printer status.

  • Page 196: The Status Line

    IBM 3270 Emulation The Status Line The last line in the window is used to display status information in the form of symbols and alphanumeric characters. A coloured line separates status information from the rest of the display. Information is displayed in any of five regions within the status line as listed below.

  • Page 197: Do Not Enter

    IBM 3270 Emulation Readiness & System Connection This indicates that a Telnet session is running. This indicates that the protocol for communication between an application program and the IBM 3270 emulation is not system network architecture (SNA). This indicates that the current screen is a Network Virtual Terminal screen.

  • Page 198: Keyboard Mapping

    IBM 3270 Emulation Perform a cursor-select operation when the cursor is not in a valid cursor-select field. The keyboard can be unlocked and the indicator removed by pressing the Reset key. SYSTEM Indicates that you cannot enter any data because the applica- tion program has disabled the keyboard following an entry.
  • Page 199 IBM 3270 Emulation Enhanced AT & Sun 5* Keyboard Layout Note: The Sun 5 keyboard has additional keys not shown in this illustration but which are unaffected by TeemTalk. 13-7...
  • Page 200 IBM 3270 Emulation Sun 4 Keyboard Layout 13-8...
  • Page 201 IBM 3270 Emulation HP 9000 Series Keyboard Layout 13-9...
  • Page 202 IBM 3270 Emulation DEC LK201/LK250 Keyboard Layout 13-10...

  • Page 203: Record & Playback Keystrokes Facility

    IBM 3270 Emulation Record & Playback Keystrokes Facility The record/playback keystrokes facility enables you to eliminate repetitive operations by using the Fn keys to store, retrieve and display data. The Fn keys can store a total of 1500 keystrokes. A sequence of recorded keystrokes may be interrupted so that keystrokes can be entered manually before continuing with the recording or playback.

  • Page 204: Playback Keystrokes

    IBM 3270 Emulation Note: You can cancel the newly recorded keystrokes by pressing the Quit key. This cancellation does not affect the previously recorded keystrokes. 4. To finish and save the recording, press the Record key. Playback Keystrokes 1. Position the text cursor where the playback is to start. 2.
  • Page 205 IBM 3270 Emulation 9007 You pressed an invalid sequence key (e.g. Play) while performing the Record function. Remedy: Press the Reset key. 9010 While performing the Play function, you pressed an Fn key that does not have a keystroke assigned to it. Remedy: Press the Reset key.
  • Page 206 IBM 3270 Emulation Notes 13-14...

  • Page 207: Ibm 5250 Emulation

    IBM 5250 Emulation IBM 5250 Emulation This chapter describes features of the IBM 5250 terminal emulation. Introduction The IBM 5250 emulator provides emulation of 5250 type alphanumeric terminals, both monochrome (green/white plus attributes) and colour. Colours may be modified using the Attribute Settings dialog box. This emulation can be used for connection to an IBM AS/400, System/36 or System/38.

  • Page 208: Network Virtual Terminal Mode

    IBM 5250 Emulation 3180_2 Monochrome 24 x 80 and 27 x 132 3477_FC Colour 24 x 80 and 27 x 132 3477_FG Monochrome 24 x 80 and 27 x 132 3486_BA Monochrome 24 x 80 3487_HA Monochrome 24 x 80 3487_HC Colour 24 x 80...

  • Page 209: The Status Line

    IBM 5250 Emulation The Status Line The last line in the window is used to display status information in the form of symbols and alphanumeric characters. A coloured line separates status information from the rest of the display. Information is displayed in any of six regions within the status line as listed below.
  • Page 210 IBM 5250 Emulation Enhanced AT & Sun 5* Keyboard Layout Note: The Sun 5 keyboard has additional keys not shown in this illustration but which are unaffected by TeemTalk. 14-4...
  • Page 211 IBM 5250 Emulation Sun 4 Keyboard Layout 14-5...
  • Page 212 IBM 5250 Emulation HP 9000 Series Keyboard Layout 14-6...

  • Page 213: Record & Playback Keystrokes Facility

    IBM 5250 Emulation Record & Playback Keystrokes Facility The record/playback keystrokes facility enables you to eliminate repetitive operations by using the Fn keys to store, retrieve and display data. The Fn keys can store a total of 1500 keystrokes. A sequence of recorded keystrokes may be interrupted so that keystrokes can be entered manually before continuing with the recording or playback.

  • Page 214: Playback Keystrokes

    IBM 5250 Emulation Note: You can cancel the newly recorded keystrokes by pressing the Quit key. This cancellation does not affect the previously recorded keystrokes. 4. To finish and save the recording, press the Record key. Playback Keystrokes 1. Position the text cursor where the playback is to start. 2.

  • Page 215: Fax Image Support

    IBM 5250 Emulation 9007 You pressed an invalid sequence key (e.g. Play) while performing the Record function. Remedy: Press the Reset key. 9010 While performing the Play function, you pressed an Fn key that does not have a keystroke assigned to it. Remedy: Press the Reset key.
  • Page 216 IBM 5250 Emulation Notes 14-10...

  • Page 217: Ibm 3151 Emulation

    IBM 3151 Emulation IBM 3151 Emulation This chapter describes features of the IBM 3151 terminal emulation. Introduction The optional IBM 3151 emulation is based on the native mode of the IBM 3151 Model 11 terminal. You can run the emulation by displaying the Emulation Settings dialog box from the Settings menu and setting the Alpha Emulation option to IBM 3151.
  • Page 218 IBM 3151 Emulation ECHO (001,001) Field 1: Indicates the current operating mode. mode, keyboard entered data is displayed and processed lo- In BLOCK cally, allowing you to edit it before a block of data is sent to the host. mode, keyboard entered data is sent simultaneously to the host In CHAR and the display.

  • Page 219: Defining Function Keys

    IBM 3151 Emulation If two or more messages are sent to a particular field, then the message with the highest priority will be displayed. Messages in field 3 are displayed in the following order: HOLD SCREEN SENDING PRINTING KEYS LOCKED INVALID KEY WRONG PLACE NUMERIC...

  • Page 220: Keyboard Mapping

    IBM 3151 Emulation You can erase the character at the current cursor position by pressing the keys Ctrl + 2. If you want to restore the default definition, press the Clear key while the cursor is in field B. 4. Press the Send key to store the key definition. The function key menu will be cleared to allow you to enter the next key definition.
  • Page 221 IBM 3151 Emulation Enhanced AT & Sun 5* Keyboard Layout Note: The Sun 5 keyboard has additional keys not shown in this illustration but which are unaffected by TeemTalk. 15-5...
  • Page 222 IBM 3151 Emulation Sun 4 Keyboard Layout 15-6...
  • Page 223 IBM 3151 Emulation HP 9000 Series Keyboard Layout 15-7...
  • Page 224 IBM 3151 Emulation Notes 15-8...

