SINTERIT LISA X Original User Manual page 51

15. Press POSITION BED to begin the positioning process
of the Print Bed and Recoater.
16. When the positioning is finished, confirm that the Print
Bed is at half its height and the Recoater is directly
above it.
17. Once again, wipe the Recoater roller with dry cloth to
remove the powder (fig. 13.20).
18. Next, wipe the Recoater roller using cloth soaked in
ethyl alcohol (fig. 13.20). Press DONE.
19. Clean all screw heads thoroughly.
20. Using a 2 [mm] allen key, undo the screws on the
Recoater cord mounting plate on the left and right side
(fig. 13.21).
21. If access to the screws is problematic, use the steering
arrows to move the Recoater in the right direction.
22. Grab the cord from both sides and remove it from the
knurled roller wheel.
23. Drag out the end of the cord (without spring) above
the Recoater's roller. At first the mounting plate, then
the ending, through the gap between the roller and
Recoater housing. Be careful not to touch the roller
(fig. 13.22).
24. Remove the second plate (with spring) from the socket.
25. Use a clean cloth to wipe the Recoater roller. Rotate the
roll during the cleaning.
26. Take the new Recoater cord and stretch it before
mounting.
27. Pre-install the plate with the spring on the Print Bed side. Be sure that the spring is fitted into the hole behind the plate.
Do not tighten the screws to the end of the range.
28. Drag the other end of the Recoater cord above the
Recoater roller.
29. Wind the Recoater cord on the roller tracing wheel (fig.
13.23).
30. Check if anything is blocking the slide of the cord.
31. Pull the cord to tense the spring.
Fig. 13.20 Use cloth and ethyl alcohol to clean the Recoater roller,
when it is above the Print Bed.
Fig. 13.21 Undo the screw of the Recoater cord.
Fig. 13.22 Drag out the plate without spring
above the Recoater's roller.
Fig. 13.23 Installing a new Recoater cord.
Sinterit Lisa X SLS 3D Printer Original User Manual | 51
%
