11. Maintenance and service of the Sinterit LISA
PRO Printer
To maintain the most efficient and long-lasting Printer, ensure regular conservation. The basic
maintenance contains:
● cleaning the PYROMETERS and the CAMERA PROTECTIVE GLASSES before and
after each print;
● checking the status of the RECOATER TRANSMISSION CABLE;
● cleaning the LASER PROTECTIVE GLASS before and after every print;
● cleaning the surface under the BEDs after every third print;
● lubricating the RECOATER's ball bearings.
A. LASER PROTECTIVE GLASS - replacement
1. Turn of the safety key switch and turn off the power switch.
2. While holding the heater module, take out the split pin positioned on the top of the
inner part of the lid.
3. Lower the heating module to get access to the place dedicated for the LASER
PROTECTIVE GLASS.
4. Unscrew two knurled nuts from the LASER PROTECTIVE GLASS module.
5. Remove the module from the locking holders located in the middle of the lid.
6. Now you can replace module of LASER PROTECTIVE GLASS with the new one.
To assemble the LASER PROTECTIVE GLASS socket:
7. Slide the metal tabs of the LASER PROTECTIVE GLASS module into the holders
located in the middle of the lid.
39
Image 57. HEATER MODULE - ​ c lasp system.
CAUTION!
Beware of sharp edges. Put on the safety gloves to protect yourself from
injuring the hand against the side of the heating module.
​