  • Page 225: Mdis Prism Emulations

    MDIS Prism Emulations MDIS Prism Emulations This chapter describes features of the MDIS P8, P9 and P12 terminal emulations. Introduction The emulation of the McDonnell Douglas P12, P8 or P9 terminal is entered by displaying the Emulation Settings dialog box from the Settings menu and setting the Alpha Emulation option to MDI P8\P12 or MDI P9, respectively.
  • Page 226 MDIS Prism Emulations Enhanced AT & Sun 5* Keyboard Layout Note: The Sun 5 keyboard has additional keys not shown in this illustration but which are unaffected by TeemTalk. 16-2...
  • Page 227 MDIS Prism Emulations Sun 4 Keyboard Layout 16-3...
  • Page 228 MDIS Prism Emulations HP 9000 Series Keyboard Layout 16-4...

  • Page 229: Pt250 Emulation

    PT250 Emulation PT250 Emulation This chapter describes the Prime PT250 terminal emulation. Introduction The emulation of the Prime PT250 terminal is entered by displaying the Emulation Settings dialog box from the Settings menu and setting the Alpha Emulation option to PT250. Click Ok to close the dialog box. The PT250 emulation is configured via the PT250 Settings dialog box which is described in the Setup Menus chapter.
  • Page 230 PT250 Emulation Field 3: Indicates the mode of data transmission as follows: CHAR indicates that the emulation is in Character mode in which each character is sent to the host when it is typed at the keyboard. CNTRL indicates that the emulation is in Control Representation mode in which all received data and commands from the host or keyboard are displayed but not acted upon.

  • Page 231: Keyboard Mapping

    PT250 Emulation ALPHA ONLY indicates that you have attempted to enter non-alpha- betic data in a field reserved for alphabetic characters when in Block mode. ALPHANUMERIC indicates that you have attempted to enter non- alphanumeric data in a field reserved for alphanumeric characters when in Block mode.
  • Page 232 PT250 Emulation Enhanced AT & Sun 5* Keyboard Layout Note: The Sun 5 keyboard has additional keys not shown in this illustration but which are unaffected by TeemTalk. 17-4...
  • Page 233 PT250 Emulation Sun 4 Keyboard Layout 17-5...
  • Page 234 PT250 Emulation HP 9000 Series Keyboard Layout 17-6...

  • Page 235: Displaying Alternate Characters

    PT250 Emulation Displaying Alternate Characters PT250 mode uses two character sets called Standard and Alternate to display characters. Both sets incorporate all the characters contained in the ASCII (7-bit or lower half) and PT250 Additional (8-bit or upper half) character set tables shown in the Character Sets appendix in the Programmer's Guide.
  • Page 236 PT250 Emulation Notes 17-8...

  • Page 237: Siemens 97801 Emulation

    Siemens 97801 Emulation Siemens 97801 Emulation This chapter describes the Siemens 97801 terminal emulation. Introduction The emulation of the Siemens 97801 terminal is entered by displaying the Emulation Settings dialog box from the Settings menu and setting the Alpha Emulation option to Siemens 97801.
  • Page 238 Siemens 97801 Emulation Enhanced AT & Sun 5* Keyboard Layout Note: The Sun 5 keyboard has additional keys not shown in this illustration but which are unaffected by TeemTalk. 18-2...
  • Page 239 Siemens 97801 Emulation Sun 4 Keyboard Layout 18-3...
  • Page 240 Siemens 97801 Emulation HP 9000 Series Keyboard Layout 18-4...

  • Page 241: Stratus V102 Emulation

    Stratus V102 Emulation Stratus V102 Emulation This chapter describes features of the Stratus V102 terminal emulation. Introduction The emulation of the Stratus V102 terminal is entered by displaying the Emulation Settings dialog box from the Settings menu and setting the Alpha Emulation option to Stratus V102.

  • Page 242: Keyboard Mapping

    Stratus V102 Emulation Keyboard Mapping The following illustrations show where Stratus V102 keyboard functions are mapped to keys on the Enhanced AT, Sun 5, Sun 4 and HP 9000 series keyboard layouts. 19-2...
  • Page 243 Stratus V102 Emulation Enhanced AT & Sun 5* Keyboard Layout Note: The Sun 5 keyboard has additional keys not shown in this illustration but which are unaffected by TeemTalk. 19-3...
  • Page 244 Stratus V102 Emulation Sun 4 Keyboard Layout 19-4...
  • Page 245 Stratus V102 Emulation HP 9000 Series Keyboard Layout 19-5...
  • Page 246 Stratus V102 Emulation Notes 19-6...

  • Page 247: Ta6530 Emulation

    TA6530 Emulation TA6530 Emulation This chapter describes the Tandem 6530 terminal emulation. Introduction The emulation of the Tandem 6530 terminal is entered by displaying the Emulation Settings dialog box from the Settings menu and setting the Alpha Emulation option to TA6530. Click Ok to close the dialog box. You must use the inbuilt telnet facility provided by TeemTalk to make a connection to a remote host when using this mode.

  • Page 248: Operating Modes

    TA6530 Emulation ANSI The emulation is operating in ANSI mode. BLOCK The emulation is operating in Block mode. CNTRL Display controls mode activated. In this mode, received control codes will be displayed but not actioned. CONV The emulation is operating in Conversational mode. HOLD Hold screen is activated.

  • Page 249: Keyboard Mapping

    TA6530 Emulation Display memory is treated as one long page consisting of 400 lines, of which 24 lines may be viewed at any one time. Lines above or below those currently displayed may be scrolled into view using cursor or display control keys. Once all the display memory has been used, new data will force all previous lines of data up one line so that the first line is erased, ensuring that the oldest data is erased first.
  • Page 250 TA6530 Emulation Enhanced AT & Sun 5* Keyboard Layout Note: The Sun 5 keyboard has additional keys not shown in this illustration but which are unaffected by TeemTalk. 20-4...
  • Page 251 TA6530 Emulation Sun 4 Keyboard Layout 20-5...
  • Page 252 TA6530 Emulation HP 9000 Series Keyboard Layout 20-6...

  • Page 253: Wyse Emulations

    Wyse Emulations Wyse Emulations This chapter describes features of the Wyse WY-50, WY-50+ and WY-60 terminal emulations. Introduction The emulation of the Wyse WY-50, WY-50+ or WY-60 terminal is entered by displaying the Emulation Settings dialog box from the Settings menu and setting the Alpha Emulation option to Wyse 50, Wyse 50+ or Wyse 60.

