6.3 Choosing the file

IMPORTANT!
In order to print, you will need a file prepared in Sinterit Studio, which you can download from our
website: www.sinterit.com/software.
1. Select PRINTING from the main menu and press ADD NEW PRINT JOB.
2. Choose the new file (USB or UPLOADED from Sinterit Studio) or recently used file (RECENT) (fig. 6.1).
3. The following screen displays some basic information about the processed file (PRINT JOB) as well as the current
status of the printer (PRINTER STATUS). Press
you want to choose another file to print, press CHANGE PRINT JOB.
4. Press DONE (fig. 6.2).
USB
PRINT JOB NAME
PRINTING TIME
MATERIAL NAME
PRINT JOB NAME
PRINTING TIME
MATERIAL NAME
Fig. 6.1 Loading the file.
IMPORTANT!
If any part of the printer requires maintenance or replacement, a corresponding message will
appear on the screen.
IMPORTANT!
It is always possible to go back to the main menu on the screen without interrupting the printing
process.

6.4 Filling the print chamber with powder

IMPORTANT!
Remember to close the printer door! As a safety precaution, moving parts inside the printer
are locked in place while the door is open. Most actions will produce a warning and cannot be
performed while the printer door is open.
1. Slide the UNLOCK LID button to release the electrolock
and allow the print chamber to be opened (fig. 6.3).
Remember, you only have 10 seconds to open it before
the lock activates again.
2. Push on the lid and pull it up using the lid handle (fig.
6.4).
next to the component timer for more information. If at this point
TITLE
RECENT
PUMP2 POWEDER
NEEDED
14:45:45
0.001
TEXT
TEXT POWEDER
NEEDED
TEXT
0.001
TEXT
PRINTING - OPEN THE LID
CHANGE PRINT JOB
Fig. 6.2 PRINT JOB and PRINTER STATUS screen.
Fig. 6.3 Releasing the electrolock.
Sinterit Lisa X SLS 3D Printer Original User Manual | 27
PRINT JOB PRINTER STATUS
MODEL NAME PUMP_02
MATERIAL PA12
INTROGEN NO
PRINTING TIME 23:34:23
LAYER 3455
DONE
