13.4 Recoater maintenance

13.4.1 Recoater strip replacement

IMPORTANT!
Strip replacement is available by selecting under SETTINGS
RECOATER SETTINGS
checkbox and accepting with the SAVE button.
You will need: 2 [mm] allen key, new Recoater strip.
1. On the PRINTER STATUS tab, select the RECOATER MAINTENANCE position.
2. The Recoater Strip replacement tab will appear on the screen. You can use the step-by-step guide (press FOLLOW
GUIDE) or perform the replacement yourself.
3. In this case, mark MAINTENANCE DONE once you have completed the procedure, and then the DONE button. The
timer will reset to zero (fig. 13.9).
Fig. 13.9 Select the RECOATER MAINTENANCE position
to start the maintenance
4. Choose UNLOCK LID on the screen.
5. Push on the lid and pull it up using the lid handle. Remember, you only have 10 seconds to open it before the lock
activates again.
6. Clean the print chamber if needed.
7. Press POSITION RECOATER to set it in the middle of the printing chamber, in between the beds (fig. 13.11).
8. Using a 2 [mm] allen key, unscrew both ends of the strip from the angle brackets.
9. Press POSITION RECOATER again to set it on the hinge side of the printing chamber, near the end.
10. Gently remove the old Recoater strip.
11. Slide the new Recoater strip under the angle brackets (far side first) (fig. 13.12).
CHANGE RECOATER DRIVE TYPE, ticking the Recoater Strip
Fig. 13.11 The POSITION RECOATER screen.
MORE OPTIONS
Fig. 13.10 The Recoater maintenance
(Recoater strip replacement) screen.
Sinterit Lisa X SLS 3D Printer Original User Manual | 48
