Installing a DIMM

To install a DIMM, complete the following steps.
110
System x3650 M3 Types 4255, 7945, and 7949: Installation and User's Guide
1. Read the safety information that begins on page vii and "Installation guidelines"
on page 37.
2. Turn off the server and peripheral devices, and disconnect the power cord and
all external cables (see "Turning off the server" on page 22).
3. Remove the server cover (see "Removing the cover" on page 44).
4. If PCI riser-card assembly 1 contains one or more adapters, remove riser-card
assembly 1 (see "Removing a PCI riser-card assembly" on page 45).
5. Remove the DIMM air baffle (see "Removing the DIMM air baffle" on page 49).
PCI riser-card
assembly 1
DIMM air baffle