  • Page 254: Status Line Messages

    Wyse Emulations Status Line Messages The status line at the top of the window is divided into two sections. The left section displays messages relating to the emulation and the right section is used to display messages from the host. The type of status line displayed is determined by the setting of the Status Line option in the Wyse Settings dialog box.

  • Page 255: Keyboard Mapping

    Wyse Emulations Field 5: >AUX indicates that the emulation is in auxiliary print or transparent print mode. <AUX indicates that the emulation is in auxiliary receive mode. =AUX indicates that the emulation is in auxiliary receive mode and auxiliary print mode. %AUX indicates that a print screen operation is in progress.
  • Page 256 Wyse Emulations Enhanced AT & Sun 5* Keyboard Layout Note: The Sun 5 keyboard has additional keys not shown in this illustration but which are unaffected by TeemTalk. 21-4...
  • Page 257 Wyse Emulations Sun 4 Keyboard Layout 21-5...
  • Page 258 Wyse Emulations HP 9000 Series Keyboard Layout 21-6...

  • Page 259: File Transfer

    File Transfer File Transfer This chapter describes how to transfer files using the Kermit, XMODEM, XMODEM-1K, YMODEM Batch, ZMODEM and IXF protocols. Introduction TeemTalk includes a file transfer utility which enables two-way file transfer between the host and your workstation. This chapter describes how to transfer files when running any emulation except the IBM emulations.

  • Page 260: Ymodem Batch

    File Transfer YMODEM Batch YMODEM Batch is similar to XMODEM-1K but enables several files to be trans- ferred. It checks for errors using a cycling redundancy check only. ZMODEM ZMODEM is an advanced development of YMODEM which enables much faster multiple file transfer with enhanced error detection and aborted transfer resumption.

  • Page 261: Sending Files

    File Transfer Sending Files The following procedure is used to transfer files from your workstation to the host. 1. Start the transfer procedure on the host computer and specify that files are to be received. 2. Display the TeemTalk File menu on your workstation and select File Transfer...
  • Page 262 File Transfer 7. Specify the directory path and name of the file then click OK to start transferring data to the host. A dialog box will be displayed showing how the file transfer is progressing. The transfer will continue until all selected files have been received by the host or the transfer is cancelled.

  • Page 263: Receiving Files

    File Transfer Receiving Files The following procedure is used to transfer files from the host to your workstation. 1. Start the transfer procedure on the host computer and specify that files are to be sent. 2. Display the TeemTalk File menu on your workstation and select File Transfer...

  • Page 264: Cancelling A File Transfer

    File Transfer Cancelling A File Transfer When a file transfer is in progress, the File Transfer Data window will be displayed. This will provide information on the progress of the file transfer similar to that shown below. Clicking the Reset or Cancel button will display another dialog box with four cancel options.

  • Page 265: Setting Protocol Parameters

    File Transfer Setting Protocol Parameters General Parameters Clicking the General... button in the Initiate File Transfer dialog box will cause the General Parameters dialog box to be displayed, as shown above. This enables you to set various parameters for any of the transfer protocols. Note that the Kermit and ZMODEM protocols have additional parameters which can be set in another dialog box by clicking the Kermit or ZModem button in the Initiate File Transfer dialog box.
  • Page 266 File Transfer Duplicate File Warning Factory default: Yes, Selected When this is selected, if an incoming file has the same name as an existing one it will be renamed to avoid overwriting it. A unique generation number will append or re- place part of the old name.

  • Page 267: Kermit Parameters

    File Transfer Kermit Parameters Clicking the Kermit... button in the Initiate File Transfer dialog box will cause the Kermit Parameters dialog box to be displayed, as shown above. This enables you to set parameters specific to the Kermit protocol. Note that the Kermit protocol has additional parameters which can be set in the General Settings dialog box, as described in the previous section.
  • Page 268 File Transfer End of line char Factory default: CTRL-M (i.e. CR) This specifies the character which terminates the packet. Quote char Factory default: # This specifies the character used to indicate that the next character is in the decimal range 0 - 31, 128 - 159, or is a delete character (127). Packet size Factory default: 80 This specifies the maximum byte size of a packet from the sequence number byte and...

  • Page 269: Zmodem Parameters

    File Transfer ZMODEM Parameters Clicking the ZModem... button in the Initiate File Transfer dialog box will cause the ZModem Parameters dialog box to be displayed, as shown above. This enables you to set parameters specific to the ZMODEM protocol. The Outbound settings inform the remote end how to treat the data that will be sent to it.
  • Page 270 File Transfer File Transfer Action Factory default: Default This specifies what action is to be taken by the receiving end on files that are trans- ferred. Selecting Default will use the action specified by the receiving end. Newer or Longer will cause files to be transferred if they do not exist in the destination directory and will replace files with the same name if the transfer files are more recent or contain more data.
  • Page 271 File Transfer Window size Factory default: 0 When a file transfer has been initiated, ZMODEM will send data continuously to the receiving end. If the receiving end is slower, then data will be stored on the network. This may cause a problem if an error occurs because the message will take longer to get through to the sender due to the amount of data still waiting on the network.

  • Page 272: Ixf Parameters

    File Transfer IXF Parameters The IXF (Information eXchange Facility) protocol is supported when TeemTalk is running the Tandem 6530 terminal emulation. Clicking the IXF... button in the Initiate File Transfer dialog box will cause the Information eXchange Facility Options dialog box to be displayed, as shown above. This enables you to set parameters specific to the IXF protocol.
  • Page 273 File Transfer Print Translate Factory default: Unselected Not implemented in this version. No Skip Factory default: No This option applies when File Direction is set to Print. When selected, this will pre- vent the host from adding lines to the file that skip over page boundaries. No Strip Factory default: No This option applies when File Direction is set to Print.
  • Page 274 File Transfer Retry Delay Factory default: 0 This specifies the period of time in milliseconds that the protocol will wait for a packet to be transferred before trying again. The protocol will be exited if the number of retries exceeds that specified by the Max Retries option. The valid range is 0 - 65535. Timeout Factory default: 10000 This specifies the length of time in milliseconds that the protocol will wait for a re-...

  • Page 275: Kermit Remote Operations

    File Transfer Kermit Remote Operations When Kermit is selected as the transfer protocol, the Remote button in the Initiate File Transfer dialog box provides access to commands that enable you to perform various operations on the host. Kermit has to be operating in server mode on the host for remote commands to function.
  • Page 276 File Transfer Change Dir This enables you to specify a different working directory for the host and enter your password. If no directory is specified, the host will execute its default action for this command. UNIX will enter the home directory. Directory This enables you to specify which filenames are listed from the host's working direc- tory.

