SINTERIT LISA X Original User Manual page 61

Fig. 13.57 Remove four screws from the access panel.
8. Now you have access to the tightening mechanism.
9. To tighten the cord, use a 7 [mm] wrench and loosen the three screws marked in figure 13.59.
10. Screw the marked bolt with a torque wrench (fig. 13.60). Tighten the cord for a value of 21 Ncm.
Fig. 13.59 Loosen the three screws of the tighten mechanism.
11. Using a 7 [mm] wrench, tighten back the three screws marked in figure 13.59.
12. Mount back the access panel on the top side of the printer (fig. 13.61).
13. Using a 2 [mm] allen key, tighten back the four screws securing the access panel on the top of the printer (fig. 13.62).
Fig. 13.61 Mount back the access panel.
14. Good job. The maintenance timer will reset to zero.
Fig. 13.58 Remove the access panel.
Fig. 13.60 Screw the marked bolt with a torque wrench.
Fig. 13.62 Tighten the back four screws of the access panel.
Sinterit Lisa X SLS 3D Printer Original User Manual | 61
