Recycling Kramer Products
The Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC aims to reduce
the amount of WEEE sent for disposal to landfill or incineration by requiring it to be collected
and recycled. To comply with the WEEE Directive, Kramer Electronics has made
arrangements with the European Advanced Recycling Network (EARN) and will cover any
costs of treatment, recycling and recovery of waste Kramer Electronics branded equipment on
arrival at the EARN facility. For details of Kramer's recycling arrangements in your particular
country go to our recycling pages at www.kramerav.com/il/quality/environment.

Overview

Congratulations on purchasing your Kramer
Extender.
EXT3-U-KIT is a comprehensive, extended-reach CAT extender kit for USB 2.0, RS-232 and
audio signals and 2-way powering over twisted pair. The
USB input signal into a CAT signal. The
signal into a USB signal.
EXT3-U-KIT provides exceptional quality, advanced and user-friendly operation, and flexible
control:
•
Comprehensive USB Extender – Plug & play USB extender kit for providing extended-
reach CAT signals and 2-way power over twisted pair copper infrastructures. A local
USB host is auto-connected to remote-connected USB devices employing either
interrupt, bulk or isochronous USB 2.0 standard data transfer communication.
•
Flexible USB Connectivity – Wide Variety of USB peripheral devices can be extended
including cameras, touch screens, smart boards, hard drives, game controllers, audio
devices, printers, scanners, or HID (Human Interface Devices) devices such as a mouse
or keyboard. Dual role and OTG (On The Go) devices such as smart phones and
tablets, connected either to a transmitter–side USB host port or receiver-side USB
device port, can communication with a remote host or peripheral pairing device.
•
Remote USB Charging – Fast USB charging of peripheral devices when the receiver is
powered by a power supply, and standard USB charging when the receiver is powered
by the transmitter via CAT.
•
Bidirectional RS-232 Extension – Serial interface data flows in both directions, allowing
data transmission and device control.
•
Audio Extension – Send an audio signal from an audio source connected to the
transmitter to an active audio playing device connected to the receiver.
•
Cost-Effective Maintenance – Status LED indicators facilitate easy local maintenance
and troubleshooting.
•
Easy Installation – Single twisted-pair cable for signal and power wiring. Compact
PicoTOOLS® fan-less enclosure for device–back mounting, or side-by-side mounting of
4 units in a 1U rack space with the recommended rack adapter.
EXT3-U-KIT – Introduction
EXT3-U-KIT USB 2.0, RS-232 & Audio
EXT3-U-T
EXT3-U-R receiver converts the transmitted CAT
Kramer Electronics Ltd.
transmitter converts the