  • Page 277: Local Operation

    File Transfer Local Operation Clicking the Local button in the Initiate File Transfer dialog box will display a dialog box which enables you to specify the default local directory for sending and receiving files. 22-19...
  • Page 278 File Transfer Notes 22-20...

  • Page 279: Ibm File Transfer

    IBM File Transfer IBM File Transfer This chapter describes the file transfer utility supported by the IBM 3270 terminal emulation. Introduction TeemTalk enables you to transfer files using the IND$FILE transfer facility when running the IBM 3270 emulation. This chapter describes the basic procedure for sending and receiving files then goes on to describe all the options in the Ind$File dialog box.

  • Page 280: Sending & Receiving Files

    IBM File Transfer Sending & Receiving Files The following procedure is used to transfer files between your PC and the host. 1. Make sure the host session is ready for transferring files. 2. Select File Transfer... from the TeemTalk File menu. The Ind$File dialog box will be displayed: 3.
  • Page 281 IBM File Transfer 6. Specify the name of the Local File to send or Host File to receive. 7. If you are receiving a file, click the Receive button. If you are sending a file, click the Send button. A message box will display information on the file transfer as it progresses.

  • Page 282: Ind$File Settings

    IBM File Transfer Ind$File Settings File Transfer Program Factory default: ind$file This specifies the name of the file transfer program. Currently only IND$FILE is supported. Host Type Factory default: MVS/TSO This specifies the type of operating system or environment used by the remote host. MVS/TSO for Mutiple Virtual Storage / Time Sharing Option.
  • Page 283 IBM File Transfer Local File This specifies the name of a local PC file to be transferred to the host, or to assign a different name to a host file being transferred to the local PC. Host File This specifies the name of a host file to be transferred to the local PC, or to assign a different name to a local file being transferred to the host.

  • Page 284: Private Profile File Entries

    IBM File Transfer Private Profile File Entries The TeemTalk private profile file teemx*.ini (where * is 320 or 340, depending on your version of TeemTalk) includes the file transfer entries shown below by default. These relate to the entries in the IBM File Transfer and Host Options dialog boxes. The possible values for each command are shown in the right hand column.

  • Page 285: Ftp File Transfer

    FTP File Transfer FTP File Transfer This chapter describes the FTP file transfer utility which enables you to transfer files in ASCII, Binary or Tenex format between your workstation and systems running the FTP daemon ftpd. The Transfer Procedure The basic procedure for transferring files is described below. Following sections describe the various options available in detail.
  • Page 286 FTP File Transfer 2. Click Connect at the top of the dialog box to display a menu, then select the Connect option to display the Connection dialog box. 3. Enter the Host name, Login details and Password relevant for the host you wish to connect to (on some systems you may be required to enter the Account as well).
  • Page 287 FTP File Transfer Note that the directory structure of the AS400 operating system consists of libraries/files.members. Changing the directory changes the library. Double- clicking a file name (folder) will display its members (documents). 5. Select the destination directory in the same way. 6.

  • Page 288: Menu Descriptions

    FTP File Transfer Menu Descriptions Three menus can be displayed from the FTP File Transfer dialog box. These menus are displayed by clicking Connect, Operations or Settings at the top of the box. Connect Menu Connect This option will display the following dialog box which enables you to enter details of the remote host and make a connection.
  • Page 289 FTP File Transfer You will be returned to the FTP File Transfer dialog box when the connection is successful. The Disconnect button enables you to close the connection to the host. To save you having to enter details of the remote host each time you want to make a connection, you can assign a session name to them which will automatically set the host, login, password and account details when you click on it.

  • Page 290: Operations Menu

    FTP File Transfer Operations Menu The Operations menu enables you to select, create or remove directories, copy or rename files, and change permission settings on the local workstation or remote host. Local Change Directory Remote Change Directory These options will display a dialog box which enables you to change the current directory.
  • Page 291 FTP File Transfer Local Copy This option will display a dialog box which enables you to duplicate a file on the local workstation. Local Rename This option will display a dialog box similar to that shown above which enables you to change the name of a file on the local workstation.

  • Page 292: Transfer Settings Menu

    FTP File Transfer Transfer Settings Menu Clicking the Settings button will display the Transfer Settings dialog box. This enables you to specify how file names are treated, how information is displayed in the local and remote directory list boxes, and whether carriage return characters are stripped from ASCII files.

  • Page 293: Resources & Command Line Options

    Resources & Command Line Options Resources & Command Line Options This chapter describes how to use resources and command line options to specify how TeemTalk is run and displayed by the X Window System. Introduction Resources are used to specify how TeemTalk is run and displayed by the X Window System.

  • Page 294: Resource Format

    Resources & Command Line Options Resource Format There are a number of files in which resources are specified. Generally they are specified in the user's .Xdefaults file or the system wide application defaults file. The .Xdefaults file resides in the user's home directory and resources specified in it only affect invocations of TeemTalk made by the owning user.

  • Page 295: Command Line Option Format

    Resources & Command Line Options Command Line Option Format The command line for loading TeemTalk can be extended by options that control its display and operation, overriding resource file default settings. Options and associated values must be separated from the TeemTalk loading name and each other by a space.

  • Page 296: Command Summary

    Resources & Command Line Options Command Summary General Operation & Setup Command Function Resource Command Line X server for display & input display: host:server.screen -display h:sv.sn Sync signal to X server freq. pollTime: seconds -poll seconds Run program instead of shell program: program -program prog Include program arguments...

  • Page 297: Window Elements

    Resources & Command Line Options Display Format Command Function Resource Command Line Icon file for iconized display iconFile: filename -icon filename Start TeemTalk iconized none -iconic TeemTalk icon display location iconGeometry: ±x±y -iconGeometry Window maximized on loading maXimized: on Title for window & icon title: title -title title Window border width in pixels...
  • Page 298 Resources & Command Line Options Command Function Resource Command Line 132 col. double height text doubleheight132Font: list -dhfn132 list 132 column double width text doublewidth132Font: list -dwfn132 list 132 col. double width & height doubled132Font: list -dbfn132 list Default font index on startup defaultFontindex: # -df # Load all fonts on startup...

  • Page 299: General Operation & Setup

    Resources & Command Line Options General Operation & Setup Server For TeemTalk Display & Input Resource: xteemx340*display: host:server.screen Command Line: -display host:server.screen Default Setting: Determined by the DISPLAY environment variable. These commands specify which X server is to be used to display data and take input when TeemTalk is being run on a remote system.

  • Page 300: Licence Manager File Location

    Resources & Command Line Options Command line example: xteemx340 -program ls -arguments -l (l is a lowercase L) This will do a long (-l) directory listing (ls). Create A Login Shell Resource: xteemx340*loginShell: on/off Command Line: -ls enables login shell disables login shell Default Setting: Not applicable These commands enable you to specify that the shell that is started in the TeemTalk...

