Kramer EXT3-C-XR-TR User Manual page 80

PRIORITY?
Set input priority.
PROT-VER?
Get device protocol
version.
.
RELAY-STATE
Set relay state
RELAY-STATE?
Get relay state.
ROUTE
Set layer routing.
This command
replaces all other
routing commands.
ROUTE?
Get layer routing state.
This command
replaces all other
routing commands.
SECUR Start/stop security.
The permission
system works only if
security is enabled
with the "SECUR"
command.
SECUR? Get security state.
The permission
system works only if
security is enabled
with the "SECUR"
command.
SIGNAL?
Get input signal status.
SN?
Get device serial
number.
TIME
Set device time and
date.
The year must be 4
digits.
The device does not
validate the day of
week from the date.
Time format - 24
hours.
Date format - Day,
Month, Year.
TIME? Get device time and
date.
The year must be 4
digits.
The device does not
validate the day of
week from the date.
Time format - 24
hours.
Date format - Day,
Month, Year.
EXT3-21-XR-TR – Protocol 3000
COMMAND
#PRIORITY?layer_type<CR>
FEEDBACK
~nn@PRIORITYlayer_type,priority_1,priority_2,priorit
y_3<CR><LF>
COMMAND
#PROT-VER?<CR>
FEEDBACK
~nn@PROT-VER3000:version<CR><LF>
COMMAND
#RELAY-STATEVrelay_id,state<CR>
FEEDBACK
~nn@RELAY-STATErelay_id,state<CR><LF>
COMMAND
#RESET<CR> #RELAY-STATE?relay_id<CR>
FEEDBACK
~nn@RESETok<CR><LF>
COMMAND
#ROUTElayer_type,out_index,in_index<CR>
FEEDBACK
~nn@ROUTElayer_type,out_index,in_index<CR><LF>
COMMAND
#ROUTE?layer_type,out_index<CR>
FEEDBACK
~nn@ROUTElayer_type,out_index,in_index
COMMAND
#SECURsecurity_state<CR>
FEEDBACK
~nn@SECURsecurity_state<CR><LF>
COMMAND
#SECUR?security_state<CR>
FEEDBACK
~nn@SECURsecurity_state<CR><LF>
COMMAND
#SIGNAL?in_index<CR>
FEEDBACK
~nn@SIGNALin_index,status<CR><LF>
COMMAND
#SN?<CR>
FEEDBACK
~nn@SNserial_num<CR><LF>
COMMAND
#TIMEday_of_week,date,data<CR>
FEEDBACK
~nn@TIMEday_of_week,date,data<CR><LF>
COMMAND
#TIME?<CR>
FEEDBACK
~nn@TIMEday_of_week,date,data<CR><LF>
layer_type – Layer Enumeration
1 – Video
– Priority of inputs (1-2)
priority
1 – USB-C 1
2 – HDMI 2
3 – HDMI 3
– XX.XX where X is a
version
decimal digit
– Relay number1-2
relay_id:
state: – Relay state
0 – (open)
1 – (close)
relay_id: – Relay number1-2
state: – Relay state
0– (open)
1– (close)
layer_type
Layer Enumeration
1 – Video
5 – USB
out_index
1 – Output
–
in_index
Source id for Video:
1 – USB-C 1
2 – HDMI IN 2
3 – HDMI IN 3
layer_type
Layer Enumeration
1 – Video
5 – USB
out_index
<CR><LF>
1 – Output
–
in_index
Source id for Video:
1 – USB-C 1
2 – HDMI IN 2
3 – HDMI IN 3
security_state
0 – OFF (disables security)
1 – ON (enables security)
security_state
0 – OFF (disables security)
1 – ON (enables security)
– Number that indicates the
in_index
specific input:
1 – USB-C IN 1
2 – HDMI IN 2
3 – HDMI IN 3
status – Signal status according to
signal validation:
0 – Off
1 – On
– 14 decimal digits,
serial_num
factory assigned
– One of
day_of_week
{SUN,MON,TUE,WED,THU,FRI,SAT}
– Format: DD-MM-YYYY.
date
– Format: hh:mm:ss where
data
hh = hours
mm = minutes
ss = seconds
– One of
day_of_week
{SUN,MON,TUE,WED,THU,FRI,SAT}
– Format: YYYY/MM/DD where
date
YYYY = Year
MM = Month
DD = Day
– Format: hh:mm:ss where
data
hh = hours
mm = minutes
ss = seconds
Kramer Electronics Ltd.
Get the input priority:
#PRIORITY?1<CR>
Get the device protocol
version:
#PROT-VER?<CR>
Set relay 2 to closed:
#RELAY-STATE
Get relay state:
#RELAY-STATE?
Route video input 2 to the
output:
#ROUTE1,1,2<CR>
Get video routing output:
#ROUTE?1,1<CR>
– Security state
Enable the permission
system:
#SECUR1<CR>
– Security state
Enable the permission
system:
#SECUR?<CR>
Get the input signal lock
status of IN 1:
#SIGNAL?1<CR>
Get the device serial
number:
#SN?<CR>
Set device time and date to
December 5, 2020 at
2:30pm:
#TIMEmon05-12-
2020,14:30:00<CR>
Get device time and date:
#TIME?<CR>
78
,

<CR>

<CR>
