Cost–effective Maintenance - Status LED indicators for HDMI, Loop, HDBT, and USB
active host ports, facilitate easy local maintenance and troubleshooting.
•
Comprehensive and Cost–effective Management
IP−driven firmware upgrade and management via user−friendly embedded web pages,
and remote IP or local serial service and management via API commands and
responses communication, for flexible service options and ensure lasting, field proven
deployment.
•
Easy and Elegant Installation — PoE powering via LAN port connection, or bidirectional
PoE powering via HDBaseT port connection, and MegaTOOLS™ fan–less enclosure for
dropped–ceiling mounting, on or under table, or side–by–side mounting of 2 units in a
1U rack space with the recommended rack adapter, for easy switcher extender
deployment.

Typical Applications

EXT3-21-XR-TR
•
Advanced switcher extender building-block for enterprise and education hybrid solutions.
•
Upgrading deployed room solutions to hybrid-capable, controllable, and managed
solutions.
Controlling your EXT3-21-XR-TR
Control your EXT3-21-XR-TR
or:
•
Via the IP commands transmitted by a controller and touch screen system, or a browser
using built-in user-friendly Web pages.
•
By RS-232 serial commands transmitted by a touch screen system, PC, or a serial
controller.
EXT3-21-XR-TR – Introduction
is ideal for the following typical applications:
directly via the front panel push buttons, remote GPIO buttons
Kramer Electronics Ltd.
–
Local panel status LED, remote
