The virtual media key has an LED. When this LED is lit and green, it indicates that
the key is installed and functioning correctly.
The remote presence feature provides the following functions:
v Remotely viewing video with graphics resolutions up to 1600 x 1200 at 75 Hz,
v Remotely accessing the server, using the keyboard and mouse from a remote
v Mapping the CD or DVD drive, diskette drive, and USB flash drive on a remote
v Uploading a diskette image to the IMM memory and mapping it to the server as a
The blue-screen capture feature captures the video display contents before the IMM
restarts the server when the IMM detects an operating-system hang condition. A
system administrator can use the blue-screen capture to assist in determining the
cause of the hang condition.

Enabling the remote presence feature

To enable the remote presence feature, complete the following steps:
1. Install the virtual media key into the dedicated slot on the system board (see
2. Turn on the server.

Obtaining the IP address for the Web interface access

To access the Web interface and use the remote presence feature, you need the IP
address for the IMM. You can obtain the IMM IP address through the Setup utility.
To locate the IP address, complete the following steps:
1. Turn on the server.
2. When the prompt <F1> Setup is displayed, press F1. If you have set both a
3. From the Setup utility main menu, select System Settings.
4. On the next screen, select Integrated Management Module.
5. On the next screen, select Network Configuration.
6. Find the IP address and write it down.
7. Exit from the Setup utility.

Logging on to the Web interface

To log on to the Web interface to use the remote presence functions, complete the
following steps:
1. Open a Web browser on a computer that connects to the server and in the
regardless of the system state
client
client, and mapping ISO and diskette image files as virtual drives that are
available for use by the server
virtual drive
"Installing an IBM Virtual Media Key" on page 57).
Note: Approximately 3 minutes after the server is connected to ac power, the
power-control button becomes active.
Note: Approximately 3 minutes after the server is connected to ac power, the
power-control button becomes active.
power-on password and an administrator password, you must type the
administrator password to access the full Setup utility menu.
address or URL field, type the IP address or host name of the IMM to which
you want to connect.
Chapter 3. Configuring the server
155