  • Page 301: Run Script File

    Resources & Command Line Options Command line examples: xteemx340 -name myTeemTalk xteemx340 -name hisTeemTalk These will select the following files from the .Xdefaults file: myTeemTalk*title: johns TeemTalk hisTeemTalk*title: stuarts TeemTalk Specify Resource On Command Line Resource: None Command Line: -xrm resource string Default Setting: Not applicable This allows a resource specification to be included on the command line as an argument.

  • Page 302: Emulation To Run On Startup

    Resources & Command Line Options Emulation To Run On Startup Resource: xteemx340*emuLation: emulation# Command Line: -em emulation# Default Setting: VT320 7-bit These commands enable you to specify the terminal emulation that TeemTalk runs when it is started, where emulation# is a numeric value corresponding to the emulation as indicated below: VT52 TA6530...

  • Page 303: Zmodem Startup

    Resources & Command Line Options ZMODEM Startup Resource: xteemx340*zmodemStartup: on/off Command Line: -zm +zm off Default Setting: Off When ZMODEM startup is enabled, TeemTalk will check incoming data for a remote ZMODEM startup sequence then automatically start a file transfer using the settings specified in the ZModem Settings dialog box.

  • Page 304: Input Queue Size

    Resources & Command Line Options Input Queue Size Resource: xteemx340*inputQueue: 0-4096 Command Line: -q or -Q 0-4096 Default Setting: 255 These commands enable you to set the input queue size for network data. The size of the input queue will determine how quickly an interrupt command takes effect. Prevent Message Display Resource: xteemx340*quiet: on/off...

  • Page 305: Cursor Line Selection Extent

    Resources & Command Line Options Cursor Line Selection Extent Resource: xteemx340*cutToBeginningOfLine: on/off Command Line: -cb cursor to end of line entire cursor line Default Setting: Cursor to end of line. These commands enable you to specify how much of the cursor line is selected when the mouse button is clicked three times in quick succession.

  • Page 306: Ibm Reply Mode

    Resources & Command Line Options IBM Reply Mode Resource: xteemx340*ibmReplymode: on/off Command Line: -ibmreply (on) +ibmreply (off) Default Setting: Off When you switch from one application to another the current contents of the screen is saved before the new application is displayed. Enabling IBM reply mode will prevent the colour information from being sent in a reply to the IBM host, forcing the reply mode to be always set to Field mode, not Extended Field or Character mode.
  • Page 307 Resources & Command Line Options Only the first alias for each printer is displayed Only the last alias for each printer is displayed All aliases for each printer are displayed Send String To Host On Exit Resource: xteemx340*exitString: "string" Command Line: -es "string" Default Setting: Not applicable These commands enable you to specify a string which will automatically be sent to the host when the TeemTalk window is closed.

  • Page 308: Telnet Session

    Resources & Command Line Options Telnet Session Initiate Telnet Session With Host Resource: xteemx340*tnHost: hostname Command Line: -tnhost hostname Default Setting: Not applicable These commands enable you to cause TeemTalk to initiate a telnet session with the specified host. Most emulations work quite well in the standard TeemTalk environment when the telnet process provided with the workstation is used to make the connection to the remote host.

  • Page 309: Suppress Telnet Echo Option

    Resources & Command Line Options Closed Telnet Session Exits TeemTalk Resource: xteemx340*tnExit: on Command Line: -tnexit Default Setting: off (message box displayed) When a telnet session is closed, TeemTalk normally displays a message box giving you the option to reconnect, cancel or exit. These commands enable you to cause TeemTalk to be exited immediately when the telnet session is closed.

  • Page 310: Display Format

    Resources & Command Line Options Display Format Icon File Name Resource: xteemx340*iconFile: filename Command Line: -icon filename Default Setting: Not applicable These commands enable you to specify the name of the file containing the icon that is displayed when TeemTalk is iconized. The icon file must be in standard X11 bitmap format.

  • Page 311: Window Border Width

    Resources & Command Line Options Window Maximized When Loaded Resource: xteemx340*maXimized: on Command Line: -ma These commands will cause the window to be displayed at the maximum size possible when TeemTalk is loaded, while retaining the default number of lines and columns and including all window elements if enabled (title bar, soft buttons etc.).
  • Page 312 Resources & Command Line Options The -geometry = option may be abbreviated to -g =. Note: The effect of these commands is determined by the window manager which may have its own rules for window size and position on the display. The command is followed by the size and location arguments, which take the following form: widthxheight±xoffset±yoffset...
  • Page 313 Resources & Command Line Options Text Lines Displayed When TeemTalk Loaded Resource: xteemx340*defaultLines: number of lines Command Line: -dl number of lines Default Setting: 24 (with status line on 25th line) These commands specify the number of text lines displayed in the window when TeemTalk is loaded.

  • Page 314: Save 4014 Graphics Display

    Resources & Command Line Options ReGIS Graphics Redraw Resource: xteemx340*graphicsRedraw: on/off Command Line: -gr enables ReGIS graphics redraw disables ReGIS graphics redraw Default Setting: on TeemTalk automatically redraws the ReGIS graphics screen when the window is resized. You can disable this function using these commands. Sixel Graphics Scaling Resource: xteemx340*scaleSixels: on/off...

  • Page 315: Window Elements

    Resources & Command Line Options Window Elements In addition to the following commands, the section entitled Object Names Available In TeemTalk towards the end of this chapter lists the names given to various elements of the window which can be used to specify whether or not they are enabled and how they are displayed using standard X resource commands.
  • Page 316 Resources & Command Line Options menu bar. You can enable/disable individual menu items by using the following resources: File Menu: xteemx340*File*Factory*Sensitive: true/false xteemx340*File*Reset*Sensitive: true/false xteemx340*File*Save*Sensitive: true/false xteemx340*File*Open*Sensitive: true/false (Telnet) xteemx340*File*Close*Sensitive: true/false (Telnet) xteemx340*File*Capture*Sensitive: true/false xteemx340*File*Replay*Sensitive: true/false xteemx340*File*CancelCapture*Sensitive: true/false xteemx340*File*CancelReplay*Sensitive: true/false xteemx340*File*PrinterSettings*Sensitive: true/false xteemx340*File*Print*Sensitive: true/false xteemx340*File*StartAutoprint*Sensitive: true/false...

  • Page 317: Soft Buttons

    Resources & Command Line Options Deactivate DEC Status Line Resource: xteemx340*activeStatusline: on/off Command Line: -as Default Setting: on These commands enable you to specify whether or not the user can change terminal settings using the DEC status line. The status line is active (i.e. the user can change terminal settings) by default.

