WARNING!
Powders - extinguishing fire
All commonly used fire extinguishers are permitted – Carbon dioxide (CO
extinguishing powder, alcohol-resistant foam, and atomized water. Do not use a
high-pressure water jet!
Combustion products
The range of possible combustion products includes simple asphyxiants (CO
nitrogen oxides) and toxic substances (carbon monoxide, cyanide). It is paramount
to avoid inhaling the smoke, and in such an event, promptly evacuate onto fresh air
and seek immediate medical attention.

2.9 Safety plates (specification tag and symbols)

Manufacturer
Sinterit sp. z o.o. ul. Nad Drwina 10/B-3, 30-741 Krakow, Poland
www.sinterit.com support@sinterit.com
IEC Protection Class
Class 1
IP Code
Complies with 21 CFR 1040.10 and 1040.11 except for conformance with IEC 60825-1 Ed.3., as described in Laser Notice No. 56, dated May 8, 2019.
WARNING!
• Removing the safety plates on the device is strictly forbidden!
• The manufacturer declines all liability about device safety in the event of failure to comply with the
above indications.
ATTENTION!
• Make sure all the safety messages are legible.
• Clean these with cloth, soap, and water. Do not use solvents, diesel fuel, or petrol.
• Replace the damaged plates with new ones supplied by Sinterit. If a plate is attached to a replaced
part, make sure a new plate is affixed to the new part.
• When contacting the manufacturer or dealer, always quote the details shown on the Lisa X tag.

2.10 Scrapping

IMPORTANT!
In the case of scrapping, all the parts of the device will have to be disposed of
through adequate disposal channels by applicable legislation. Before scrapping,
all plastic and rubber parts will have to be separated from the electrical material.
Parts made of plastic, aluminium, and steel may only be recycled if collected by
special centres.
DO NOT REMOVE THIS LABEL!
Machine type
Dimensions
Total weight
Power consumption
IP20
AC current
Short-circuit
current rating
Contains devices FCC
Laser product class
Embedded laser
product class
WARNING! Read and understand operator's manual and all other safety instructions before using this machine.
Failure to follow operating instructions could result in serious injury.
Sinterit LISA X
Name
Serial number
Manufactured Made in EU / POLAND
SELECTIVE LASER SINTERING 3D PRINTER
650 x 610 x 1200 [mm] 25.6 x 24.0 x 47.2 [in]
145 [kg] 319 [lbs]
190-240 [V] AC, 50-60 [Hz], 1.65 [kW]
8 [A] / 230 [V] AC
Number
6 [kA] 1
of phases
FCC ID: 2ABCB-RPICM4
CLASS 1 IR LASER PRODUCT INVISIBLE LASER RADIATION
CLASS 4 IR LASER PRODUCT
INVISIBLE LASER RADIATION
wavelength λ = 976 ± 3 [nm]
beam divergence θ = 13°
beam output CW (CONTINUOUS WAVE)
maximum power 30 [W]
Sinterit Lisa X SLS 3D Printer Original User Manual | 14
