SINTERIT LISA X Original User Manual page 56

9. Press UNLOCK DOOR on the screen and open the
printer door.
10. Check the amount of powder under the Feed Bed.
If the powder layer is thin and smooth – press the
MAINTENANCE DONE button (fig. 13.40).
11. If the powder layer has formed a mound – press the
REPLACE SEALING button (fig. 13.40).
12. Choose the right nozzle and vacuum the surface under
the Beds thoroughly (fig. 13.41). Press the DONE button.
13. Close the printer door and press the DONE button.
ATTENTION!
Vacuum the space under the Beds carefully!
Above are the bed motors, which can be damaged during cleaning.
14. In the print chamber, clean the Feed Bed thoroughly, especially screw heads.
15. Using a 2.5 [mm] allen key, unscrew and remove four screws securing the Feed Bed cover (fig. 13.42).
16. Remove the Feed Bed cover. You can use the metal spatula (from Dedicated Powder Tools) to pry up and remove the
cover (fig. 13.43).
Fig. 13.42 Unscrew the Feed Bed screws.
17. Remove the used fibreglass rope around the Feed Bed. You can use the metal spatula to help pull out the sealing (fig.
13.44).
18. Vacuum powder from the Feed Bed. Use appropriate nozzles (fig. 13.45).
Fig. 13.40 Check the amount of powder under the Beds.
Fig. 13.41 Vacuum the powder on the bottom of the printer.
Fig. 13.43 Remove the Feed Bed cover.
