SINTERIT LISA X Original User Manual page 39

CLEAN THE PRINTER - REMOVE POWDER
Fig. 10.7 Clean the print chamber using Multi PHS or the ATEX/Intertek Vacuum Cleaner with Separator.
17. Press UNLOCK DOOR on the screen and open the printer door.
18. Press the UNLOCK OVERFLOW button on the printer
screen. After 10 seconds, the electrolock will activate
and you will not be able to pull the drawer out. If you
still want to pull out the drawer, slide the UNLOCK
OVERFLOW button on the printer screen again.
19. Slide out the Overflow Bin (fig. 10.8).
20. Take the Overflow Bin from its drawer and transfer its contents onto the Multi PHS worktop or into the metal container.
Clean it thoroughly of any powder residues.
21. Put the Overflow Bin back in its drawer, press UNLOCK OVERFLOW again and slide it into place.
22. Some materials require replacing both the Bed sealing before use. Select the type of material you will use from the
list on the screen. (fig. 10.9).
23. The printer will inform you if replacing the seals is required in your case (fig. 10.10). In case it's not required,
the material removal is now finished. Otherwise please see Chapters 13.5 Replacing the Print Bed Sealing and
13.6 Replacing the Feed Bed Sealing.
Sealing replacement required.
This type of material require replacing the Print Bed and Feed Bed sealing before use.
Fig. 10.10 The notice informing you whether sealing maintenance will be required.
24. Good job. The printer has been thoroughly cleaned and is ready to print in other material.
ATEX Vacuum Cleaner with Cyclon
Separator to clean the printer.
Remove remaining powder from the Feed
and Print Beds.
Use steering arrows to move the Recoater
to clean the area under it.
Use a general surface nozzle.
DONE
Fig. 10.9 Prompt to select the next used material.
GOT IT
DONE
Fig. 10.8 Sliding out the Overflow Bin.
Sealing replacement required.
This type of material not require replacing the Print Bed and Feed Bed sealing before use.
Sinterit Lisa X SLS 3D Printer Original User Manual | 39
GOT IT
DONE