  • Page 318: Colour Selection

    Resources & Command Line Options Colour Selection Colour Mapping Resource: xteemx340*installColormap: on/off Command Line: -ic enables writing of colour map disables writing of colour map Default Setting: on Most workstations have only one hardware colour map, a physical register into which colour values are written by the application program for display.

  • Page 319: Foreground (Text) Colour

    Resources & Command Line Options Foreground (Text) Colour Resource: xteemx340*foreground: colour (all areas) xteemx340*vt220*foreground: colour (emulation) Command Line: -fg colour Default Setting: black These commands select the colour of the foreground, which includes all menus, window borders as well as the emulation workspace. In the emulation workspace the foreground is considered to be any colour which is white.

  • Page 320: Reflection 4 Colour Support

    Resources & Command Line Options Reflection 4 Colour Support Resource: xteemx340*r4Compatibility: on/off Command Line: -r4 Default Setting: off These commands will cause the colours displayed by TeemTalk to be compatible with Reflection 4 software. 25-28...

  • Page 321: Font Selection

    Resources & Command Line Options Font Selection The fonts that are used for displaying text in the TeemTalk window are specified by the following resources and command line options. Each font selection resource and command line option specifies up to ten fonts. This is to support the window sizing function described in the Getting Started chapter.
  • Page 322 Resources & Command Line Options Default Fonts: "nil2,tis1203,tis1404,tis1605,tis2406,tis2807,tis3208,tis4010,tis4812,tis4814" This specifies the fonts to use for 80 column double height text. 80 Column Double Width Text Resource: xteemx340*doublewidth80Font: "font list" Command Line: -dwfn80 "font list" Default Fonts: "nil2,tis606,tis708,tis810,trm1212,tis1414,tis1616,tis2020,tis2424,tis2828" This specifies the fonts to use for 80 column double width text. 80 Column Double Height &...
  • Page 323 Resources & Command Line Options 132 Column Double Width Text Resource: xteemx340*doublewidth132Font: "font list" Command Line: -dwfn132 "font list" Default Fonts: "nil2,tis606,tis708,tis810,trm1210,tis1410,trm1610,trm2012,trm2416,trm2820" This specifies the fonts to use for 132 column double width text. 132 Column Double Height & Width Text Resource: xteemx340*doubled132Font: "font list"...

  • Page 324: Ibm 3270 Font Size Fixed

    Resources & Command Line Options IBM 3270 Font Size Fixed Resource: xteemx340*ibmFixedFont: on/off Command Line: -ibmfixed Default Setting: Font size changes to retain same window size When you switch between IBM models while running the IBM 3270 emulation, the size of the font is adjusted by default so that the total number of rows and columns supported by the IBM model selected can be displayed without adjusting the size of the window.

  • Page 325: Understanding X Resources

    Resources & Command Line Options Understanding X Resources Most X clients now implement a simple mechanism of specifying application prefer- ences using preference strings. These preference strings comprise the name of the X client followed by the name of the resource to be set. A colon and then the value to be assigned to the resource follow.
  • Page 326 Resources & Command Line Options Object Names Available In TeemTalk The following object names are available in TeemTalk: vt220 the main emulation window. scrollbar the scrollbar on the right hand side of the window. menubar the menubar at the top of the window. File the File pulldown menu.
  • Page 327 Resources & Command Line Options File*Close (Telnet) File*Capture File*Replay File*CancelCapture File*CancelReplay File*PrinterSettings File*Print File*StartAutoprint File*StopAutoprint File*RunScript File*CancelScript File*ScriptRecorder File*FileTransfer File*FTP File*ClearBuffer File*Quit Edit*GraphicCopyMode Settings*Emulation Settings*Host Settings*Terminal Settings*Graphics Settings*HP Settings*PT250 Settings*Tandem6530 Settings*IBM3151 Settings*Wyse Settings*IBM3270 Settings*IBM5250 Settings*BQ3107 Settings*Macros Settings*Attributes Settings*Mouse As the menus can be uniquely identified, total control can be exerted over various attributes within the setup entries.

  • Page 328: Command Line

    Resources & Command Line Options The following sections describe the most common sources of resource entries; the sections are ordered according to priority - e.g. command line options override duplicate entries in the .Xdefaults file. Command Line Entries on the command line override any other settings specified in other resource files.
  • Page 329 Resources & Command Line Options Controlling The Resource Database The X utility xrdb is a useful tool for maintaining and debugging the resource database. Whilst full details can be found in all good X guides, a few uses are presented below. xrdb <...
  • Page 330 Resources & Command Line Options Debugging Resources Problems with resource management are seldom attributable to TeemTalk and are more commonly attributable to incorrect syntax or the resource file not being read by the resource manager. Resource files require 100% accuracy in specification; every- thing is case sensitive, the position of white space characters are critical, and non- printable characters inserted in the file causes absolute havoc.
  • Page 331 Key Reference Numbers Key Reference Numbers This appendix lists the reference numbers assigned to keys on the British keyboard. National 8-bit Key Reference Numbers NORMAL SHIFT NORMAL SHIFT £ Î ß Ï À Ñ Á Ò Â Ó Ã Ô Ä...
  • Page 332 Key Reference Numbers British Keyboard Key Reference Numbers NORMAL SHIFT CTRL CT+SH COMPOSE -166 -166 -166 -166 DELETE -232 -234 -236 -238 ENTER -110 ESCAPE FIND -255 -261 -267 -273 HELP -231 -233 -235 -237 INSERT HERE -256 -262 -268 -274 NEXT -260...
  • Page 333 Key Reference Numbers British Keyboard Key Reference Numbers NORMAL SHIFT CTRL CT+SH → → → → → -135 -139 -143 -147 ↑ ↑ ↑ ↑ ↑ -136 -140 -144 -148 ← ← ← ← ← -137 -141 -145 -149 ↓ ↓ ↓ ↓ ↓ -138 -142 -146...

  • Page 334: Key Reference Numbers

    Key Reference Numbers British Keyboard Key Reference Numbers NORMAL SHIFT CTRL CT+SH...

  • Page 335: Keysyms

    Keysyms Keysyms This appendix describes the use of virtual keysyms and lists all the valid keysyms that may be used to define the function of keys Virtual Keysyms The standard X translation tables may be used to redefine the function of most keys on the keyboard.

