SINTERIT LISA X Original User Manual page 66

19. Through the inspection opening on the right side of the printer, tighten or loosen the marked bolt with a 10 [mm] socket
wrench (fig. 13.81). Tightening (
20. Repeat steps 10-12 (tension measurement using the smart device). In case of incorrect measurement, continue
adjusting the tension and measure it again – repeat until the value is within the correct range.
21. Once the measurement comes back correct, press CORRECT MEASUREMENT and put away your smart device.
22. Using a 7 [mm] socket screwdriver, tighten back the four nuts of the tensioning mechanism.
23. Mount back the access panel on the top side of the printer. Make sure to slide it under the print chamber gasket (fig.
13.82).
Fig. 13.80 Location of the four nuts of the tensioning mechanism.
) will increase the tension ( Hz), while loosening (
Fig. 13.81 Location of the tensioning bolt.
) will decrease it ( Hz).
Sinterit Lisa X SLS 3D Printer Original User Manual | 66
