Table B-13
Sequence Tests (For models 40fx, 80ex, 125ex, and 220mx ONLY)
No.
Test Name
60
FRU Isolation Test
65
Calibrate Magazines
66
Clear Magazine Min/
Max
67
Calibrate Mailslot
68
Clear Mailslot Max/
Min
75
UPS Test
Appendix B
Jukebox Micro-Move Error Codes
Description
Assumes that something has physically failed,
either electronic or mechanical. A series of
special low-level tests are executed to select the
three (or fewer) FRUs which are most likely to
be at fault. Tests 30, 31, 33, 35, 36, 40, and 50
are executed as a part of the isolation process.
Calculates a min/max clearance for a magazine.
(The selected magazine should be empty.) The
autochanger requires a disk in the mailslot. The
test passes if clearance is 85 encoder counts (1
mm) up and down. (See Info 23 for actual
values.)
If this test is run by SCSI command, set Byte 1
to the magazine number.
The test returns: PASS or FAIL.
Clears the value calculated in Test 65.
Calculates a min/max clearance for the mailslot.
The autochanger requires a disk in the mailslot.
The test passes if clearance is 85 encoder counts
(1 mm) up and down. (See Info 23 for actual
values.)
The test returns: PASS or FAIL.
Clears the value calculated in Test 67.
Tests whether or not the UPS is connected
properly.
The test returns PASS if connected properly,
FAIL if the UPS is not connected properly or if
there is no UPS connected.
Autochanger Error Codes
B-51
