Kramer EXT3-C-XR-TR User Manual page 69

Function Description
BUILD-DATE?
Get device build date.
CEC-MEMBERS?
Get list of CEC logical
addresses.
CEC-NTFY- Set CEC notification
ACTIVE activity (valid until the
next power up).
CEC-NTFY- Get CEC notification
ACTIVE? activity status.
CEC-SND
Send CEC command
to port.
COM-ROUTE?
Get tunneling port
routing.
This command
sets tunneling port
routing. Every com
port can send or
receive data from the
ETH port.
Set command can edit
an existing
configuration.
CONF-EXPORT
Export configuration
file
CONF-IMPORT
Export configuration
file
COUNTER? Get the sent or
received CEC
messages count.
COUNTER-CLR
Clear CEC messages.
EXT3-21-XR-TR – Protocol 3000
Syntax
COMMAND
#BUILD-DATE?<CR>
FEEDBACK
~nn@BUILD-DATEdate,time<CR><LF>
COMMAND
#CEC-MEMBERS?port_index<CR>
FEEDBACK
~nn@CEC-MEMBERSport_index,<la1>,<la2>...<CR><LF>
COMMAND
#CEC-NTFY-ACTIVEcec_ntf<CR>
FEEDBACK
~nn@CEC-NTFY-ACTIVEcec_ntf<CR><LF>
COMMAND
#CEC-NTFY-ACTIVE?<CR>
FEEDBACK
~nn@CEC-NTFY-ACTIVEcec_ntf<CR><LF>
COMMAND
#CEC-
SNDport_index,sn_id,cmd_name,cec_len,cec_command<CR>
FEEDBACK
~nn@CEC-
SNDport_index,sn_id,cmd_name,cec_mode<CR><LF>
COMMAND
#COM-ROUTE?com_id<CR>
FEEDBACK
~nn@COM-ROUTEcom_id,port_type,port_id,eth_rep_en,pin
g_val<CR><LF>
COMMAND
#CONF-EXPORT<CR>
FEEDBACK

~nn@CONF-EXPORT filename<CR><LF>
COMMAND
#CONF-IMPORTfile_name<CR>
FEEDBACK
~nn@CONF-IMPORTfile_name<CR><LF>
COMMAND
#COUNTER?category_id,sub_category_id<CR>
FEEDBACK
~nn@COUNTERcategory_id,sub_category_id,count<CR><LF>
COMMAND
#COUNTER-CLR?category_id,sub_category_clr<CR>
FEEDBACK
~nn@COUNTER-
CLRcategory_id,sub_category_id,count<CR><LF>
Kramer Electronics Ltd.
Parameters/Attributes
date – Format: YYYY/MM/DD where
YYYY = Year
MM = Month
DD = Day
– Format: hh:mm:ss where
time
hh = hours
mm = minutes
ss = seconds
– 1
Port_index
– 1 to 15
la
–
cec_ntf
0 – Inactive
1 – Active
–
cec_ntf
0 – Inactive
1 – Active
port_index – CEC port transmitting
the command: 1
sn_id – 1
– command name
cmd_name
– 1–16
cec_len
– CEC format
cec_command
command (in HEX format, no leading
zeros, no '0x' prefix)
– CEC mode
cec_mode
0 – Sent
1 – Gateway disabled
2 – Inactive CEC-Master
3 – Busy
4 – Illegal Message Parameter
5 – Illegal CEC Address Parameter
6 – Illegal CEC Command
7 – Timeout
8 – Error
– Machine dependent, * (get
com_id
all route tunnels)
– TCP/UDP
port_type
0 – TCP
1 – UDP
– TCP/UDP port number
port_id
– Ethernet Reply
eth_rep_en
0 – COM port does not send replies
to new clients
1 – COM port sends replies to new
clients.
– Send an empty string to
ping_val
TCP client every 0 to 3600 seconds. 0 -
3600
the name of the file we
file_name -
want to upload for the export.
the name of the file we
file_name -
want to upload for the import.
– CEC messages: 0
category_id
– Type of
Sub_category_id
message:
0 – Sent message
1 – Received message
count – Number range: 0-65535
– CEC messages: 0
category_id
– Type of
Sub_category_clr
message to clear:
0 – Clear sent messages
1 – Clear received messages
* – Clear all CEC messages
Example
Get the device build date:
#BUILD-DATE?<CR>
Set gateway members:
#CEC-MEMBERS?1<CR>
Enable CEC notification:
#CEC-NTFY-
ACTIVE1<CR>
Get CEC notification activity
status::
#CEC-NTFY-
ACTIVE?<CR>
Send TV-OFF CEC
command to the HDBaseT
port:
#CEC-SND1,1,TV-
OFF,2,e004<CR>
Get tunneling port routing
for all route tunnels:
#COM-ROUTE?*<CR>
Export configuration file:
#CONF-EXPORT<CR>
Import configuration file:
#CONF-IMPORT EXT3-
21-XR-TR-conf<CR>
Get the number of sent
messages:
#COUNTER?0,0<CR>
Clear all CEC messages:
#COUNTER-CLR?0,*<CR>
67
