13. LISA X MAINTENANCE

ATTENTION!
Any assembly, installation, adjustment and service work should be carried out with the device free
of hazardous substances, including powder and dust in a NOT-CLASSIFIED atmosphere (an area
with a non-potentially explosive atmosphere).

13.1 Basic maintenance

1. To determine if it is time to service the printer
components, from
MAINTENANCE and then select PRINTER STATUS
(fig. 13.1).
2. The PRINTER STATUS screen includes:
a) PRINTER STATUS tab, in which you can check the current status of the printer and the condition of the printer
components (fig. 13.2). Components requiring maintenance and cleaning are:
• Inspection panel*
• Laser protective glass
• Recoater strip/short cord*
• Print Bed sealing
• Feed Bed sealing
* Marked elements may be different or not installed, depending on printer revision.
b) SELF CHECK tab, in which it is possible to check that all components in the printer are working correctly (motors,
laser, heaters, etc.; fig. 13.3).
c) ERRORS tab, in which you will see possible errors and messages of damage to printer components (fig. 13.4).
PRINTER STATUS
Fig. 13.2 The PRINTER STATUS screen.
the Main Menu, select
PRINTER STATUS
SEFL CHECK ERRORS
CURRENT MATERIAL PA12 SMOOTH
RECENT PRINT JOB PUMP_01
PRINTER TEMPERATURE 100°C
MAINTENANCE STATUS
LASER PROT. GLASS 16/80 h
REOCATER CORD 30/200 h
PRINT BED SEALING 30/200 h
Fig. 13.4 The ERRORS screen.
MAINTENANCE
Fig. 13.1 The MAINTENANCE and PRINTER STATUS screen, which
contains all the basic printer maintenance tasks.
• Reflector sealing*
• F-Theta scanning lens
• Recoater drive cord
• Recoater drive belt (GT2)
• Infrared bulbs
PRINTER STATUS
Fig. 13.3 The SELF CHECK screen.
Sinterit Lisa X SLS 3D Printer Original User Manual | 44
UNLOCK LID
25°C
CLEAN REMOVE
THE PRINTER PRINTOUT
PRINTER PRINT JOB
STATUS HISTORY
UNLOCK OVERFLOW
UNLOCK DOOR
PRINTER STATUS
SEFL CHECK ERRORS
MOTORS
HEATERS
INFRARED BULBS
LASER
FAN
INERT GAS
SELF CHECK
