Recycling Kramer Products
The Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC aims to reduce
the amount of WEEE sent for disposal to landfill or incineration by requiring it to be collected
and recycled. To comply with the WEEE Directive, Kramer Electronics has made
arrangements with the European Advanced Recycling Network (EARN) and will cover any
costs of treatment, recycling and recovery of waste Kramer Electronics branded equipment on
arrival at the EARN facility. For details of Kramer's recycling arrangements in your particular
country go to our recycling pages at www.kramerav.com/il/quality/environment.

Overview

EXT3-21-XR-TR
(4:4:4) HDMI, USB, Ethernet, PoE power, RS−232, and IR signals over twisted pair, flexibly
set as transmitter−side or receiver−side device.
EXT3-21-XR-TR
signal and extends uncompressed video signals to up 100m (330ft) over CAT copper cables
at up to 4K@60Hz (4:4:4) video resolution.
EXT3-21-XR-TR
receives the HDBaseT 3.0 signal and converts it back into the original input signals. The
connected USB 3.1 peripherals, such as a room camera and microphone, are switchable for
use of the active USB host, for convenient hybrid meeting operation with both room and
online participants.
EXT3-21-XR-TR
flexible control.
Exceptional Quality
•
HDMI Signal Switching and Extension
through from the source to the display. Supports HDR10, deep color, x.v.Color™, lip
sync, HDMI uncompressed audio channels, Dolby TrueHD, DTS–HD, 2K, 4K, and 3D as
specified in HDMI 2.0.
•
Flexible USB Switching and Extension– An active USB 3.1 host is connected to the
extender at either the transmitter or receiver sides. USB 2.0 signals are extended
between the extender transmitter and receiver sides, and switched at the receiver side,
enabling connection of the active USB host to both local and remote USB devices, such
as camera and audio devices, or HID (Human Interface Devices) mouse or keyboard
devices.
•
Multi–channel Audio Transmission - Up to 32 channels of digital stereo uncompressed
signals for supporting studio–grade surround sound.
•
Ethernet Extension - Ethernet interface data flows in both directions, allowing extension
of up to 1 Gbps Ethernet connectivity for LAN communication and device control.
EXT3-21-XR-TR – Introduction
is a high−performance, extended−reach HDBaseT 3.0 extender for 4K60Hz
transmitter−side converts all input signals into the transmitted HDBaseT 3.0
receiver−side is an auto−switcher with HDMI and HDBaseT inputs that
provides exceptional quality, advanced and user-friendly operation, and
–
HDCP 2.3, EDID and CEC signals are passed
