Summary of Contents for SINTERIT Lisa Pro
- Page 1 Sinterit Lisa Pro SHORTENED USER GUIDE Read the instruction manual before using the device. Version 1S...
-
Page 2: Table Of Contents
6. Cleaning the printer................................13 7. Technical support ................................15 The Shortened User Guide is a shortened version of the Sinterit LISA PRO user manual. For correct and trouble-free operation of the printer, please read the full user manual available at www.sinterit.com. -
Page 3: Sinterit Lisa Pro 3D Printer
5.Printer’s lid / 6.Lid’s handle / 7.Overflow Bin / 8.USB port / 9.Safety key switch / 10.Safety button (E-STOP) / 11.Hinges / 12.Access to gas installation / 13.Gas input / 14.Power socket / 15.Power switch Sinterit Lisa PRO USER MANUAL (short version) | 3... - Page 4 24.Recoater’s slide guide / 25.Recoater’s transmission 29.Embedded camera (captures image from the PRINT cables: short (replaceable) and long / 26.Feed Bed / BED) / 30.Print Bed pyrometer / 31.Feed Bed pyrometer 27.Print Bed / 28.Recoater 4 | Sinterit Lisa PRO USER MANUAL (short version)
-
Page 5: Preparing The Machine To Print
Do not use isopropyl alcohol! Pay attention to any fibers left on the surface. Clean both sides (Image 10). Image 10. Correct unmounting of the LASER PROTECTIVE GLASS. Sinterit Lisa PRO USER MANUAL (short version) | 5... - Page 6 Please contact the Support Team (section 7, page 15) by referring to the code displayed inside the warning triangle and providing the serial number of the device. 6 | Sinterit Lisa PRO USER MANUAL (short version)
-
Page 7: Printing - Standard Mode
LOAD FROM USB section will be displayed and a flash drive icon will appear on the left side of sections (Image 13). Image 13. Connecting a USB flash drive to the LISA PRO printer screen. IMPORTANT! After uploading the model on the printer’s internal storage, printed projects can be chosen from RECENT MODELS. - Page 8 • When working with powders always wear protective clothing (glasses, mask, gloves). • For the first use of the Sinterit LISA PRO Printer use only the powder (for PA12 SMOOTH and PA11 ONYX) from the container labeled PRINT READY POWDER.
- Page 9 The operation may complete quicker: whenever the powder uniformly covers the PRINT BED surface you can press STOPPING. Image 22. LEVELING DONE screen. Image 23. Stopping the leveling process manually screen. Sinterit Lisa PRO USER MANUAL (short version) | 9...
-
Page 10: Information And Tasks While Printing
BACK button on the LCD screen. Unlock Lid and start the Leveling process again. 17. Press START PRINTING button on the LISA PRO display and the printing process will start. 18. Upon confirmation, the progress of printing process will appear on the screen. -
Page 11: Finishing The Print
Leave the content with the printouts to cool down, for at least one hour Image 30. Correct condition of the BEDs content after (see image below). printing (visible cracks on the surface). Sinterit Lisa PRO USER MANUAL (short version) | 11... - Page 12 6. Transfer it to the container in which it will be mixed, with the FRESH POWDER (to refresh the used powder and prepare it for the next print). 7. Place the OVERFLOW BIN back in its place. Image 32. OVERFLOW BIN cleaning screen. Image 33. Correct cleaning of the OVERFLOW BIN. 12 | Sinterit Lisa PRO USER MANUAL (short version)
-
Page 13: Cleaning The Printer
3. Remove and clean the LASER PROTECTIVE GLASS. It is recommended to clean the glass before and after each print. In order to clean the glass, follow the instructions in the “Maintenance and service of the Sinterit LISA PRO Printer”, section 11 – available in the full version of the manual. - Page 14 All remaining powder should be placed into the OVERFLOW BIN through the gap. Confirm by clicking DONE (Image 42). Image 40. Removing powder from PRINT BED to OVERFLOW BIN. 14 | Sinterit Lisa PRO USER MANUAL (short version)
-
Page 15: Technical Support
IMPORTANT! More informations, f.ex. about nitrogen chamber, working with powders, etc. you can find in the full version of LISA PRO USER MANUAL. It is strongly recommend to read the full version before taking any action. Sinterit Lisa PRO USER MANUAL (short version) | 15... - Page 16 SINTERIT Sp.z o.o. ul. Kalwaryjska 69/9 30-504 Krakow, Poland www.sinterit.com Contact: +48 570 967 854...
