Operating and Controlling
EXT3-21-XR-TR

Principles of Operation

•
Pair-synched Coupled AV+USB Auto Switching
•
Coupled or Individual AV+USB Switching
•
Flexible EXT3-21-XR-TR Auto Switching Policy
•
Online Meeting Systems Integration
•
Routing IP-Driven Control Signals via Built-in Control Gateway
Remote Buttons Control on page 16.
•
EXT3-21-XR-TR Flexible Powering
•
Single Device Operates as Either Tx or Rx
Pair-synched Coupled AV+USB Auto Switching
Two paired EXT3-21-XR-TR devices, one set as a transmitter (Tx mode) and the other set as
a receiver (Rx mode), feature a default inter-synched pairing operation; No additional control
system is needed to synch the pairing operation. This kit-like pair operation provides a cost-
effective solution for standard rooms with flexible support for both Room-Based Meeting
(RBM) or Bring Your Own Meeting (BYOM) hybrid meeting scenarios, as follows:
RBM scenario:
•
Rx-connected room PC/NUC is running the room-based meeting app, such as Zoom
Room.
•
The room PC/NUC is auto-connected to all room USB devices, both the Tx-connected
and Rx-connected USB devices.
EXT3-21-XR-TR – Operating and Controlling EXT3-21-XR-TR
on page 12.
on page 14.
on page 15.
on page 15.
on page 16.
on page 16.
Kramer Electronics Ltd.
on page 15.Flexible
