3.3 Specification

One phase electrical circuit secured by:
GENERAL INFORMATION
Technology SLS - selective laser sintering
Laser type
Laser scanner type Galvo
Dimensions 650x610x1200 [mm] (25.6x24.0x47.2 [in])
Weight 145 [kg] (319.7 [lbs])
Operating voltage
Average power consumption 0.85 [kW]
Maximum power consumption 1.65 [kW]
PRINTER PARAMETERS
Size of Print Bed 150 x 200 x 350 [mm] (5.9 x 7.9 x 13.8 [in])
Layer height Z (min-max) 0.075 - 0.175 [mm] (0.003 - 0.006 [in])
Build Speed up to 14 [mm/h] (0.55 [in/h])
PRINT FEATURES
Min. wall thickness from 0.5 [mm] (0.020 [in])
Hole diameter from 0.5 [mm] (0.020 [in])
Moving part clearance from 0.2 [mm] (0.008 [in])
ADDITIONAL PRINTER FEATURES
Inert gas control system built-in
Average inert gas consumption 0.48 [m
Coupling installed in Lisa X Pneumatic quick-coupling Male Plug Nipple DN 7.2
IR Fiber Coupled Diode Laser, 30W; λ = 976 ± 3 [nm]
rated to > 30,000 hrs
POWER
230 [V] AC, 50/60 [Hz], 8 [A]
or 100-120 [V] AC, 50/60 [Hz], 15 [A]
• fuse rated at B16 [A];
• residual current circuit breaker 30 [mA];
• correctly working grounding system
/h] = 8 [l/min.]
3