  • Page 336: Keysyms & Functions

    Keysyms Keysyms & Functions This section lists all the actual keysyms and their functions. The first column in the following tables provides an example of a legend which may be printed on the cap of a key which relates to the function performed or character displayed as described in the second column.
  • Page 337 Keysyms Keysyms FUNCTION KEYSYM Begin Move cursor to beginning of line, BOL Begin Select Select, mark Select Print Print Print Execute Execute, run, do Execute Insert Insert, insert here Insert Undo Undo, oops Undo Redo Redo, again Redo Menu Menu Menu Find Find, search...
  • Page 338 Keysyms Keysyms FUNCTION KEYSYM Keypad 0 KP_0 Keypad 1 KP_1 Keypad 2 KP_2 Keypad 3 KP_3 Keypad 4 KP_4 Keypad 5 KP_5 Keypad 6 KP_6 Keypad 7 KP_7 Keypad 8 KP_8 Keypad 9 KP_9 Function key 1 Function key 2 Function key 3 Function key 4 Function key 5...
  • Page 339 Keysyms Keysyms FUNCTION KEYSYM Function key 20 Function key 21 Function key 22 Function key 23 Function key 24 Function key 25 Function key 26 Function key 27 Function key 28 Function key 29 Function key 30 Function key 31 Function key 32 Function key 33 Function key 34...
  • Page 340 Keysyms Keysyms FUNCTION KEYSYM Right function key 4 (F24 equivalent) Right function key 5 (F25 equivalent) Right function key 6 (F26 equivalent) Right function key 7 (F27 equivalent) Right function key 8 (F28 equivalent) Right function key 9 (F29 equivalent) Right function key 10 (F30 equivalent) Right function key 11 (F31 equivalent) Right function key 12 (F32 equivalent)
  • Page 341 Keysyms Keysyms FUNCTION KEYSYM Number sign numbersign Dollar sign dollar Percent sign percent & Ampersand ampersand Apostrophe qouteright Left parenthesis parenleft Right parenthesis parenright Asterisk asterisk Plus sign plus Comma comma Hyphen, minus sign minus Full stop period Solidus slash Zero Three Four...
  • Page 342 Keysyms Keysyms FUNCTION KEYSYM Commercial at Uppercase A Uppercase B Uppercase C Uppercase D Uppercase E Uppercase F Uppercase G Uppercase H Uppercase I Uppercase J Uppercase K Uppercase L Uppercase M Uppercase N Uppercase O Uppercase P Uppercase Q Uppercase R Uppercase S Uppercase T...
  • Page 343 Keysyms Keysyms FUNCTION KEYSYM Right square bracket bracketright Circumflex accent asciicircum Low line underscore Grave accent quoteleft Lowercase a Lowercase b Lowercase c Lowercase d Lowercase e Lowercase f Lowercase g Lowercase h Lowercase i Lowercase j Lowercase k Lowercase l Lowercase m Lowercase n Lowercase o...
  • Page 344 Keysyms Keysyms FUNCTION KEYSYM Lowercase z Left brace braceleft Vertical line Right brace braceright Tilde asciitilde No-break space nobreakspace ¡ Inverted exclamation mark exclamdown ¢ Cent sign cent £ Pound sign sterling ¤ Currency sign currency ¥ Yen sign ¦ Broken vertical bar brokenbar §...
  • Page 345 Keysyms Keysyms FUNCTION KEYSYM ¸ Cedilla cedilla ¹ Superscript 1 onesuperior º Masculine ordinal indicator masculine » Right angle quotation mark guillemotright ¼ Vulgar fraction one quarter onequarter ½ Vulgar fraction one half onehalf ¾ Vulgar fraction three quarters threequarters ¿...
  • Page 346 Keysyms Keysyms FUNCTION KEYSYM Õ Uppercase O with tilde Otilde Ö Uppercase O with diaeresis Odiaeresis × Multiplication sign multiply Ø Uppercase O with oblique stroke Ooblique Ù Uppercase U with grave accent Ugrave Ú Uppercase U with acute accent Uacute Û...
  • Page 347 Keysyms Keysyms FUNCTION KEYSYM ò Lowercase o with grave accent ograve ó Lowercase o with acute accent oacute ô Lowercase o with circumflex accent ocircumflex õ Lowercase o with tilde otilde ö Lowercase o with diaeresis odiaeresis ÷ Division sign division ø...
  • Page 348 Keysyms Notes B-14...

  • Page 349: Virtual Key Names

    Virtual Key Names Virtual Key Names This appendix lists all the virtual key names supported by TeemTalk. Introduction Virtual key names enable you to include a specific key function in a user definition for key macros, soft buttons, hotspots, etc. The following sections list the virtual key names applicable to each terminal emulation mode.

  • Page 350: Bq 3107 Virtual Key Names

    Virtual Key Names AT&T 4410 Virtual Key Names Key Function Virtual Key Name Key Function Virtual Key Name Backspace AT_BACKSPACE F1 - F8 AT_F1 - AT_F8 Break AT_BREAK Home Down AT_HOMEDOWN Clear AT_CLEAR Home Up AT_HOMEUP Cursor Down AT_DOWN Line Feed AT_LINEFEED Cursor Left AT_LEFT...
  • Page 351 Virtual Key Names DEC VT400 Virtual Key Names Key Function Virtual Key Name Key Function Virtual Key Name Back Tab VT_CSIZ Insert VT_INSERT Break VT_BREAK Keypad 0 - 9 VT_PAD0 - 9 Backspace VT_BACKSPACE Keypad Comma VT_COMMA Compose VT_COMPOSE Keypad Decimal VT_PADDECIMAL Cursor Down VT_DOWN...

  • Page 352: Ibm 3270 Virtual Key Names

    Virtual Key Names HP700/92 Virtual Key Names Key Function Virtual Key Name Key Function Virtual Key Name Backspace HP_BACKSPACE Insert Wrap HP_INSERTWRAP Clear Display HP_CLEARMEM Menu HP_MENU Clear Line HP_CLEARLINE Next Page HP_NEXTPAGE Cursor Down HP_DOWN Previous Page HP_PREVPAGE Cursor Left HP_LEFT Print HP_PRINT...

  • Page 353: Ibm 5250 Virtual Key Names

    Virtual Key Names IBM 5250 Virtual Key Names Key Function Virtual Key Name Key Function Virtual Key Name Attention AS_ATTN Field Plus AS_FIELDPLUS Back Tab AS_BACKTAB Help AS_HELP Backspace AS_BACKSPACE Home AS_HOME Clear AS_CLEAR Insert Mode AS_INSERT Cursor Down AS_DOWN Monochrome AS_MONO Cursor Left...

  • Page 354: Pt250 Virtual Key Names

    Virtual Key Names PT250 Virtual Key Names Key Function Virtual Key Name Key Function Virtual Key Name Back Tab PT_BACKTAB Keypad 0 - 9 PT_PAD0 - 9 Backspace PT_BACKSPACE Keypad Decimal PT_PADDECIMAL Break PT_BREAK Keypad Minus PT_PADMINUS Cancel PT_CANCEL Keypad Plus PT_PADPLUS Change Mode PT_CHNGMODE...

