Using the Sprite Overlay
The Sprite Overlay displays important sprite properties directly on the Stage. You can open
editors, inspectors, and dialog boxes to change sprite properties by clicking the corresponding
icons in the Sprite Overlay.
To display the Sprite Overlay when a sprite is selected:
•
Select View > Sprite Overlay > Show Info.
Name, cast, and media type of sprite's
cast member
Attached behavior(s)
To use Sprite Overlay options to change how the overlay appears:
Click the Sprite on the Stage to select it.
1
In the Sprite Overlay, click the icon that represents the data you want to edit:
2
•
To edit the Sprite's cast member, click this icon to open the tab in the Property inspector that
applies to this type of sprite. For example, clicking this icon displays the Vector tab for a vector
sprite, the Text tab for a text sprite, and so on.
•
To open the Sprite tab in the Property inspector, click this icon.
•
To open the Behavior tab in the Property inspector, click this icon. See Chapter 14,
"Behaviors," on page 357.
To change the Sprite Overlay's appearance to suit your preferences:
Select View > Sprite Overlay > Settings.
1
Select a Display option to determine when sprite properties are visible and active:
2
displays sprite properties only when the pointer is over a single sprite.
Roll Over
displays sprite properties when you select a sprite.
Selection
displays sprite properties for all sprites on the Stage.
All Sprites
Use the Text Color box to select the color for text that appears in the Sprite Overlay.
3
164 Chapter 5
Channel number; left, top,
right, and bottom coordinates;
ink; and blend settings
Sprite Overlay
Overlay opacity control
