- Page 1 USER MANUAL MODEL: EXT3-U3-T / EXT3-U3-R USB 3.2 Gen 1 Extender−Receiver P/N:2900-301820 Rev 1 www.kramerav.com...
-
Page 2: Table Of Contents
Kramer Electronics Ltd. Contents Introduction Getting Started Overview Typical Applications Defining EXT3-U3-T / EXT3-U3-R USB 3.2 Gen 1 Extender−Receiver Defining EXT3-U3-T Defining EXT3-U3-R Mounting EXT3-U3-T/R Connecting EXT3-U3-T/R Connecting to EXT3-U3-T/R via RS-232 Wiring RJ - 45 Connectors Technical Specifications EXT3-U3-T/R – Contents... -
Page 3: Introduction
Kramer Electronics Ltd. Introduction Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been providing a world of unique, creative, and affordable solutions to the vast range of problems that confront the video, audio, presentation, and broadcasting professional on a daily basis. In recent years, we... -
Page 4: Recycling Kramer Products
USB2.0/1.1 devices. In addition to USB3, the kit extends RS232 signals and FSYNC video signal (for camera frame synchronization). The EXT3-U3-T transmitter unit converts the USB3 host side signal into a CATx signal format based on HDBaseT.USB. The EXT3-U3-R receiver unit converts the CATx signal back into a USB3 device side signal and functions as a USB hub for up to 3 devices. -
Page 5: Typical Applications
Cost-Effective Maintenance – Status LED indicators facilitate easy local maintenance and • troubleshooting. Typical Applications EXT3-U3-T/R is ideal for the following typical applications: USB Camera deployment in meeting spaces and lecture halls Extending Video Over USB formats like UVC or DisplayLink ... -
Page 6: Defining Ext3-U3-T / Ext3-U3-R Usb 3.2 Gen 1 Extender−Receiver
Connect to USB local devices (for example, a USB camera, a sound-bar, microphone, etc.). All 3 USB connectors on the receiver can provide power. PWR LED Lights green when powered. LINK LED Lights blue when a link is established. EXT3-U3-T/R – Defining EXT3-U3-T / EXT3-U3-R USB 3.2 Gen 1 Extender−Receiver... - Page 7 RS-232 4-pin Terminal Block Connector Rx, Tx: RS-232 interface pass-through extension (supports any baud rate up to 115200). Service 3-pin Terminal Block Connector Connect for firmware upgrade. (G, Rx, Tx) EXT3-U3-T/R – Defining EXT3-U3-T / EXT3-U3-R USB 3.2 Gen 1 Extender−Receiver...
-
Page 8: Mounting Ext3-U3-T/R
Kramer Electronics Ltd. Mounting EXT3-U3-T/R This section provides instructions for mounting EXT3-U3-T/R. Before installing, verify that the environment is within the recommended range: • Operation temperature – 0° to 40°C (32 to 104°F). • Storage temperature – -40° to +70°C (-40 to +158°F). -
Page 9: Connecting Ext3-U3-T/R
,Blu-Ray player). Alternatively, you can connect RS-232 ports the other way around: connect a controlled device to the EXT3-U3-T RS-232 port and a controller to the EXT3-U3-R RS-232 port. 3. Connect the USB type A ports on the EXT3-U3-R to USB devices (for example, KAC-CAM-50M and/or a smartphone). -
Page 10: Connecting To Ext3-U3-T/R Via Rs-232
EXT3-U3-T/R features an RS-232 3-pin terminal block connector control of an RS-232 device over the extension. Connect the RS-232 terminal block on the rear panel of EXT3-U3-T/R to a PC/controller, as follows: From the RS-232 9-pin D-sub serial port connect:... -
Page 11: Technical Specifications
Storage Temperature: -40° to +70°C (-40° to 158°F) Conditions Humidity: 10% to 90%, RHL non-condensing Safety: CE, FCC, UL Regulatory Compliance Environmental: RoHs, WEEE Demi Tool Demi Tool Enclosure Type: Aluminum Cooling Passive Accessories Power adaptor Included EXT3-U3-T/R – Technical Specifications... - Page 12 SAFETY WARNING Disconnect the unit from the power supply before opening and servicing For the latest information on our products and a list of Kramer distributors, visit our website where updates to this user manual may be found. We welcome your questions, comments, and feedback.