  • Page 355: Siemens 97801 Virtual Key Names

    Virtual Key Names Siemens 97801 Virtual Key Names Key Function Virtual Key Name Key Function Virtual Key Name Backspace SI_BACKSPACE Keypad 0 - 9 SI_PAD0 - SI_PAD9 Back Tab SI_BACKTAB Keypad CE SI_PADCE Break SI_BREAK Keypad Decimal SI_PADDECIMAL CH Code SI_CHCODE Keypad Divide SI_PADDIVIDE...

  • Page 356: Ta6530 Virtual Key Names

    Virtual Key Names TA6530 Virtual Key Names Key Function Virtual Key Name Key Function Virtual Key Name Backspace TA_BACKSPACE Keypad Comma TA_PADCOMMA Back Tab TA_BACKTAB Keypad Decimal TA_PADDECIMAL Break TA_BREAK Keypad Enter TA_ENTER Character Delete TA_CHARDEL Keypad Minus TA_PADMINUS Character Insert TA_CHARINS Line Delete TA_LINEDEL...

  • Page 357: Viewdata Virtual Key Names

    Virtual Key Names Viewdata Virtual Key Names Key Function Virtual Key Name Key Function Virtual Key Name * (Star) PR_STAR Cursor Right PR_RIGHT # (Hash) PR_HASH Cursor Up PR_UP Cancel Print PR_CANCEL Exit to ANSI mode PR_EXIT Cursor Down PR_DOWN Reveal PR_REVEAL Cursor Left...

  • Page 358: Sending Text To A File

    Virtual Key Names TeemTalk Virtual Key Name Functions TeemTalk provides additional virtual key name functions for special tasks such as sending text to a file or the serial port, and reading text from a file to place in the keyboard buffer as if typed. Key Function Virtual Key Name Start Send Text sequence...

  • Page 359: Reading Text From A File

    Virtual Key Names Reading Text From A File The following command format is used to read a string from a file and push it into the keyboard buffer as if typed: <VK_FILE_I><filename>max length,retries,termination char- acter <VK_FEND> The string is terminated when the maximum length is read, or the maximum number of retries is reached, or the termination character is read.
  • Page 360 Virtual Key Names Notes C-12...

  • Page 361: Product Specification

    Product Specification Product Specification This appendix describes the level of support provided by each terminal emulation. Introduction The following sections describe the level of support provided by each terminal emulation throughout the product range. Note that your product version may not support all the terminal emulations listed here.
  • Page 362 Product Specification Telnet Specification: Implements RFC 854, 855, 856, 857, 858, 860, 1091, 1408, 1571, 1572. Implements RFC 1205, 2877 for IBM 5250. Implements RFC 2355, 1576, 1646, 1647 for IBM 3270. AixTerm Limitations: No Vertical tab stops. No Select Alternate presentation variant. No Select reversed string.

  • Page 363: Digital Vt Emulation

    Product Specification Data General D200/D410 Specification: Dasher D410 Display Terminals User’s Manual (014-000761-02 December 1983). Digital VT Emulation Specification: Digital VT 420 Programmer's Manual (EK-VT420-RM-001). Limitations: The DEC Multisession and SSU protocols are not implemented. HP 700/92 Emulation Specification: HP 2392A Reference Guide (02394-90001. April 1984). IBM 3270 Emulation Specification: 3270 Information Display System Data Stream Programmer's Reference...
  • Page 364 Product Specification IBM 5250 Emulation Specification: 5494 Remote Control Unit Functions Reference. Release 2.0. (SC30-3533-02). Limitations: No Right to Left writing mode. No double-byte support. The 3812-1 Non Host Print Transform (Non-HPT) print protocol is not supported. No Calculator / Hex key. No Password encryption.

  • Page 365: Stratus V102

    Product Specification Stratus V102 Specification: V102 Display Terminal Operator’s Manual (TVI 131974-00 June 1985). Limitations: Page print flip mode not supported. Serial configuration commands not supported. Select character set commands not supported. Tandem 6526/6530 Emulation Specification: Tandem 653x Multi-Page Terminal Programmer’s Guide (82310-B00 December 1983).

  • Page 366: Televideo 955

    Product Specification Televideo 955 Specification: Televideo 955 Display Terminal Operator's Manual (131969-00-B Sept 1985). Limitations: Page print flip mode not supported. Serial configuration commands not supported. Select character set commands not supported. Unisys T27 Specification: Burroughs T27 Programmer’s Reference Manual (1196904 Aug 1986). Limitations: Print protocol, printer sessions and auxiliary i/o are not supported.
  • Page 367 Product Specification Function key label save commands not supported. Automatic font loading not supported. Remote caps lock commands not supported. Ignore nulls commands not supported. Attribute overwrite mode not supported. Disable intensity commands not supported. Some select personality commands not supported. Wyseword mode not supported.
  • Page 368 Product Specification Notes...
  • Page 369 Index Index Symbols Setup 8-68 Specification D-2 4010/4014 Emulation Status bar 10-1 Selecting 3-9 Virtual key names C-2 Buffer For Text Lines 25-21 ADDS Viewpoint A2 Emulation Selecting 3-6 Capturing Files 8-6 AIXTerm Emulation 3-6 Character Sets Specification D-2 Multinational mode 8-34 ANSI BBS Emulation 3-6 National mode 8-34 VT420 downloadable 8-33...
  • Page 370 Index Cursor static/flashing 25-25 Telnet close option 25-17 Cut/paste EOL character 25-12 Telnet keepalive messages 25-16 Deactivate DEC status line 25-25 TERM environment variable 25-8 Debug mode 25-11 Text cursor colour 25-27 Emulation to run on startup 25-10 Text lines displayed 25-21 Font selection 25-29 Title for window &...
  • Page 371 Index Backing store 25-21 IBM 3270 functions 13-7 Colour or greyscale 8-38 IBM 5250 functions 14-4 Control codes 8-34 MDIS Prism functions 16-2 Cursor style 8-37 PT250 functions 17-4 Double margin 8-40 Siemens 97801 functions 18-2 Hold screen 3-13, 9-8 Stratus V102 functions 19-3 Hotspots 6-1 TA6530 functions 20-4...
  • Page 372 Index FTP File Transfer 24-1 HP 700-92/96 Emulation Transfer procedure 24-1 Specification D-3 Function Keys HP700/92 Emulation DEC VT320 equivalents 4-2 Configuration selection 12-8 Viewdata emulation 3-9 Device control 12-8 Display attributes 12-15 Function keys & labels 12-1 Introduction 12-1 Getting Started Key programming 12-13 Host communications 3-3...
