12. Press POSITION RECOATER to set it in the middle of the printing chamber, in between the beds.
13. Using a 2 [mm] allen key, pre-screw the Recoater strip to the angle brackets (fig. 13.13).
14. Check that the Recoater strip does not bend and firmly tighten the screws.
15. Good job. The maintenance timer will reset to zero.

13.4.2 Recoater short cord replacement

You will need: 2 [mm] allen key, new Recoater cord, PHS or ATEX/Intertek Vacuum Cleaner with separator, 2 x cotton cloth,
ethanol-based cleaning solution or 99.9% purity isopropanol.
1. On the PRINTER STATUS tab, select the RECOATER MAINTENANCE position (fig. 13.14)
2. The Recoater cord maintenance tab will appear on the screen. You can use the step-by-step guide (press FOLLOW
GUIDE) or perform the replacement yourself.
3. In this case, mark MAINTENANCE DONE once you have completed the procedure, and then the DONE button. The
timer will reset to zero (fig. 13.15).
Fig. 13.14 Select the RECOATER MAINTENANCE position
to start the maintenance.
Fig. 13.12 Installing the replacement Recoater strip.
Fig. 13.13 Pre-screw the Recoater strip to the angle brackets.
To mount slide grip, you can gentlu
bend it. Be careful not to bend it too
sharply
screw
2.0 [mm]
Fig. 13.15 The screen of the maintenance
of the Recoater (roller and cord).
