Table 3-32
Jukebox SCSI-2 Command Set
Send Diagnostic Command (1DH)

Send Diagnostic Command Data

Send Diagnostic Command Parameter List
Byte 7 6
0
1 Break
2
3
4
5
6
7
8
9
Test Number Diagnostic test number. See Table B-12 on page B-40 or
Table B-13 on page B-44 for a list of the jukebox
diagnostic tests.
Break Indicates how to terminate the loop count if an error
occurs.
0 - Break on first error
1 - Do not break on error
Loop Count
Identifier The number of times the test will be repeated before the
test is terminated and status is returned.
1H - Run 1 time
2H - Run 10 times
3H - Run 100 times
4H - Run 1000 times
Parameters Parameters associated with the specified tests.
3-36
5 4 3
Test Number
Loop Count Identifier
Parameters
Parameters
Parameters
Parameters
Parameters
Parameters
Parameters
Parameters
2 1 0
Chapter 3
