For the C1150 Series Jukebox
This upgrade requires code to be downloaded to the controller PCA and the drives.
BEFORE starting this upgrade, obtain the following:
*
The downloadable code required for this upgrade. FTP this code
from hpgrsg.gr.hp.com (15.38.89.10
Further download instructions are available at that address.
* A PC with a SCSI interface and appropriate cables.
* A utility to download the code - DOWNLD2 or HP TOOLSET (Version 1.95ce
or later.) from CoComp.

Capacity Upgrade

Important! Read This First
)
using an "anonymous" login.
HP Part No. C1155-90000
Printed in USA June, 1996
Edition 1 0696

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Surestore 160ex - Optical Jukebox and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for HP Surestore 160ex - Optical Jukebox

Summary of Contents for HP Surestore 160ex - Optical Jukebox

  • Page 1: Capacity Upgrade

    Capacity Upgrade For the C1150 Series Jukebox Important! Read This First This upgrade requires code to be downloaded to the controller PCA and the drives. BEFORE starting this upgrade, obtain the following: The downloadable code required for this upgrade. FTP this code from hpgrsg.gr.hp.com (15.38.89.10 using an "anonymous"...
  • Page 2 Hewlett-Packard Company, 1996...

  • Page 3: Esd Precautions

    Capacity Upgrade For the C1150 Series Jukebox Before C1155F/G/H upgrade: Upgraded to equivalent of: (# of drives and slots) C1150F/G/H C1160F/G/H (64 slots) (2 drives, 32 slots) -or- C1170F/G/H (76 slots) Table 1: C1150 Series Capacity Upgrade Options a. Install only the 4, 8-slot magazines for a total of 64 slots and the drive upgrade (C1154F/G/H).

  • Page 4: Kit Contents

    Kit Contents • 8 - magazine guides, 8 slot (makes 4 sets) — # C1100-44x00 • 4 - magazine guides, 6 slot (makes 2 sets) — # C1160-41x15 • 1 - controller PCA — # C1170-60x01 • 1 - product upgrade label sheets (Upgrade to: ) — # 5181-9902 •...

  • Page 5: Before You Begin

    Before You Begin Caution Do NOT switch off power to the jukebox until you are sure the . Switching off the jukebox when the SCSI bus is inactive SCSI bus is active can cause data loss and/or indeterminate bus states. When doing this upgrade, be sure that disk cartridges are not If you need to remove moved from their original slot locations.
  • Page 6 Installing the Capacity Upgrade Caution Put on a grounding strap to work inside the outer shell of this jukebox. 1. Remove the left, right and back panels. Refer to Figures 1 and 2. Figure 1: Right-side panel access a. Remove the T-20 screw that holds the bottom edge of the panel. b.
  • Page 7 Rear, overall arrows, screws Figure 2: Rear access panel d. Remove the 7 T-20 screws around the outer edge of the panel. e. Remove the single screw underneath the bottom of the panel. f. Rotate the back panel back and lift if off the frame.
  • Page 8 Note The magazines come in sets of 8-slot magazines (4 sets) and 6-slot magazines (2 sets). Each magazine (set of cartridge slots) comes as two identical sides. To upgrade to a C1160F/G/H with 4 drives and 64 slots, a drive upgrade (C1154F/G/H) AND this capacity upgrade must be installed.
  • Page 9 Back View Drive Drive A performance upgrade adds 2 drives and 32 (4, 8-slot) magazines. A capacity upgrade adds 44 (4, 8-slot and 2, 6-slot) magazines- including 12 additional slots in the area where the additional drives would be added during a drive/performance upgrade.
  • Page 10 The magazine guide pictured on the previous page is shown as it is oriented when placing it into the inside right of each stack (as you face the "picker side" of the stacks). Place the leading tabs (top right in the picture) into the slots farthest in, then rotate the magazine guide into the stack, catching the trailing tabs (lower left arrows in picture).
  • Page 11 b. Remove the 6 T-20 screws on the controller PCA cover and lift the cover off. See Figure 6. Figure 6: Controller PCA - cover on c. Disconnect all cables from the controller PCA. See Figure 7 d. Remove the 7 T-20 screws from the controller PCA and remove the PCA. Through rear access panel ---- Controller PCA with cables off Figure 7: Controller PCA - cover off and cables removed...
  • Page 12 2 drive / 76 slot jukebox. Make sure the product number suffix (F, G, or H) matches the old product number suffix. Note: The label does NOT cover the original serial number. Example Hewlett-Packard Co. label Upgraded to C1170F S/N 9999999999 Original Made in U.S.A.
  • Page 13 b. IF THERE IS ALREADY A PRODUCT NAMEPLATE: place the new model number name- plate over the current model number on the back center of the jukebox as illustrated in Figure 9. If there is NO model number nameplate currently on the jukebox, go to the next step. Model ABCD Front...
